- Page 1 REPAIR PARTS MANUAL MODEL NO. 14592RB (BA14592RBD) Lawn Tractor 532 18 94-01 01.06.04 RD PRINTED IN U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “Tractor” • Model Number - “14592RB (BA14592RBD)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 SCHEMATIC 12VDC STARTER AMMETER BATTERY SOLENOID (OPTIONAL) STARTER FUSE WHITE BLACK BLACK BLACK FBI BUZZER SWITCH CLUTCH / BRAKE ATT'MENT CLUTCH (PEDAL UP) (CLUTCH OFF) GREEN OPERATOR PRESENCE RELAY GREEN... -
Page 4: Electrical
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 ELECTRICAL... - Page 5 REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 ELECTRICAL KEY PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 17 61-38 Switch Interlock Push-In 532 18 37-59 Harness Asm. Light...
-
Page 6: Chassis
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 CHASSIS AND ENCLOSURES 26 25 chassis_Elite Value_CRD_4... -
Page 7: Chassis
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 CHASSIS AND ENCLOSURES KEY PART KEY PART DESCRIPTION DESCRIPTION 532 17 46-20 Chassis 532 18 13-88 Console 532 18 03-84 Drawbar 532 15 65-24 Rod Pivot Chassis/Hood 817 06 06-12 Screw 3/8-16 x .75... -
Page 8: Drive
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 DRIVE drive-fender_CRD_Elite_Basic_2... - Page 9 REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 DRIVE KEY PART KEY PART DESCRIPTION DESCRIPTION - - - - - - - Transaxle Peerless 206-546 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga. Order parts from transaxle manu-...
-
Page 10: Steering
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 STEERING ASSEMBLY steering_pl.lt_29... -
Page 11: Steering
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 STEERING ASSEMBLY KEY PART DESCRIPTION 532 17 59-04 Steering Wheel 532 18 47-06 Cast Iron Axle Assembly 532 16 98-40 Spindle Assembly, L.H. 532 16 98-39 Spindle Assembly, R.H. -
Page 12: Seat
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 SEAT ASSEMBLY seat_lt.bolt_7 KEY PART KEY PART DESCRIPTION DESCRIPTION 872 05 04-12 Bolt Rdhd Sht Nk 1/4-20 x 1-1/2 532 18 87-04 Seat 532 13 43-00 Spacer Split... -
Page 13: Decals
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 DECALS MAX + _ 90N MAX + _ 150N KEY PART KEY PART DESCRIPTION DESCRIPTION 532 14 54-98 Decal Read Owner’s Manual Sym 532 15 97-36 Decal Chassis Hot Muffl er... -
Page 14: Engine
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_37... -
Page 15: Engine
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 ENGINE KEY PART DESCRIPTION 532 17 05-51 Control Throt 817 72 04-08 Screw Hex Thd Cut 1/4-20 x 1/2 - - - - - - - - Engine B&S Model 21A807... -
Page 16: Mower Lift
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 MOWER LIFT 17 18 lift-rh.1piece_3... - Page 17 REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 MOWER LIFT KEY PART DESCRIPTION 532 15 94-61 Wire Asm Inner Spring W/Plunger 532 15 94-76 Shaft Asm. Lift 532 17 89-81 Pin Groove 812 00 00-02 E Ring #5133-62 819 21 16-21 Washer 21/32 x 1 x 21 Ga.
-
Page 18: Mower Deck
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 MOWER 36(92cm)_deck-elect.(CRD)_1 36 GW med/wide/std... - Page 19 REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 MOWER KEY PART KEY PART DESCRIPTION DESCRIPTION 532 16 55-52 Housing Asm. Mower 873 68 06-00 Nut Crownlock 3/8-16 unc 872 14 05-06 Bolt Rdhd Sqnk 5/16-18 unc x 3/4...
-
Page 20: Bagger
REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 BAGGER Bagger Asy (CRD)_6... - Page 21 REPAIR PARTS TRACTOR- -MODEL NO. 14592RB (BA14592RBD), PRODUCT NO. 964 77 25-02 BAGGER KEY PART DESCRIPTION 532 16 52-49 Tube Handle Bagger CRD 872 14 04-16 Bolt Carriage 1/4-20 x 2.0 Gr.5 532 12 39-76 Nut Lock 1/4 Lge Flg Gr. 5 Zinc 532 16 99-16 Handle Bagger w/Lvrs Gr.
- Page 22 SERVICE POLICY ® ® WARRANTY Issued January 1980 Revised January 1991 LIMITED WARRANTIES NEW PEERLESS GEAR POWER TRAIN COMPONENTS A. Products Warranted Peerless Gear and Machine Division of Tecumseh Products Company (“Tecumseh”), subject to the limitations contained below, will,at its option, repair or replace, without charge for parts or labor only, any part of a new Power Train Component (which as used herein means and includes the transaxle, gear box, transmission, differential and right angle drives, and any part of the Power Train Component), EXCEPT any new Power Train Component incorporated in equipment used for commercial or rental purposes, which is found upon examination by any Tecumseh Authorized Service Outlet or by Tecumseh’s factory in Grafton, Wisconsin, to be DEFECTIVE...
-
Page 23: Limited Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of one (1) year from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi... - Page 24 FINLAND SUOMI Electrolux Outdoor Products Finland Tel: 00 39611, Fax: 00 39 612632 ITALIA McCulloch Italiana s.r.l. - Via Como 72, 23868 Valmadrera (LECCO) - ITALIA, Tel: 800 017829, Fax: 0341 581671 IRELAND Electrolux Outdoor Products Tel: 01 4565222, Fax: 01 4568551 MAGYARORSZÁG...
