- Page 1 Installation Guide Installation Wireless USB to VGA Kit GUW2015VKIT PART NO. M1062...
-
Page 3: Table Of Contents
Table of Contents System Requirements Important Information Package Contents Device Overview Wireless USB Host Adapter Wireless VGA Adapter Wireless VGA Software Installation Wireless VGA Display Settings Wireless USB Manager Wireless USB Host Adapter Settings Wireless USB Host Adapter Selection Wireless USB Host Adapter Reset Wireless VGA Adapter in wired mode Frequently Asked Questions Technical Specifications... -
Page 4: System Requirements
System Requirements - Microsoft Windows ® XP 32-bit (Service Pack 2) - Microsoft Windows ® Vista ® - USB 2.0 Compliant hardware and system - Display with VGA port (VGA cable not included) 32/64-bit... -
Page 5: Important Information
Important Information Before you get started, please NOTE: Do not place Wireless USB devices under direct sunlight or near high heat emitting devices; Do not place Wireless USB devices near water or wet surfaces to avoid electric hazards; Do not place Wireless USB devices on any moving or unstable surfaces. -
Page 6: Package Contents
Package Contents 1 x Wireless USB Host Adapter (for PC) 1 x Wireless VGA Adapter (for Monitor/TV/Projector) 1 x USB 2.0 A to mini-B Cable (3 ft.) 1 x USB 2.0 Extension Cable (5 ft.) 1 x Velcro fabric hook-and-loop fastener 1 x Power Adapter 1 x Quick Start Guide 1 x Registration / Warranty Card... -
Page 7: Device Overview
Device Overview Wireless USB Host Adapter 1. LINK: Data Transfer Activity Indicator LED blinks when data is being transferred 2. PWR: Power LED is solid when powered by the PC... -
Page 8: Wireless Vga Adapter
Wireless VGA Adapter 5 6 7... - Page 9 1. VGA : VGA Activity Indicator a. LED is solid when display cable is connected b. LED is blinking when data is being transferred 2. PWR: Power Indicator a. LED is solid when power is applied 3. 1 – 2 – 3: Status Indicator Single* solid light: device is wirelessly connected to the selected Wireless USB Host Adapter Single* slowly blinking light: device is searching for...
-
Page 10: Wireless Vga Software Installation
Step 3 – Choose installation method. The next screen will let you choose whether you want to install the latest software from the IOGEAR website or if you want to install the software directly from the installation CD. - Page 11 If selecting Option 2: Download latest software installer from the Web, a web browser window will launch directing you to the IOGEAR website where you will find the most up-to-date software. Once you download the software, double-click on the .exe file to begin the installation process.
- Page 12 Step 5 – For Windows XP users, if you do not have Microsoft .NET Framework 2.0 installed, you will be prompted to have it installed. Click “Yes” to install .NET 2.0 Framework. Check “License Agreement” and click “Install”. Click “Finish” to complete installing .NET Framework 2.0. Restart the computer when prompted.
- Page 13 Step 7 - Driver Installation for Wireless USB Host Adapter. Make sure the antenna is connected to the Wireless USB Host Adapter. Plug the Wireless USB Host Adapter to your computer via option 1 or 2. Windows will detect the device and complete the driver installation process automatically.
- Page 14 Option 2: If using with a Desktop PC, plug the Wireless USB Host Adapter into an available USB 2.0 port utilizing the provided extension cable. Place the extension cable on a fl at surface, preferably the top of the desk/work area in order to ensure a good line-of-sight signal with the Wireless VGA Adapter.
- Page 15 Step 8 - Driver Installation for Wireless VGA adapter Make sure the antenna is connected to the Wireless VGA adapter. Connect one end of the VGA cable (not in- cluded) to the Wireless VGA Adapter, and the other end to your display’s blue VGA port. •...
- Page 16 • For Projector...
- Page 17 Plug the power cable into the Wireless VGA adapter. Make sure the Power Indicator LED is solid.
- Page 18 Windows will automatically install the appropriate Wireless VGA Adapter drivers. Change your display’s setting to select VGA as your input device. Please refer to the operating instructions supplied with your display. ® You may use the included Velcro fabric hook- and-loop fastener to attach the Wireless VGA adapter to your projector or LCD display in order to ensure a good line-of-sight signal with the...
-
Page 19: Wireless Vga Display Settings
Wireless VGA Display Settings To change the display settings, right click on the Monitor icon in the Windows system tray. A menu will appear and you will have the ability to change parameters such as resolution, color quality, mirror mode or extension mode and more. - Page 20 There are two options to adjust the Resolution, Color Quality, Screen Rotation, and Extended or Mirror Mode. One is to click on the IOGEAR DisplayLink Manager icon in the Windows tray as shown above, another is to go to Control Panel, double click on “Display”, then choose...
- Page 21 To set up the Wireless VGA Adapter to mirror the primary display: Go to the “Settings” tab of the Display Properties page Click on the Monitor connected to the “IOGEAR Wireless USB VGA adapter” Ensure that “Extend my Windows desktop onto this monitor” is Unchecked Click “Apply”...
- Page 22 To set up extended mode: Go to the “Settings” tab of the Display Properties page Click on the Monitor connected to the “IOGEAR Wireless USB VGA adapter” Ensure that “Extend my Windows desktop onto this monitor” is checked Click “Apply”...
- Page 23 Screen Refresh Rate Configuration To adjust the refresh rate of the extended screen, click on “Advanced” and then the “Monitor” tab.
-
Page 24: Wireless Usb Manager
Wireless USB Manager The Wireless USB Manager is a simple and easy- to-use interface that allows you to manage your Wireless USB devices and control your Wireless USB Host Adapter settings. The Wireless USB Manager can be accessed via the Wireless USB Manager icon located in the Windows system tray. - Page 25 If your Wireless VGA Adapter is connected and working, then the icon will change and show the current signal strength. The View menu will give the option of what type of devices you wish to display (All Devices, Connected Devices and Disconnected Devices). The Options menu will give the option to launch Host Settings window and turn the Wireless USB Host Adapter radio on or off.
-
Page 26: Wireless Usb Host Adapter Settings
Wireless USB Host Adapter Settings To manage the Wireless USB Host Adapter settings, either select “Host Settings” in the “Option” menu of the Wireless USB Manager application or right click on the Wireless USB Manager icon in the Windows tray. •... - Page 27 • Advanced Settings Channel selection: this function allows you to manually set a radio channel (not recommended) for the wireless communication (combination of Band Group and Channel). For optimal performance, the automatic setting is recommended.
-
Page 28: Wireless Usb Host Adapter Selection
Wireless USB Host Adapter Selection To use this button, you must purchase at least one additional Wireless USB Host Adapter (GUWA200). The additional Wireless USB Host Adapters not included in this kit will have to go through the association process before they can be used with the Wireless VGA Adapter. For more information about the association process, please refer to Appendix - Cable association with other devices . -
Page 29: Wireless Usb Host Adapter Reset
Wireless USB Host Adapter Reset To erase all Wireless USB Host Adapters (except the Wireless USB Host Adapter included in this kit) associated* to your Wireless VGA Adapter, hold down the “RESET” button on the Wireless VGA Adapter for 10 seconds. This will cause the Wireless VGA Adapter to erase all Wireless USB Host Adapters that have been associated from its list. -
Page 30: Wireless Vga Adapter In Wired Mode
Wireless VGA Adapter in Wired Mode Your Wireless VGA Adapter can also be used in wired mode. Make sure the position of the WIRELESS/WIRED switch is in the WIRED position. Plug the USB cable between your computer and the Wireless VGA Adapter. The function is the same as the wireless mode but data will be transferred through the cable and does not require the use of the Wireless USB... -
Page 31: Frequently Asked Questions
Frequently Asked Questions For the latest FAQs, please go to IOGEAR website (www.iogear.com). Why can’t I install .NET? You may have an older version of .net, preventing the newer one from being installed. Using Add/Remove Programs or Programs and Features on the Control Panel, uninstall any version of Microsoft .NET Framework older than version 2.0. - Page 32 If you see an icon that is grayed out in the Wireless USB Manager, try resetting the Wireless VGA Adapter by unplugging its power cord and plugging it back in. You should see the icon in the Wireless USB Manager appear in color when it is connected.
- Page 33 Why is my video choppy? If you are experiencing choppy video, try changing the channel or move in your computer closer to the display.
-
Page 34: Technical Specifications
Technical Specifications Specifications Function Operating System Support PHY Data Rate Operating Range Frequency Number of Channels RF Modulation Type Interface Video Resolution Video Streaming GUW2015VKIT Microsoft XP 32-bit; Microsoft Vista 32/64-bit 53.3Mbps, 80Mbps, 106.6Mbps, 160Mbps, 200Mbps, 320Mbps, 400Mbps, 480Mbps Up to 30 feet (10 meters) 3.1GHz to 4.8GHz (WiMedia Band Group 1) 7 channels (3 FFI + 4 TFI) QPSK/DCM... - Page 35 Screen Mode Color Depth USB Specification Association Mode Native Mode Antenna Type Reset Switch Power Consumption Max Output Power Power Adapter Extended and Mirror mode 32-bit True Color Certified Wireless USB 1.0; USB 2.0 Pre-Association and Cable Association; Stores up to 16 Associated Hosts For playback of high resolution video Omni directional Used for erasing association history by pressing...
-
Page 36: Limited Warranty
The direct vendor also reserves the right to revise or update the device or documentation without obligation to notify any individual or entity of such revisions, or updates. For further inquiries please contact IOGEAR. -
Page 37: Federal Communications Commission
Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device is authorized under 47 CFR 15.519 (the FCC Rules and Regulations). -
Page 38: Contact
All information furnished here is for informational purposes only and is subject to change without notice. IOGEAR, Inc. assumes no responsibility for any inaccuracies or errors that may appear in this... -
Page 39: Appendix
Complete the installation of the Wireless VGA kit as shown in the Wireless VGA Software Installation section. Install the GUWH104 software “Driver Hub Only” for your Wireless USB Hub from IOGEAR website. Please make sure that you are in the correct product page. -
Page 40: Cable Association
II. Cable association with other devices Association Concept: In order to establish a secure wireless connection, between both the Wireless USB Host Adapter and the Wireless USB devices, you will need to go through the cable association process. The association process will allow the Wireless USB Host Adapter and the Wireless USB device to exchange security information about each other necessary to operate in a secured wireless mode. - Page 41 Cable association steps: Make sure that the Wireless USB Manager is running. Check your Windows tray for the Wireless USB Manager icon. Power on your Wireless USB device. Connect the USB cable between an available USB port on your computer and your Wireless USB device.
- Page 42 Associated Wireless USB devices will appear as icons in the Wireless USB Manager. When the Wireless USB device is connected to your computer, the icon will appear in color.
