Chapter Two Introduction of remote and basic operation

Chapter Two Introduction of remote and basic operation
2.1

Diagram of the remote

Please make sure the remote is directed to the infrared
receiving window. The obstacles may affect the receiving
of signal & make remote fail to work normally.
12
1
13
2 14
3
15
4
5
16
6
17
7
8
9 18
10
11
19
2.2

Functions of buttons

1." " : A button to turn on/off the system.
If the system is set to power on automatically with
the ignition, the system will power on automa tically.
After powering on, press "On/Off" button to turn off
the system.
2. Search: A button to search for TV stations.
3. Menu: A button to enter OSD interference of DVD
or TV etc.
4. "¡ø " : A button to move cursor upwards or turn
volume down.
5. " ": A button to move cursor leftwards or shift to
the former TV channel.
6. "ENT": A button to confirm to enter.
7. " ": A button to return to former function
interference or former TV channel.
8. "¨‹ : A button to move cursor downloads or turn "
volume down.
9. " ": A button to confirm to play.
10. Arab number buttons
11. "Mute": A button to mute the speaker.
12. "Navi": A button to activate the function of GPS
navigation.
13. "TFT": A button to turn off the backlight of panel.
14. "OSD": A button to enter "OSD" interference.
Please note: The button can not work , while car is
running.
15. "Setup": A button to enter the interference of
setup.
16. " ": A button to move cursor rightwards or next
TV channel.
17. " ": Abutton to get title or message.
18. "ESC": A button to exit from the current function.
19. " ": A button to adjust the brightness of display
Attentions about the remote control
DTV is optional. It will not work if there is no TV
Tuner.
"Navi" on the remote will let the system shift to
"Navigation"function.

2.3 Basic operation

Turn on/off the system
The system will turn on automatically with ignition.
Then the system will enter the interference of main
menu within 15 seconds.
Function shifts
The system will forbid doing any function shifts,
unless the car stops & its hand brake works for brake .
But please notice the following items.
The system can not play movie and music at the
same time.
The system can run movie or music with "setup"
function at the same time.
The system can run movie or music with "nav igation"
function at the same time.
The system can run TV playing or navigation at the
same time. (Please note: TV is optional function).
