4. Securely crimp each connection and solder it. 5. Inspect the solder joints of the two “original” leads on the circuit board copper side. If they are not shiny, reheat them and apply additional solder if necessary. TECHNICAL INFORMATION Model Names 902D 903Ds 904DF CDT Size 19-inch...
GENERAL INFORMATION This color monitor automatically scans all horizontal frequencies from 30KHz to 95KHz, and all vertical frequencies from 50Hz to 160Hz. This color monitor supports IBM PC, PC/XT, PC/AT, personal System/2 (PS/2), Apple Macintosh, and compatible users crisp text and vivid color graphics display when using the following graphics adapters : (VGA, 8514/A, Super VGA, VESA and XGA and Apple Macintosh Video Card).
PIN CONNECTOR Signal Green Blue GND - Red GND - Green GND - Blue +5Vdc Arrangement of 15-pin D-sub connector GND - H.Sync GND - V.Sync Bi-directional Data (SDA) Horizontal Sync Vertical Sync (VCLK) Data Clock (SCL) CAUTIONS FOR ADJUSTMENT AND REPAIR •...
OPERATION AND ADJUSTMENT Control Panel • Move cursor to the right window on the OSD window. • Increase the value of any selected function. • Move cursor to the left window on the OSD window. • Decrease the value of any selected function. •...
Key Process ENGL SH DEUTSCH ESPAÑOL FRANCA S TAL ANO MENU Start • When you choose the icon on the OSD window, you can exit the OSD screen. Hot Key BRIGHTNESS CONTRAST...
OSD Functions ICON CONTROL FUNCTIONS Select language for OSD (5 languages). LANGUAGE H. CENTER & Adjust the position of the display horizontally(left or right) and vertically (up or down) V. CENTER Choose different preset color temperatures or set your own customized color parameters. COLOR TEMP RED GAIN Adjust the red gain.
Page 8
ICON CONTROL FUNCTIONS Adjust the left and right margins for more convex or more concave margins. PINCUSHION Adjust the trapezoid of the screen by moving the lines inward or outward. TRAPEZOID Adjust the side balance when the sides of the screen are bowed towards left or right. PIN BALANCE Adjust the parallelogram when the screen is leaning left or right.
Horizontal Frequency : 30KHz - 95KHz Vertical Frequency : 50Hz - 160Hz Pre-Adjustment 1. HV Adjustment Adjust VR151 for 26KV(902D, 904DF) / 26.5KV(903Ds) at 91KHz mode. Main Adjustment 1. Setting the Controls Set contrast and brightness in Control Menu unless otherwise specified.
Page 10
(k) Select 6550°K on the OSD Menu and set the color coordinates in x=0.313, y=0.329 at the maximum contrast control and center brightness control (l) Check if a full white pattern is over 27Ft/L. 5. Static Convergence Adjustment (a) Apply a magenta cross hatch pattern on display. (b) Adjust the focus from the best over all focus on the display.
9. Abnormal Picture 9-1. Horizontal Size * At first, adjust controls in the OSD Menu * The B+ are as follows: MODE Scan B+ S.VGA XGA 46K CAD 68K 109V 125V 135V...
INFORMATION OF PART DESCRIPTION Important Safety Notice Components identified with the International Symbol have special characteristics important for safety. When replacing any components, use only manufacturer’s specified parts. Abbreviation of Description RESISTOR Description Allowance ± 1% ± 5% ± 10% ±...
ELECTRICAL PARTS LIST ! have special characteristics important for safety and x-ray radiation. The components identified by mark These should be replaced only with the types specified in the parts list. PART-CODE PART-NAME PART-DESC NOTE 00010 9979800482 PCB CRT T=1.6*155*123 00010 9979800497 PCB CONTROL...
Page 36
PART-CODE PART-NAME PART-DESC NOTE C155 CMXL2E473J C MYLAR MEU 250V 0.047MF J(TP) C159 CMXM2A222J C MYLAR 100V 2200PF J (TP) C160 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP C161 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP C162 CCXF1H104Z C CERA 50V F 0.1MF Z C163...
Page 37
PART-CODE PART-NAME PART-DESC NOTE C322 CXCH1H221J C CERA 50V CH 220PF J (TAPPING) C323 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C324 CCZB1H181K C CERA 50V B 180PF K AXIAL C325 CMXM2A104J C MYLAR 100V 0.1MF J (TP) C401 CMXM2A273J C MYLAR 100V 0.027MF J (TP) 903Ds only...
Page 38
PART-CODE PART-NAME PART-DESC NOTE C539 CMXM2A222J C MYLAR 100V 2200PF J (TP) C540 CCXB2H221K C CERA 500V B 220PF K (TAPPING) C541 CMXM2A104J C MYLAR 100V 0.1MF J (TP) 904DF only C541 CMXM2A184J C MYLAR 100V 0.18MF J C542 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP C542...
Page 39
PART-CODE PART-NAME PART-DESC NOTE C819 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012 C820 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP C823 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012 C824 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012 C825 CEXF1H470V C ELECTRO...
Page 45
PART-CODE PART-NAME PART-DESC NOTE R156 RD-AZ223J- R CARBON FILM 1/6 22K OHM J R157 RD-AZ103J- R CARBON FILM 1/6 10K OHM J R158 RD-2Z221JS R CARBON FILM 1/2 220 OHM J SMALL R159 RD-AZ103J- R CARBON FILM 1/6 10K OHM J R160 RD-AZ100J- R CARBON FILM...
Page 46
PART-CODE PART-NAME PART-DESC NOTE R244 RD-AZ100J- R CARBON FILM 1/6 10 OHM J R245 RD-4Z101J- R CARBON FILM 1/4 100 OHM J R246 RD-AZ513J- R CARBON FILM 1/6 51K OHM J R247 RD-2Z203JS R CARBON FILM 1/2 20K OHM J SMALL R250 RD-AZ182J- R CARBON FILM...
Page 47
PART-CODE PART-NAME PART-DESC NOTE R376 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J 904DF only R380 RD-AZ331J- R CARBON FILM 1/6 330 OHM J R381 RD-AZ331J- R CARBON FILM 1/6 330 OHM J R382 RD-AZ331J- R CARBON FILM 1/6 330 OHM J R383 RD-AZ331J- R CARBON FILM...
Page 48
PART-CODE PART-NAME PART-DESC NOTE R528 RS02Z470J- R M-OXIDE FILM 2W 47 OHM J (TAPPING) 904DF only R529 RS02Z101J- R M-OXIDE FILM 2W 100 OHM J (TAPPING) R529 RS02Z470J- R M-OXIDE FILM 2W 47 OHM J (TAPPING) 903Ds only R529 RS02Z470J- R M-OXIDE FILM 2W 47 OHM J (TAPPING) 904DF only...
Page 49
PART-CODE PART-NAME PART-DESC NOTE R569 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J R571 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J R572 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J R573 RD-AZ105J- R CARBON FILM 1/6 1M OHM J R574 RD-AZ472J- R CARBON FILM...
Page 50
PART-CODE PART-NAME PART-DESC NOTE R828 RD-AZ101J- R CARBON FILM 1/6 100 OHM J R829 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012 R831 HRFT750JCA R CHIP 1/10 75 OHM J 2012 R832 HRFT102JCA R CHIP 1/10 1K OHM J 2012 R833 RD-AZ330J- R CARBON FILM...
