IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PXT12538
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
431150 Rev. 3
06.16.10 JA
DO NOT THROW AWAY
5000
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PXT12538
Summary of Contents for Poulan Pro PXT12538
- Page 1 Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. PXT12538 LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 431150 Rev. 3 06.16.10 JA Printed in the U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “TRACTOR” • MODEL NUMBER - “PXT12538 (96016002200)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic 38
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 SCHEMATIC 38 SCH03 BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY... -
Page 4: Electrical 32
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 ELECTRICAL 32... - Page 5 TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 ELECTRICAL 32 PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 176689 Box Battery 176138 Switch Interlock 175688 Harness Asm Light w/4152j 4152J Bulb Light #1156 421299 Cable Battery 6 Ga.
-
Page 6: Chassis
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 CHASSIS AND ENCLOSURES 39... -
Page 7: Chassis
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 CHASSIS AND ENCLOSURES 39 PART DESCRIPTION 174619 Chassis 176554 Drawbar, Stretch 155272 Bumper, Hood/Dash 428394X010 Dash 72140608 Bolt, Carriage 3/8-16 x 1 174996 Panel Dash LH 172105X010 Panel Slkscr Dash RH... -
Page 8: Drive 40
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 DRIVE 40 52 30 drive-stlt_Peerless_fender_18... -
Page 9: Drive
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 DRIVE 40 PART PART DESCRIPTION DESCRIPTION - - - - - - Transaxle Peerless 206-545C 10040700 Washer Lock Hvy Hlcl Spr 7/16 146682 Spring Return Brake T/a Zinc... -
Page 10: Engine 24
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 ENGINE 24 OPTIONAL EQUIPMENT Spark Arrester engine-stlt_bs_15... -
Page 11: Engine
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 ENGINE 24 PART DESCRIPTION 170551 Control Th/ch Flag 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 - - - - - - - - Engine, B&S 219807-0389-B1 179758 Muffler Exhaust B&S... -
Page 12: Steering
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 STEERING ASSEMBLY 41 Steering-lt_OPP_1... -
Page 13: Steering
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 STEERING ASSEMBLY 41 PART DESCRIPTION 186780 Wheel Steering 418168 Axle Asm 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Washer Thrust .75 x 1.230 121748X Washer 25/32 x 1-5/8 x 16 Ga. -
Page 14: Decals 27
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 DECALS 27 PART PART DESCRIPTION DESCRIPTION 405121 Decal, Replacement 429170 Decal, Hood 408808 Decal, Engine HP 145005 Decal, Caution, Battery 170563 Decal, Warning 179769X428 Pad Foot Rest RH... -
Page 15: Seat
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 SEAT ASSEMBLY 42 seat_lt.bolt_9 PART PART DESCRIPTION DESCRIPTION 424035 Seat 134300 Spacer Split .28 x .96 140551 Bracket Seat Pivot 121250X Spring Cprsn 71110616 Bolt Hex 3/8 - 16 x 1... -
Page 16: Mower Deck 44
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 MOWER DECK 44 38-7_deck-manual_22... -
Page 17: Mower Deck
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 MOWER DECK 44 PART PART DESCRIPTION DESCRIPTION 192556 Mower Housing Assembly 193216 Spring Brake Return 72140506 Bolt Carriage 5/16-18 x 3/4 19131311 Washer 13/32 x 13/16 x 11 Ga. -
Page 18: Mower Lift 45
TRACTOR - - MODEL NO. PXT12538 (96016002200), PRODUCT NO. 960 16 00-22 MOWER LIFT 45 16 17 lift-rh.1piece_32 PART PART DESCRIPTION DESCRIPTION 404981 Plunger Asm Lift Lever 73350800 Nut Jam Hex 1/2-13 unc 159471 Shaft Asm Lift RH 175689 Trunnion... - Page 19 SERVICE NOTES...
-
Page 20: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
