ACCESSORIES
Carry Bag
Rugged double-stitched construction - CBAG-W
Pouch & Digger Combo
Pouch with 2 large pockets & 9" heavy duty digging tool. TP-KIT-W
Bounty Hunter Stereo Headphones
Use with Bounty Hunter metal detectors. Lightweight and adjustable with
true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor,
4' cable. HEAD-W
Pin Pointer
Pinpoints the exact location of buried metal objects. Audio signal indicator
and vibrator. Runs on 1 – 9-Volt Battery. PIN POINTER-W
Sand Scoop
Large scoop with filtering holes. Made of strong plastic. SAND SCOOPBH
Coil Covers
Protect your coil from abrasion and damage.
10" Coil Cover – 10COVER
8" Coil Cover – 8COVER-7
4" Coil Cover – 4COVER
Replacement/Accessory Search Coils
10" Magnum Coil – 10COIL
8" Replacement Standard Coil – 8COIL-7BLK
4" Gold Nugget Coil – 4COIL
9" Heavy-Duty Digging Tool
Metal blade with comfortable plastic handle and depth gauge TROWEL-2
Digging Tool
Light and practical wide blade digging tool. TROWEL-W
Bounty Hunter T-Shirt
®
100% cotton with Bounty Hunter
Logo. Sizes – LG, XL & XXL
Bounty Hunter Baseball Cap
One size fits all, with Bounty Hunter
®
logo.
Gold
Prospecting Kits
FOR COMPLETE DETAILS VISIT WWW.DETECTING.COM • 1-800-413-4131
ME2200B
Rev.3
102912
O W N E R ' S
The Elite 2200 is a
professional metal detector.
While the most difficult aspects of metal detecting have been
automated, it is a sophisticated electronic device which
requires an understanding of some basic features and metal detecting
concepts.
If you do not have prior experience with a metal detector, we strongly
recommend that you:
1) Adjust the Sensitivity to a low setting in the event of false
signals. Always begin use at a reduced sensitivity level; increase to
full sensitivity after you have become familiar with the detector.
2) Do not use indoors. This detector is for outdoor use only. Many
household appliances emit electromagnetic energy, which can
interfere with the detector. If conducting an indoor demonstration,
turn the sensitivity down and keep the searchcoil away from
appliances such as computers, televisions and microwave ovens.
If your detector beeps erratically, turn off appliances and lights,
especially those with dimmer switches.
Also keep the searchcoil away from objects containing metal, such
as floors and walls.
3) Read this manual. Most importantly, review the Quick-Start Demo
(p.7-8) and Basic Operation (p. 9-12).
4) Use 9-volt ALKALINE batteries only. Do not use Heavy Duty
Batteries.
M A N U A L
Advertisement
Related Manuals for Bounty Hunter Elite 2200
Summary of Contents for Bounty Hunter Elite 2200
- Page 1 Pouch & Digger Combo Pouch with 2 large pockets & 9” heavy duty digging tool. TP-KIT-W Bounty Hunter Stereo Headphones Use with Bounty Hunter metal detectors. Lightweight and adjustable with true stereo sound, adjustable volume, 1/8 jack with 1/4 adaptor, 4’ cable. HEAD-W O W N E R ’...
-
Page 2: Table Of Contents
Liability under this Warranty is limited to replacing or repairing, at our option, any Bounty Hunter Notch ......11 Detector returned, shipping cost prepaid, to First Texas Products, LLC. -
Page 3: Troubleshooting
Ground Balancing is the ability of the detector to ignore, or "see through," the earth’s naturally occurring minerals, and only sound a tone when a metal object is detected. The Elite 2200 incorporates proprietary Squelch-Tech® circuitry to eliminate false signals from... -
Page 4: Assembly
Assembly In The Field Techniques (continued) Swing searchcoil slowly, rather than a silver or copper object. Assembly is easy and requires no tools. overlapping each sweep as you If the tone changes at different Position detector upright. move forward. It is important to angles, you may have encountered LOCKING sweep the coil at a consistent speed... - Page 5 Assembly In The Field Techniques Adjusting the Armrest PINPOINTING COIL MOVEMENT Most people will find the standard position rest very Accurate pinpointing takes practice When swinging the coil, be comfortable. Very large forearms and and is best accomplished by careful to keep it level with the short forearms (particularly children’s “X-ing”...
-
Page 6: Batteries
A secondary use for the Sensitivity Control is to reduce false detection Close the battery door. signals caused by severe ground conditions. While your Elite 2200 contains circuitry to eliminate the signals caused by most naturally When only the bottom segment of the battery indicator is illuminated, occurring ground minerals, 100% of all ground conditions cannot be replace the batteries. -
Page 7: Quick-Start Demo
Turn off appliances or lights that cause electromagnetic categories. While the Elite 2200 will buried object, you could be detecting a interference. eliminate or indicate the presence of most... - Page 8 Audio Target Identification Quick-Start Demonstration (continued) While the LCD (Liquid Crystal Display) is very accurate in identifying VI. Wave the Nail over the searchcoil buried objects, the user in the field does not always maintain the display screen in his field of vision. Therefore, we have incorporated an audio a.
- Page 9 Press the POWER touch pad. HEADPHONE JACK • The detector will beep 4 times • All display segments will illuminate momentarily The Elite 2200 Metal • The SENSITIVITY and BATTERY indicators will Detector has a stereo stay illuminated headphone jack located at the rear of the case.
-
Page 10: All Metal
Basic Operation (continued) Basic Operation (continued) touch pad. Each time the L pad is depressed, an additional "R" will DEFAULT OPERATION appear, thus eliminating from detection the objects which fall into the The detector defaults to ALL METAL mode after powering on. In this corresponding categories.
