LG 563LE Owner's Manual

Hide thumbs Also See for 563LE:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Introduction
The 563LE Flat Panel Monitor has an active matrix TFT (Thin-Film
Transistor) LCD (Liquid Crystal Display).
This monitor is designed for use in small working areas or for those who need
more working space on the desk.
Features
The 563LE is a 15.0-inch (15.0 inches viewable) intelligent micropro-cessor
based monitor.
Digitally controlled auto-scanning is done with the microprocessor for horizontal
scan frequencies between 31 and 61kHz, and vertical scan frequencies
between 56 and 75Hz.
The microprocessor-based digital controls allow you to adjust conveniently a
variety of image controls by using the OSD (On Screen Display).
The monitor is shipped with 14 factory pre-programmed video modes that are
permanently resident. In addition, there are 16 user-storable modes, for a total
of 30 memory modes.
Plug and play capability if supported by your system.
This monitor has DDC 2B function.*
Compliant with the following regulated specifications :*
- EPA E
S
NERGY
TAR
- Swedish TCO'99
*
For detailed information, please refer to the Reference Guide provided .
A1

Advertisement

Table of Contents
loading

Related Manuals for LG 563LE

Summary of Contents for LG 563LE

  • Page 1 Introduction The 563LE Flat Panel Monitor has an active matrix TFT (Thin-Film Transistor) LCD (Liquid Crystal Display). This monitor is designed for use in small working areas or for those who need more working space on the desk. Features The 563LE is a 15.0-inch (15.0 inches viewable) intelligent micropro-cessor based monitor.

  • Page 2: Connecting The Monitor

    Connecting the Monitor On the back of the monitor are two plug-in connections; one for the AC power cord, and the other for the signal cable from the video card. Power off both the monitor and PC. Connect the 15 pin VGA connector of the supplied signal cable to the output VGA video connector on the PC and the matching input connector on the rear of the monitor.

  • Page 3: Location And Function Of Controls

    Location and Function of Controls Front View Power Indicator Power Button • • • • • • OSD Button AUTO/SET Button Buttons VESA wall mounting Rear View Connected to another object (stand type and wall-mounted type - optional) ID Label •...

  • Page 4: Control Panel Function

    Control Panel Function Front Panel Controls Buttons Power Button OSD Button AUTO/SET AUTO/SET Button Power (DPMS) Indicator Control Function Use this button to enter and from the on OSD Button screen display (OSD). Use these buttons to choose or adjust items in Buttons the on screen display.

  • Page 5: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Making adjustments to the image size, position and operating parameters of the monitor are quick and easy with the On Screen Display Control system. A quick example is given below to familiarize you with the use of the controls. Following section is an outline of the available adjustments and selections you can make using the OSD.

  • Page 6: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selection and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the items that are shown on the Menu. OSD Adjust Description Brightness...
  • Page 7 On Screen Display(OSD) Selection and Adjustment OSD Adjust Description CLOCK To minimize any vertical bars or TRACKING stripes visible on the screen background.The horizontal screen CLOCK size will also change. PHASE To adjust the focus of the display. PHASE This item allows you to remove any horizontal noise and clear or sharpen the image of characters.

  • Page 8: Video Memory Modes

    Video Memory Modes The monitor has 30 memory locations for display modes, 14 of which are factory preset to popular video modes. Display Modes (Resolution) Display Modes (Resolution) Horizontal Freq.(kHz) Vertical Freq.(Hz) 31.47 640 x 350 31.47 720 x 400 31.47 640 x 480 35.00...

  • Page 9: Troubleshooting

    Troubleshooting Check the following before calling for service. Display Position is incorrect. Push the AUTO/SET Button. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. On the screen background, vertical bars or stripes are visible. Push the AUTO/SET Button.

  • Page 10: Specifications

    Specifications Display Type 15.0inch (38.1cm) Flat Panel Active matrix-TFT LCD, Anti-Glare coating Viewable Size 15.0inch (38.1cm) Pixel pitch 0.3 x 0.3mm Horizontal Freq. 31 - 61kHz (Automatic) Sync Input Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative Signal Input 15 pin D-Sub Connector Display Area...
