- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. CSB4411...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. CSB4411 Voltage: 230/240 Volts AC 50Hz Wattage: 10.9/11.9kW Height: 1290mm Width: 550mm Depth: 595mm Weight: 54kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC... -
Page 3: Table Of Contents
CONTENTS Technical Details ............................ Contents ..............................Preface ..............................Safety ..............................Before Installation ........................... During Operation ..........................After Use ............................General ............................Introduction ............................Rating Plate ............................ Installation ............................Reversible Oven Door ........................General Notes on Using Your Appliance ..................About Condensation and Steam ....................Grill and Oven Furniture ......................... -
Page 4: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 5: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN DURING OPERATION THE INTERESTS OF YOUR SAFETY. Do not use this appliance if it is in ENSURE THAT YOU UNDERSTAND contact with water. Never operate THEM ALL BEFORE INSTALLING OR it with wet hands. USING THE APPLIANCE. -
Page 6: After Use
Take care follow Do not leave utensils containing recommendations given foodstuffs, e.g. fat or oil in or on tending the food when grilling. appliance case inadvertently switched ON. Always oven gloves Cookers and hobs become very remove and replace food in the hot, and retain their heat for a long oven. -
Page 7: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED The cable should be routed away from potentially hot areas marked by X in the diagram below. RATING PLATE This is situated on the front frame of the appliance and can be seen upon opening the top cavity door. Alternatively the rating plate may also be found on the back or top of some models (where applicable). -
Page 8: Reversible Oven Door
REVERSIBLE MAIN OVEN DOOR GRILL AND OVEN FURNITURE If you require the oven door to be hinged on the The following items of grill/oven furniture have opposite side, you will need to contact a qualified been supplied with the appliance. If you require Service Engineer. -
Page 9: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Timer - Oven Temperature Control - Oven Indicator Neon - Grill Control - Hotplate Controls... -
Page 10: The Timer
THE TIMER A CLOCK/COOK TIME SETTING KNOB B START TIME SETTING KNOB C MINUTE HAND D MANUAL SYMBOL ( E DISPLAY WINDOW F START TIME INDICATOR G HOUR HAND 1. TO SET THE TIME OF DAY The clock will operate when the appliance is switched ON at the wall. - Page 11 4. TO CANCEL THE MINUTE MINDER Turn setting knob (A) anti-clockwise, without pushing it in until the manual symbol ( appears in the display window as Fig.4. 5. HOW TO SET THE OVEN TIMER When using the oven timer for the very first time, it is advisable to let it operate while you are at Fig.
- Page 12 B) TO SET THE TIMER TO SWITCH OFF AUTOMATICALLY Make sure the electricity supply is switched on. ii) Ensure the clock shows the correct time of day and the appliance is set to manual. Adjust as necessary. iii) Place food in oven. iv) To set the length of time you want the food to cook;...
-
Page 13: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 14: Deep Fat Frying
6. Frying temperatures DEEP FAT FRYING Celsius Fahrenheit Scale (°C) Scale (°F) SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one third full of oil, DO NOT cover the pan with a lid First frying of potatoes and DO NOT leave the pan unattended. -
Page 15: The Grill
THE GRILL USES OF THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHLDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL • Ensure the handle is correctly located. It is not Turn the grill control to the required setting. necessary to remove the grill pan handle during •... -
Page 16: Hints And Tips
To check the progress of the food being grilled, the GRILLING CHART grill pan should be withdrawn on the shelf to tend the food during cooking, or the carrier shelf can be lifted RUNNER GRILL TIME away from the appliance and rested on a heat FOOD POSITION (mins in total) -
Page 17: The Oven
THE OVEN SELECTING THE OVEN • HINTS AND TIPS To operate the oven simply set the oven control • dial to the required temperature. Arrange the shelves in the required positions before switching the oven ON. Shelf positions are numbered from the bottom upwards. THINGS TO NOTE The oven indicator neon will glow until the oven has reached the desired temperature and then... -
Page 18: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. Shelf positions are counted from the bottom of the oven. MAIN OVEN APPROXIMATE COOKING... -
Page 19: Oven Roasting Chart
ROASTING CHART TEMPERATURES (°C) COOKING TIME MEAT OVEN 20-35 minutes per ½kg (1lb) Beef 180-200 and 20-35 minutes over Beef, boned 180-200 25-35 minutes per ½kg (1lb) and 25-35 minutes over Mutton and Lamb 180-200 25-35 minutes per ½kg (1lb) and 25-35 minutes over Pork and Veal 180-200... -
Page 20: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE THINGS TO NOTE ELECTRICITY SUPPLY AT THE MAIN The red spot in the centre of the hotplates may be WALL SWITCH AND ALLOW THE removed with some abrasive cleaning agents. This is not a fault and does not affect the performance of APPLIANCE TO COOL BEFORE the hotplates. -
Page 21: Cleaning The Grill And Oven Furniture
CLEANING GRILL OVEN HINTS AND TIPS FURNITURE • Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if All removable parts except the grill pan handle can abrasives or aerosol sprays of any kind are used. be washed in the dishwasher. •... -
Page 22: Something Not Working
SOMETHING NOT WORKING? Before calling an Engineer please carry out the following checks, you may be able to solve the problem without the expense of an engineer. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 23: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquires concerning your Tricity Bendix appliance, or for further information on Tricity Bendix products, please contact our Customer Care Department by letter or telephone at the address below;... -
Page 24: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •... -
Page 25: Notes
NOTES... - Page 26 NOTES...
- Page 27 NOTES...
- Page 28 In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. TRICITY BENDIX 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ.
