IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PO12530LT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan.com
532 43 83-68 Rev. 8
DO NOT THROW AWAY
5000
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Failure to do so
can re sult in serious injury.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PO12530LT
Summary of Contents for Poulan Pro PO12530LT
- Page 1 Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Failure to do so can re sult in serious injury. PO12530LT LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan.com 532 43 83-68 Rev. 8...
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “TRACTOR” • MODEL NUMBER - “PO12530LT (96041021300)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 SCHEMATIC SCH18 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK... -
Page 4: Electrical
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 ELECTRICAL T31K With 12V Outlet Option With Service Minder Option... - Page 5 TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 ELECTRICAL PART DESCRIPTION 532 14 49-24 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock 532 41 28-94 Cable Starter Battery 6 Ga.
-
Page 6: Chassis
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 CHASSIS Chassis-tex_ALPHA_1... - Page 7 TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 CHASSIS PART DESCRIPTION 532 41 17-64 Dash 532 40 61-79 Hood 532 43 85-44 Grille 532 19 61-25 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4 532 42 09-86...
-
Page 8: Drive
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 DRIVE drive-tex_peerless_fender_39_r1... -
Page 9: Drive
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 DRIVE PART PART DESCRIPTION DESCRIPTION – – – – – – Transaxle, Peerless 203-569 (Order 532 16 94-84 Retainer Clip parts from transaxle manufacturer.) 532 10 57-09 Spring, Return, Clutch... -
Page 10: Engine
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tex_BS_30... - Page 11 TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 ENGINE KEY PART DESCRIPTION – – – – – – Engine Briggs Model No. 219807-3389-G1 (438203) (Order parts from engine manufacturer.) 532 17 97-58 Muffler 532 19 43-19 Keeper Belt Engine...
-
Page 12: Steering
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 STEERING steering-tex_STDHRS_10... -
Page 13: Tractor - Model No. Po12530Lt (96041021300), Product No. 960 41
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 STEERING PART DESCRIPTION 532 42 45-43 Wheel, Steering 532 41 81-68 Axle Asm., Front 532 41 68-45 Spindle Asm., LH 532 41 68-46 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23... -
Page 14: Mower Deck
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 MOWER DECK tex-deck_SRD_25_r1... -
Page 15: Mower Deck
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 MOWER DECK KEY PART KEY PART DESCRIPTION DESCRIPTION 532 19 70-26 Spring Torsion 532 41 92-72 Deck Weldment 30"Srd 532 11 04-52 Nut Push 532 19 51-61 Stud Fastner w/'d'anti-Rotatio 532 40 18-72 Spring Return Deck 38/46"... -
Page 16: Mower Lift
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 MOWER LIFT 101* lift-tex_18_r4 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm.,Cross Lift 817 00 06-12 Screw 3/8-16 x .75 Smgml Tap/R.Z 532 19 52-31 Lever Asm., Lift RH... -
Page 17: Seat
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 SEAT seat-tex_knob_1 PART PART DESCRIPTION DESCRIPTION 532 40 30-17 Seat 532 13 43-00 Spacer Split 532 18 01-66 Bracket Pivot Fender 532 12 37-40 Spring CPRSN Plate SW 1.310 Ga. -
Page 18: Decals
TRACTOR - MODEL NO. PO12530LT (96041021300), PRODUCT NO. 960 41 02-13 PART PART DESCRIPTION DESCRIPTION 532 40 88-08 Decal Engine HP 532 14 08-37 Decal Saddle Brake Parking 532 43 38-18 Decal Fender RH/LH 532 18 04-32 Decal Fender 100 DB/CE... -
Page 19: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship. -
Page 20: Parts And Service
Model Number/Manufacturer's I.D. Number b. Description of part. For Technical Assistance: call 1-800-829-5886 For a Parts Manual, go to our website: www.poulan.com/support.asp NOTE: HOP provides parts and service through its au thor ized dis tribu tors and dealers; there fore, all requests for parts and service should be directed to your local dealer(s).
