Summary of Contents for Electrolux ERH 3620 X
- Page 1 - f r e e z e r INSTRUCTION BOOK ERH 3620 X 2222 089-72...
-
Page 2: Important Safety Information
Refer to your local • Avoid prolonged exposure of the appliance to Electrolux Service Force Centre and always insist direct sunlight. on genuine spare parts. • Do not use other electrical appliances (such as... -
Page 3: Fastening To The Wall
Fastening to the wall Warning! 15 cm 15 cm 1,5 cm The appliance must be fastened to the wall for safety reasons. Take the bag supplied with the appliance. It contains the following accessories: 2 brackets 4 wall plugs (for fixing to masonry wall) D742 4 wall plugs (for fixing to dry lined walls) 4 screws... -
Page 4: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Important Safety Information Technical Specification Fastening to the wall Installation Operation Positioning Before use Shelf holders Control panel Starting your appliance Electrical Connection Temperature control Rear Spacers Freezing fresh food Door Reversal Frozen food storage Thawing Making ice cubes... -
Page 5: Operation
OPERATION Before use Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Control panel ALARM SUPER B C D... -
Page 6: Frozen Food Storage
However, if the appliance is working in unfavourable Frozen food storage room conditions such as When you first start the freezer or if the freezer has poor ventilation, been out of use for some time, we advise you to run high temperature, your appliance for at least 12 hours in the «fast frequent door openings,... -
Page 7: Thawing
Thawing Fresh food refrigeration Frozen food, prior to being used, can be thawed in To obtain the best performance, do not store warm the fridge or at room temperature depending on the food or evaporating liquids in the refrigerator; do time available. -
Page 8: Movable Shelves
Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. D338 Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height. To do this proceed as shown in the diagram. PR249 Use of the adjustable temperature compartment... -
Page 9: Hints And Tips
HINTS AND TIPS Energy Saving Advice Normal Operating Sounds • You may hear faint gurgling or bubbling sounds • Do not install the appliance close to sources of when the refrigerant is pumped through the coils heat, such as a boiler or radiator. or tubing at the rear, to the cooling plate/evaporator. -
Page 10: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried Changing the light bulb out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. -
Page 11: Defrosting
Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates. Important To avoid defrost water overflowing into the fridge, periodically clean the water discharge hole in the centre of the V shaped drip collector at the back of the refrigerator compartment behind the salad... -
Page 12: Something Not Working
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom Solution No power to the appliance... -
Page 13: Service And Spare Parts
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 14: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 15: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS Height Width Depth POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 200 W AVERAGE DAILY UNITS ELECTRICITY * 0.959 kWh GROSS CAPACITY Fridge 184 l Cellar zone 88 l Freezer 88 l NET CAPACITY Fridge 180 l... -
Page 16: Installation
INSTALLATION Important Depending upon the position which you choose for IF YOU ARE DISCARDING AN OLD APPLIANCE your appliance, you may wish to reverse the way in THAT HAS A LOCK OR CATCH ON THE DOOR, which the door opens. To do this, refer to instructions YOU MUST ENSURE THAT IT IS MADE on “Door reversal”. -
Page 17: Electrical Connection
WARNING: THIS APPLIANCE MUST BE A replacement cover/carrier must be obtained from EARTHED. your local Electrolux Service Force Centre. The manufacturer declines any liability should This appliance complies with the E.E.C. Directive this safety measure not be observed. -
Page 18: Rear Spacers
Rear spacers In the bag with the documentation, there are two spacers which must be fitted as shown in the figure. Slacken the screws and insert the spacer under the screw head, then re-tighten the screws. Door reversal directions Before reversing the door make sure that the D594 following tools are available: 1 cross-slotted screwdriver... - Page 19 17.Remove the three caps (N) inserted in the late for the hinge screws and mount them on the opposite side; 18.Remove the washer (P) from the upper middle hinge, remove the pin and mount it on the other side by fitting the washer on the pin and positioning the whole group on the other side;...
- Page 20 © Electrolux plc 2003...
