FILE NO. 810-200527
SERVICE MANUAL
DVD VIDEO PLAYER & VIDEO
CASSETTE RECORDER
SD-V330SC
DOCUMENT CREATED IN JAPAN, Mar., 2005

Advertisement

Table of Contents
loading

Related Manuals for Toshiba SD-V330SC

Summary of Contents for Toshiba SD-V330SC

  • Page 1 FILE NO. 810-200527 SERVICE MANUAL DVD VIDEO PLAYER & VIDEO CASSETTE RECORDER SD-V330SC DOCUMENT CREATED IN JAPAN, Mar., 2005...

  • Page 2: Safety Precautions

    Toshiba of Canada Limited 191 McNabb Street Markham, Ontario L3R 8H2 ColorStream and ColorStream Pro are registered trademarks of Toshiba America Consumer Products, L.L.C. ©2005 Toshiba Corporation This device does not tape-record copy protected DVD Video Discs.

  • Page 3: Power Source

    Introduction IMPORTANT SAFEGUARDS IMPORTANT SAFEGUARDS / Power source 13. LIGHTNING 19. REPLACEMENT PARTS To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time, When replacement parts are required, be sure the service technician uses replacement parts specified by unplug it from the wall outlet and disconnect the antenna or cable system.

  • Page 4: Table Of Contents

    DVD bearing the DVD logo and/or every Video CD bearing the CD logo. As one of the creators of DVD technology, Toshiba DVD players are manufactured using the highest standards of quality, and as a result, such incompatibilities are rare.

  • Page 5: Identification Of Controls

    Introduction Identification of Controls (continued) The instructions in this manual describe the functions on the remote control. See the page in for details. Remote control Inserting batteries Open the battery compart- Install two “AAA” batteries (sup- Replace the compartment plied), paying attention to the ment cover in the direction of cover.

  • Page 6: Cable Tv Connections

    Connections Cable TV connections Many cable companies offer services permitting reception of extra channels including pay or subscription channels. This IMPORTANT: Make sure the TV/CABLE menu option is set to the “CABLE” mode. This DVD/VCR cannot receive scrambled programs since it does not contain a descrambler. In order to receive scram- DVD/VCR has an extended tuning range and can be tuned to most cable channels without using a cable company bled programs, your existing descrambler must be used.

  • Page 7: Connecting To Optional Equipment

    Connections Warning When playing DTS-encoded discs (audio CDs), excessive noise may be output from the analog stereo jacks. To avoid Connecting to optional equipment possible damage to the audio system, you should take proper precautions when the ANALOG AUDIO OUT (L/R) jacks of the DVD/VCR are connected to an amplification system.

  • Page 8: Clock Setting

    Basic setup (VCR) POWER Clock setting VCR DVD VCR MENU The AUTO CLOCK function will automatically set the built-in clock (Month, Day, Year and Time) when the DVD/VCR is connected to an Antenna or Cable system and it is turned off. The DVD/VCR searches ENTER for a station in your area containing the necessary AUTO CLOCK setting To set STANDARD TIME...

  • Page 9: Playback (Vcr)

    Basic setup (VCR) Playback (VCR) Tuner setting (continued) Loading and unloading a cassette tape VCR MENU EJECT Use only video cassette tapes marked ENTER SET +/– Loading 0–9 Push the center of the tape until it is automatically Insert the cassette tape with its labeled side facing up and the erase prevention tab positioned at your left.

  • Page 10: Convenience Function

    Playback (VCR) CLOCK/COUNTER Convenience function VCR DVD VCR MENU CLOCK/COUNTER SET +/– ENTER STOP PLAY STOP CALL INDEX – ZERO RETURN COUNTER RESET Repeat playback Zero return function Clock/counter display Video index search system The entire video tape will play until its end. The tape will This function rewinds the tape to the “00:00:00”...

  • Page 11: Timer Recording

    Recording (VCR) VCR DVD One-touch Timer Recording (OTR) Timer recording VCR DVD EJECT VCR MENU CH +/– The One-touch Timer Recording feature provides a simple and Timer recording can be programmed on-screen with the remote control. SET +/– convenient way to make a timed recording. The built-in timer allows automatic unattended recording of up to 8 ENTER programs within 1 month.

  • Page 12: Duplicating A Video Tape

    Other functions (VCR) Duplicating a video tape Recording a DVD/CD disc VCR DVD VCR DVD INPUT SELECT If you connect the DVD/VCR to another VCR or Camcorder, you can duplicate You can record disc material in DVD, Audio CD, etc. onto a Video a previously recorded tape.

  • Page 13: Advanced Playback (Dvd)

    Basic playback (DVD) Advanced playback (DVD) Playing a disc (continued) Zooming/Locating desired scene ZOOM You can play discs at various speeds. SLOW C/D/B/A ENTER CLEAR PAUSE/STEP PLAY DISPLAY 0–9 SEARCH SKIP Playing in fast reverse or fast forward directions Zooming To resume normal playback This unit will allow you to zoom in on the frame image.

  • Page 14: Program Playback

    Advanced playback (DVD) Program playback/Random playback Changing angles/Title selection/DVD menu TOP MENU MENU C/D/B/A You can arrange the playback order of tracks or files on the disc. And C/D/B/A ENTER also the unit selects tracks or files at random and playback them. ENTER These feature works for Audio CD, Video CD and MP3/WMA/JPEG CLEAR...

  • Page 15: Mp3/Wma/Jpeg Operation

    Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats 0–9 (including CD-R containing MP3/WMA files). Given the fact that technology in this area is still maturing, Toshiba cannot guarantee that all genre of recordable discs will produce optimal playback quality. The technical criteria set out in this owner’s manual are meant as a guide only.

  • Page 16: Setting Details

    Function setup (DVD) Customizing the function settings (continued) Setting details Section Option Details Page Menu English Menu To select the language of “Menu”, “Subtitle” and E.B.L Subtitle English Tv Screen Audio English Subtitle “Audio” if more than one language are available on Display Picture Mode Auto...

  • Page 17: Temporary Disabling Of Rating Level By Dvd Disc

    Function setup (DVD) Other Language code list OPEN/CLOSE Temporary disabling of rating level by DVD disc Enter the appropriate code number for the initial settings “Menu”, “Subtitle” and/or “Audio” Depending on the DVD disc, the disc may try to temporarily cancel the rating level that you have set.
  • Page 18 CAUTION THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM. TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE- FULLY AND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE, CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE. USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

  • Page 19: Important Service Safety Information

    IMPORTANT SERVICE SAFETY INFORMATION Safety precautions to be followed during servicing: Parts marked with an are critical parts for safety. Replace only with the one described in the parts list. Before returning the DVD product to the customer, make the appropriate leakage current check or resistance measurements to ensure that exposed parts are properly insulated from the supply circuit.
  • Page 20 IMPORTANT SAFEGUARDS READ INSTRUCTIONS All the safety and operating instructions should be read before the unit is operated. RETAIN INSTRUCTIONS The safety and operating instructions should be retained for future reference. HEED WARNINGS All warnings on the unit and in the operating instructions should be adhered to. FOLLOW INSTRUCTIONS All operating and use instructions should be followed.
  • Page 21 IMPORTANT SAFEGUARDS (CONTINUED) OUTDOOR ANTENNA GROUNDING If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
  • Page 22 IMPORTANT SAFEGUARDS (CONTINUED) EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE GROUND CLAMP ANTENNA DISCHARGE UNIT (NEC SECTION 810-20) ELECTRIC SERVICE EQUIPMENT GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING NEC-NATIONAL ELECTRICAL CODE ELECTRODE SYSTEM (NEC ART 250, PART H) S2898A...

  • Page 23: When Replacing Dvd Deck

    WHEN REPLACING DVD DECK [ When removing the DVD Deck ] Before removing Pick Up PCB and DVD PCB connector, short circuit the position shown in Fig. 1 using a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged. [ When installing the DVD Deck ] Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD PCB connector.

  • Page 24: Tape Removal Method At No Power Supply

    TAPE REMOVAL METHOD AT NO POWER SUPPLY Remove the Top Cabinet, Front Cabinet and DVD Block. (Refer to item 1 of the DISASSEMBLY INSTRUCTIONS.) Remove the screw 1 of the Deck Chassis and remove the Loading Motor. (Refer to Fig. 2) Rotate the Pinch Roller Cam in the direction of the arrow by hand to slacken the Video Tape.

  • Page 25: Tray Lock

    PARENTAL CONTROL - RATING LEVEL 4 DIGIT PASSWORD CANCELLATION If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps below. Turn Unit ON. Press and hold the '7' key on the remote control unit. Simultaneously press and hold the 'STOP' key on the front panel.
  • Page 26 TABLE OF CONTENTS • OWNER'S MANUAL CAUTION ............................ A1-1 PREPARATION OF SERVICING ....................A1-1 IMPORTANT SERVICE SAFETY INFORMATION ..............A1-2 IMPORTANT SAFEGUARDS ..................... A1-3~A1-5 WHEN REPLACING DVD DECK ....................A1-6 TAPE REMOVAL METHOD AT NO POWER SUPPLY ............A1-7 DISC REMOVAL METHOD AT NO POWER SUPPLY ............. A1-7 PARENTAL CONTROL-RATING LEVEL ..................
  • Page 27 GENERAL SPECIFICATIONS Outline of the product DVD VIDEO PLAYER & VHS Player / Recorder DVD System Color System NTSC DVD, CD-DA, CD-R/RW, VIDEO CD, Disc SVCD, DVD-R/RW (VIDEO FORMAT ONLY) Disc Diameter 120 mm , 80 mm Drive DM3PA Search speed 4 steps Actual 2-120 times (DVD)
  • Page 28 GENERAL SPECIFICATIONS Regulation Safety UL/CSA Radiation FCC/IC Laser DHHS Temperature Operation 5oC - 40oC Storage -20oC - 60oC Operating Humidity Less than 80% RH Signal Video Signal Output Level 1 V p-p/75 ohm (DVD,VCR) S/N Ratio (Weighted) 65 dB(DVD) 50 dB(VCR) Horizontal Resolution 500 Lines (DVD) 230 Lines(VCR Mode)
  • Page 29 GENERAL SPECIFICATIONS G-10 On Screen Menu Display (DVD) Menu Type Icon Language Menu Subtitle Audio OSD Language (Set up Language) Video E.B.L. (Enhanced Black Level) TV Screen Size OSD Display On/Off Picture Mode(Video/File/Auto) JPEG Interval Audio DRC (Dynamic Range Control) Dialogue On:DRC(TV)/ Off:DRC(Std) dts Decode Surround (Qsound)
  • Page 30 GENERAL SPECIFICATIONS On Screen Menu Display(VCR) Menu Type Character Timer Rec Set Auto Repeat On/Off SAP On/Off CH Set-Up TV/CABLE Auto CH Memory Add/Delete System Set Up Clock Set Yes (Calendar 12H) Language No Noise Back Ground Auto Clock Standard Time Daylight Saving Time G-CODE(or SHOWVIEW or PLUSCODE)No.
  • Page 31 GENERAL SPECIFICATIONS G-14 Remote Unit RC-KU Control Glow in Dark Remocon Remocon Format TOSHIBA Format TOSHIBA Custom Code 45-BA Power Source Voltage(D.C) UM size x pcs UM-4 x 2 pcs Total Keys 46 Key Keys Power DISPLAY/CALL Input Select Input Select / PROGRESSIVE...

  • Page 32: 75 Ohm Coaxial Cable

    GENERAL SPECIFICATIONS G-15 Features Auto Power Off (DVD) Video CD Playback SVCD Playback Overlay Graphics And Text Command List Entry Point Jump MP3 Playback WMA Playback JPEG Playback Progressive Scan Out Digital Out Dolby Digital MPEG Down Mix Out (Dolby Digital) (DTS) Qsound Surround...
  • Page 33 Drop Test Surfaces Height (cm) 80 cm Container Stuffing 2,015 Sets/40' container G-21 Material Cabinet Front PS 94V2 or More / DECABROM Non-Halogen Demand Eyelet Demand G-22 Environment Environmental standard requirement (by buyer) Green procurement of TOSHIBA Pb-free Phase3(Phase3A) A3-7...

  • Page 34: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS 1-3: DVD DECK/DVD PCB (Refer to Fig. 1-3) 1. REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS Short circuit the position shown in Fig. 1-3 using a soldering iron. If you remove the DVD Deck with no 1-1: TOP CABINET, FRONT CABINET, OPERATION 1/2 soldering, the Laser may be damaged.
  • Page 35 DISASSEMBLY INSTRUCTIONS 1-4: VCR DECK (Refer to Fig. 1-4) 1-5: VCR PCB (Refer to Fig. 1-5) Remove the screw 1. NOTE Remove the 5 screws 2. Do not remove the cable at the FE Head section. The FE Remove the 2 screws 3. Head may be damaged if you remove the cable by force.

  • Page 36: Removal Of Vcr Deck Parts

    DISASSEMBLY INSTRUCTIONS 2-3: LINK UNIT (Refer to Fig. 2-3) 2. REMOVAL OF VCR DECK PARTS Set the Link Unit to the Eject position. 2-1: TOP BRACKET (Refer to Fig. 2-1) Unlock the support 1. Extend the 2 supports 1. Remove the (A) side of the Link Unit first, then remove Slide the 2 supports 2 and remove the Top Bracket.
  • Page 37 DISASSEMBLY INSTRUCTIONS 2-5: LOADING MOTOR/WORM (Refer to Fig. 2-5-A) 2-6: TENSION ASS’Y (Refer to Fig. 2-6-B) Remove the screw 1. Turn the Pinch Roller Cam clockwise so that the Tension Remove the Loading Motor. Holder hook is set to the position of Fig. 2-6-A to move Remove the Worm.
  • Page 38 DISASSEMBLY INSTRUCTIONS NOTE [OK] Tension Connect Take care not to damage the gears of the S Reel and T Reel. Tension Band The Polyslider Washer may on the back of the reel. Take care not to damage the shaft. [NG] Tension Connect Tension Band Do not touch section “A”...
  • Page 39 DISASSEMBLY INSTRUCTIONS 2-9: CASSETTE OPENER/PINCH ROLLER BLOCK/P5 ARM ASS’Y (Refer to Fig. 2-9-A) Unlock the support 1 and remove the Cassette Opener. Remove the Pinch Roller Block and P5 Arm Ass’y. Cassette Opener Spring Position Fig. 2-10-B Pinch Roller Block 2-11: FE HEAD (RECORDER ONLY) (Refer to Fig.
  • Page 40 DISASSEMBLY INSTRUCTIONS 2-13: CAPSTAN DD UNIT (Refer to Fig. 2-13-A) 2-14: MAIN CAM/PINCH ROLLER CAM/JOINT GEAR (Refer to Fig. 2-14-A) Remove the Capstan Belt. Remove the 3 screws 1. Remove the E-Ring 1, then remove the Main Cam. Remove the E-Ring 2, then remove the Pinch Roller Remove the Capstan DD Unit.
  • Page 41 DISASSEMBLY INSTRUCTIONS NOTE 2-17: CASSETTE GUIDE POST/INCLINED BASE S/T UNIT/P4 CAP/LED REFLECTOR 1. When you install the Loading Arm S Unit, Loading Arm T (Refer to Fig. 2-17-A) Unit and Main Loading Gear, align each marker. (Refer to Fig. 2-15-B) Remove the P4 Cap.

  • Page 42: Removal Of Dvd Deck Parts

    DISASSEMBLY INSTRUCTIONS 3. REMOVAL OF DVD DECK PARTS 3-2: MAIN CHASSIS ASS'Y (Refer to Fig. 3-2-A) Remove the screw 1. NOTE Unlock the 2 supports 2. 1. Disassemble only the DVD DECK PARTS parts listed Remove the Insulator (R) from the Main Frame Ass'y. here.
  • Page 43 DISASSEMBLY INSTRUCTIONS 3-3: LOADING MOTOR PCB ASS'Y/ LOADING BELT 3-4: RACK LOADING/MAIN GEAR/PULLEY GEAR (Refer to Fig. 3-3-A) (Refer to Fig. 3-4-A) Press down the catcher 1 and slide the Rack Loading. Remove the Loading Belt. Remove the screw 1. Unlock the support 2 and remove the Pulley Gear.
  • Page 44 DISASSEMBLY INSTRUCTIONS NOTE 3-7: SWITCH PCB ASS'Y/MIDDLE GEAR/FEED MOTOR (Refer to Fig. 3-7-A) 1. In case of the Clamper Ass'y installation, install correctly Remove the screw 1. as Fig. 3-5-B. Remove the Switch PCB Ass'y. Unlock the support 2. Remove the Middle Gear. Remove the 2 screws 3.
  • Page 45 DISASSEMBLY INSTRUCTIONS [ 6 pin FFC ] Main Chassis Ass'y (Bottom Side) Reinforcement Plate Check Hook Reinforcement Plate Check Hook Check Hook 53 ± 1mm 10 ± 1mm Printing Surface Printing Surface Fold Fold Reinforcement Plate Fold 10 ± 1mm Check Hook Fold Printing Surface...

  • Page 46: Removal And Installation Of Flat Package Ic

    DISASSEMBLY INSTRUCTIONS 3. When IC starts moving back and forth easily after 4. REMOVAL AND INSTALLATION OF FLAT desoldering completely, pickup the corner of the IC using PACKAGE IC a tweezers and remove the IC by moving with the IC REMOVAL desoldering machine.
  • Page 47 DISASSEMBLY INSTRUCTIONS INSTALLATION 4. When bridge-soldering between terminals and/or the soldering amount are not enough, resolder using a Thin- 1. Take care of the polarity of new IC and then install the tip Soldering Iron. (Refer to Fig. 4-8.) new IC fitting on the printed circuit pattern. Then solder each lead on the diagonal positions of IC temporarily.

  • Page 48: Key To Abbreviations

    KEY TO ABBREVIATIONS Audio/Control H.P.F High Pass Filter Automatic Color Control H.SW Head Switch Audio Erase Hertz Automatic Frequency Control Integrated Circuit Automatic Fine Tuning Intermediate Frequency AFT DET Automatic Fine Tuning Detect Indicator Automatic Gain Control Inverter Amplifier Killer Antenna Left A.PB...
  • Page 49 KEY TO ABBREVIATIONS Serial Strobe Switch SYNC Synchronization SYNC SEP Sync Separator, Separation Transistor TRAC Tracking TRICK PB Trick Playback Test Point UNREG Unregulated Volt Voltage Controlled Oscillator Video Intermediate Frequency Vertical Pulse, Voltage Display V.PB Video Playback Variable Resistor V.REC Video Recording Visual Search Fast Forward...

  • Page 50: Service Mode List

    SERVICE MODE LIST This unit is rovided with the following SERVICE MODES so you can repair, examine and adjust easily. To enter to the SERVICE MODE function, press and hold both buttons simultaneously on the main unit or on the main unit and on the remote control for more than the standard time in the appropriate condition.

  • Page 51: Preventive Checks And Service Intervals

    PREVENTIVE CHECKS AND SERVICE INTERVALS The following standard table depends on environmental conditions and usage. Parts replacing time does not mean the life span for individual parts. Also, long term storage or misuse may cause transformation and aging of rubber parts. The following list means standard hours, so the checking hours depends on the conditions.
  • Page 52 PREVENTIVE CHECKS AND SERVICE INTERVALS CLEANING NOTE 2. TAPE RUNNING SYSTEM After cleaning the heads with isopropyl alcohol, do not When cleaning the tape transport system, use the run a tape until the heads dry completely. If the heads gauze moistened with isopropyl alcohol. are not completely dry and alcohol gets on the tape, 3.

  • Page 53: Re-Write For Dvd Firmware

    RE-WRITE FOR DVD FIRMWARE Turn on the power, and set the DVD mode. Confirm that the “No Disc” will be appeared on the screen. Open the DVD tray. Press both Channel button (6) on the remote control and the REC button on the set for more than 2 seconds. Press OPEN/CLOSE button on the unit to check if all the keys on the unit do not function.

  • Page 54: When Replacing Eeprom (Memory) Ic

    WHEN REPLACING EEPROM (MEMORY) IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. NOTE: INI 45 and INI 46 cannot be set. Because, the total time for the PLAY/REC of the main unit is recorded. INIT +0 CC AB Table 1...

  • Page 55: Rf Signal Check Of Dvd Pcb

    RF SIGNAL CHECK OF DVD PCB RF signal check can be done at the following A~D resistance points on the DVD PCB. DVD PCB (BOTTOM SIDE) R2359 R2356 Q2305 Q2303 Q2304 R2329 R2323 R2309 D4004 D4002 W836 R4016 R4042 DME031A D4003 R4036 W811...

  • Page 56: Power Button

    SERVICING FIXTURES AND TOOLS Alignment Tape Back tension cassette gauge Torque cassette gauge Taper nut driver (KT-300NR) ST-N5 ST-NF 70909103 70909199 70909228 VTR cleaning kit VTR lubrication kit Grease JG002B Adapter JG002E Dial Torque Gauge (10~90gf•cm) JG002F (60~600gf•cm) JG022 Master Plane JG024A Reel Disk Height JG153 X Value Adjustment JG154 Cable...

  • Page 57: Mechanical Adjustments

    MECHANICAL ADJUSTMENTS 1-2: CONFIRMATION AND ADJUSTMENT OF TENSION 1. CONFIRMATION AND ADJUSTMENT POST POSITION Read the following NOTES before starting work. Set to the PLAY mode. • Place an object which weighs between 450g~500g on the Adjust the adjusting section for the Tension Arm position Cassette Tape to keep it steady when you want to make so that the Tension Arm top is within the standard line of the tape run without the Cassette Holder.
  • Page 58 MECHANICAL ADJUSTMENTS 1-4: CONFIRMATION OF VSR TORQUE NOTE Install the Torque Gauge (JG002F) and Adapter (JG002B) If the torque is out of the range, replace the following parts. on the S Reel. Set to the Picture Search (Rewind) mode. Check item Replacement Part (Refer to Fig.1-4-B) Then, confirm that it indicates 120~180gf•cm.
  • Page 59 MECHANICAL ADJUSTMENTS 2-2: CONFIRMATION AND ADJUSTMENT OF AUDIO/ 2-3: TAPE RUNNING ADJUSTMENT CONTROL HEAD (X VALUE ADJUSTMENT) When the Tape Running Mechanism does not work well, Confirm and adjust the height of the Reel Disk. adjust the following items. (Refer to item 1-1) Confirm and adjust the position of the Tension Post.
  • Page 60 MECHANICAL ADJUSTMENTS 3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE 1. Tension Connect P4 Post 2. Tension Arm T Brake Spring 3. Guide Roller T Reel 4. Audio/Control Head S Reel 5. X value adjustment driver hole Adjusting section for the Tension Arm position D2-4...

  • Page 61: Electrical Adjustments

    ELECTRICAL ADJUSTMENTS Read and perform this adjustment when repairing the circuits or replacing electrical parts or PCB assemblies. 1. BASIC ADJUSTMENT CAUTION When you exchange IC and Transistor with a heat sink, apply silicon grease on the contact section of the heat sink.
  • Page 62 ELECTRICAL ADJUSTMENTS 2. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE (WIRING CONNECTION) VCR PCB CP102 CD501 S502 AC IN S501 CP3001 CP8001 CP103 FE HEAD AC HEAD TP101 TP701 TP3002 CP501 TP3001 CP651 OS651 V651 OPERATION 2 PCB CP681 CD681 OPERATION 1 PCB CD501 CP601 DVD DECK...

  • Page 63: Troubleshooting Guide

    TROUBLESHOOTING GUIDE...
  • Page 64 TROUBLESHOOTING GUIDE...
  • Page 65 TROUBLESHOOTING GUIDE...
  • Page 66 TROUBLESHOOTING GUIDE...
  • Page 67 TROUBLESHOOTING GUIDE...
  • Page 68 TROUBLESHOOTING GUIDE WHEN INSERTING A CASSETTE, IT EJECTS IMMEDIATELY Defective CASSETTE Does another CASSETTE or cassette loading block. insert? Does SW3001 and Correct SW3001 REC LEVER and REC LEVER set. correctly set ? After inserting CASSETTE, is pin 35 Check SW3001. of IC3001 0V ? Check IC3001.
  • Page 69 TROUBLESHOOTING GUIDE...
  • Page 70 TROUBLESHOOTING GUIDE...
  • Page 71 TROUBLESHOOTING GUIDE...
  • Page 72 TROUBLESHOOTING GUIDE AUTO TRACKING DOES NOT OPERATE E-10...
  • Page 73 TROUBLESHOOTING GUIDE E-11...
  • Page 74 TROUBLESHOOTING GUIDE E-12...
  • Page 75 TROUBLESHOOTING GUIDE E-13...
  • Page 76 TROUBLESHOOTING GUIDE E-14...
  • Page 77 TROUBLESHOOTING GUIDE E-15...
  • Page 78 TROUBLESHOOTING GUIDE E-16...
  • Page 79 TROUBLESHOOTING GUIDE E-17...
  • Page 80 TROUBLESHOOTING GUIDE E-18...
  • Page 81 TROUBLESHOOTING GUIDE E-19...
  • Page 82 TROUBLESHOOTING GUIDE E-20...
  • Page 83 TROUBLESHOOTING GUIDE E-21...
  • Page 84 TROUBLESHOOTING GUIDE E-22...
  • Page 85 TROUBLESHOOTING GUIDE E-23...
  • Page 86 TROUBLESHOOTING GUIDE E-24...
  • Page 87 TROUBLESHOOTING GUIDE E-25...
  • Page 88 TROUBLESHOOTING GUIDE E-26...
  • Page 89 TROUBLESHOOTING GUIDE E-27...
  • Page 90 TROUBLESHOOTING GUIDE E-28...
  • Page 91 TROUBLESHOOTING GUIDE E-29...
  • Page 92 TROUBLESHOOTING GUIDE NO PLAYBACK PICTURE OF AV JACK Check loader block. E-30...
  • Page 93 TROUBLESHOOTING GUIDE E-31...
  • Page 94 TROUBLESHOOTING GUIDE E-32...
  • Page 95 TROUBLESHOOTING GUIDE E-33...

  • Page 96: Dvd

    MECHANICAL EXPLODED VIEW PCB130 (DVD PCB ASS'Y) PCB270 (OPERATION 1 PCB ASS'Y) 101D 101I 101K 101A 101N PCB010 101F (VCR PCB ASS'Y) 101G 101C 101J 101L 101H 101E 101M 101E PCB280 101B 101L (OPERATION 2 PCB ASS'Y) J1-1...

  • Page 97: Packing Diagram

    MECHANICAL EXPLODED VIEW (PACKING DIAGRAM) 120, 126, 127, 128 CD6002, CD6003, TM601 J1-2...

  • Page 98: Chassis Exploded View

    CHASSIS EXPLODED VIEW (TOP VIEW) CD1501 M2003 UN4001 H5002 H5001 CD1502 M101 NOTE: Applying positions AA for the grease are displayed for this section. CLASS MARK Check if the correct grease is applied for each position. GREASE J2-1...
  • Page 99 CHASSIS EXPLODED VIEW (BOTTOM VIEW) M2001 CD1501 CD1502 NOTE: Applying positions AA for the grease are displayed for this section. CLASS MARK Check if the correct grease is applied for each position. GREASE J2-2...

  • Page 100: Dvd Deck Exploded View

    DVD DECK EXPLODED VIEW Cannot supply separately. If the repair is needed, replace the LOADER SUB ASS'Y. M2603 PCB610 CD2301 (LOADING MOTOR PCB ASS'Y) CD2302 PCB640 CD2001 (SW PCB ASS'Y) Do not replace the parts. Because, minute adjustments are needed if this condition is disassembled further more.

  • Page 101: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description AE007213 7A7010115A FRONT CABI ASS'Y 101A AE007214 701WPA1383 CABINET,FRONT 101B AE006720 711WPD0678 PLATE,DISPLAY 101C AE006721 712WPJ0904 FLAP,DVD 101D AE007195 712WPJ0926 FLAP,VCR 101E AE001167 7230007689 SHEET,LED 101F AE001847 7235490018 BADGE,BRAND 101G AE006722 736WPB0005...

  • Page 102: Chassis Replacement Parts List

    CHASSIS REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description AE007243 A2H201H420K DECK ASSY A2H201H420K AE005514 85OA400245 PINCH ROLLER BLOCK VA2 AE006679 85OP900759 LEVER,FLAP(S) BZ710193 85OP200290 BELT,CAPSTAN (S) BZ710515 85OP600581 WORM BZ710094 85OP500083 BASE,AC HEAD BZ710112 85OP800324 SPRING,AC HEAD AE006676 85OA000529 MAIN CHASSIS ASS'Y(S)

  • Page 103: Dvd Deck Replacement Parts List

    DVD DECK REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description AE006521 A2F401H650 DVD MECHA ASS'Y A2F401H650 AE005003 92P100109A HOLDER,TRAVERSE AE003550 92P100094A CLAMPER AE003551 92P100088A GEAR,MOTOR AE005414 92P100108A GEAR,MIDDLE AE003538 92P200013A INSULATOR(F) AE003539 92P200014A INSULATOR(R) AE006115 92SBB0029A LOADER SUB ASS'Y AE003541 92P100095A GEAR,PULLEY...

  • Page 104: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS R101 AE001790 R803R9222J 2.2K OHM 1/16W R102 AE003983 R002T42R2J 2.2 OHM 1/4W R103 AE001784 R803R9103J 10K OHM 1/16W R104 AE001890 R803R9221J 220 OHM 1/16W R105 AD302345 R803R9472J 4.7K OHM 1/16W R106 AD302345 R803R9472J...
  • Page 105 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS R606 AE001555 R002T4563J 56K OHM 1/4W R607 BZ210135 R002T4221J 220 OHM 1/4W R651 AD301203 R002T4101J 100 OHM 1/4W R661 AE002154 R803R9821J 820 OHM 1/16W R662 AE003232 R803R9181J 180 OHM 1/16W R663 AE003232 R803R9181J...
  • Page 106 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS R2327 AD302345 R803R9472J 4.7K OHM 1/16W R2328 AD302345 R803R9472J 4.7K OHM 1/16W R2329 AE004247 R803R91R2J 1.2 OHM 1/16W R2330 AE001783 R803R9102J OHM 1/16W R2332 AE001890 R803R9221J 220 OHM 1/16W R2333 AE001890 R803R9221J...
  • Page 107 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS R3053 AE001896 R803R9474J 470K OHM 1/16W R3055 AE001891 R803R9223J 22K OHM 1/16W R3056 AE001783 R803R9102J OHM 1/16W R3057 AE001891 R803R9223J 22K OHM 1/16W R3062 AE001783 R803R9102J OHM 1/16W R3063 AE001783 R803R9102J...
  • Page 108 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description RESISTORS R8008 AE001796 R803R9471J 470 OHM 1/16W R8009 AE000353 R002T2471J 470 OHM 1/2W R8010 AE001800 R803R9680J OHM 1/16W R8011 AD301203 R002T4101J 100 OHM 1/4W R8012 AE001796 R803R9471J 470 OHM 1/16W R8013 AE001784 R803R9103J...
  • Page 109 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS C121 AE002131 CS0PF0414Z 0.01 UF 50V F C122 AE002131 CS0PF0414Z 0.01 UF 50V F C123 AE002131 CS0PF0414Z 0.01 UF 50V F C124 AE002131 CS0PF0414Z 0.01 UF 50V F C126 AE001735 CS0PCH4W2J...
  • Page 110 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS ! C516 BZ110256 CC3LE0MH3M 0.0022UF 250V ! C518 AE004691 E61FF0222D 2200 UF 6.3V ! C519 AD301535 E02LU2101M 100 UF 16V C520 AE001737 CS0PF0N16Z UF 10V F C521 AD301535 E02LU2101M 100 UF 16V ! C522...
  • Page 111 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS C759 BZ110263 E50HU2220M UF 16 V C760 AE001726 CS0PB0414K 0.01 UF 50V B C762 AE001726 CS0PB0414K 0.01 UF 50V B C763 BZ110263 E50HU2220M UF 16 V C764 AE001275 CS0PF0415Z 0.1 UF 50V F C765...
  • Page 112 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS C3036 AE001275 CS0PF0415Z 0.1 UF 50V F C3038 AE001737 CS0PF0N16Z UF 10V F C3040 AE001737 CS0PF0N16Z UF 10V F C3041 AE002822 CS0PB04E3K 0.0015UF 50V B C3044 AE003854 CS0PCH4B1J PF 50V CH C3045 AE000958...
  • Page 113 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS C4067 AE001543 E50HU0470M UF 6.3V C4068 BZ110150 E50HU0101M 100 UF 6.3V C4069 AE001543 E50HU0470M UF 6.3V C4070 AE001768 E50HU0221M 220 UF 6.3V C4071 AE001543 E50HU0470M UF 6.3V C4072 AE001275 CS0PF0415Z 0.1 UF 50V F...
  • Page 114 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description CAPACITORS C8057 AE001275 CS0PF0415Z 0.1 UF 50V F C8058 AE002825 CS0PCH411D PF 50V CH C8060 AE002825 CS0PCH411D PF 50V CH C8062 BZ110187 E02LT0102M 1000 UF 6.3V C8063 BZ110187 E02LT0102M 1000 UF 6.3V C8064 79091384...
  • Page 115 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description DIODES D8111 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17 D8112 BZ410086 DD7R0S3550 DIODE,SILICON 1SS355 TE-17 IC101 AE000033 I04F38225F HA118225F ! IC501 AD302211 I1KJ9A431A KIA431A-AT ! IC502 BZ611089 I1KA98R09A KIA78R09API ! IC503 AE002809 000220002W PHOTO COUPLER...
  • Page 116 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description TRANSISTORS Q3008 BZ410097 0000M00390 PHOTO TRANSISTOR ST-304L Q8001 BZ510109 TCAA3875SY TRANSISTOR,SILICON KTC3875S_Y_RTK Q8002 BZ510045 TNYJD05001 COMPOUND TRANSISTOR DTC144EKAT146 Q8003 BZ510021 TNYJC05001 COMPOUND TRANSISTOR DTC124EKAT146 Q8004 BZ510073 TAATA12660 TRANSISTOR,SILICON KTA1266-AT(Y,GR) Q8005 BZ510109 TCAA3875SY...
  • Page 117 ELECTRICAL REPLACEMENT PARTS LIST Location No. TSB P/N Reference No. Description SWITCHES SW687 AE001707 0504R01T38 SWITCH TACT EVQ11L05R SW689 AE001707 0504R01T38 SWITCH TACT EVQ11L05R SW690 AE001707 0504R01T38 SWITCH TACT EVQ11L05R SW691 AE001707 0504R01T38 SWITCH TACT EVQ11L05R SW3001 BZ612016 0508S11001 SWITCH (LEAF) LSA-1144EAU P.C.BOARD ASSEMBLIES PCB010...
  • Page 118 ELECTRICAL REPLACEMENT PARTS LIST RESISTOR RC....CARBON RESISTOR CAPACITORS CC....CERAMIC CAPACITOR CE....ALUMI ELECTROLYTIC CAPACITOR CP....POLYESTER CAPACITOR CPP....POLYPROPYLENE CAPACITOR CPL....PLASTIC CAPACITOR CMP....METAL POLYESTER CAPACITOR CMPL....METAL PLASTIC CAPACITOR CMPP....METAL POLYPROPYLENE CAPACITOR K4-15...
  • Page 119 TOSHIBA CORPORATION 1-1, SHIBAURA 1-CHOME, MINATO-KU, TOKYO 105-8001, JAPAN...
