Media Supply Roll Post
EasyCoder PM4i Printer User's Guide (IPL Version)
Themediasupplyrollpostfitsboth38-40mm(1.5in)and76
mm(3.0in)coresbecauseitcanbemovedupordowninaslot
inthecentersection.Thebottompositionisintendedforsmall
coresandthetoppositionisforlargecores.Thepostislockedby
astraight-slotscrew.
Theposthasamoveableedgeguidetofitvariousmediawidths.
Asstandard,alowguideisfactory-fittedonthepostandahigh
guideispackedseparatelywiththeotherprinteraccessories.
Whenswitchingtheedgeguide,becarefulnottobreakit.Inthis
manual,thehighedgeguideisgenerallyillustrated.
Whentheedgeguideisinitsoutermostposition,itcanbetilted
downtoahorizontalattitudetoallowremovaloftheemptycore
andloadingofanewmediaroll.Afterloadingthemediaroll,tilt
uptheedgeguideandpushitinwardssothemediarollbecomes
flushwiththecentersection.Thelowedgeguideallowsmedia
rollswith3-incorestobeloadedwithouttiltingdowntheguide.
m
in
E
0m
(1.5
Screw
(hidden)
Optionally,theprintercanbefittedwithan1.5-inrotating
mediasupplyhubinsteadofapostandapapersensor,which
detectswhentheremainingamountofmediahasreachalevel
specifiedintheSetupMode.Therearealsoa3-inadapteranda
labelrollretainer.Anotheroptionisaninternalguideformedia
placedbehindtheprinter(forexamplefanfolds).For
illustrations,see"Options"onpage67.
Chapter 2 — Installation
Low edge guide
(standard)
High edge guide
(accessory)
