HEATER SAFETY
® ®
PLEASE READ AND SAVE
Twin Ceramic
THESE IMPORTANT
Heater
SAFEGUARDS
MODEL
BCH4267 IMPORTANT INSTRUCTIONS
When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
1. Read all instructions before using the appliance.
2. To avoid fire or shock hazard, plug the appliance
directly into an outlet of the same voltage as the one
indicated on the rating plate of your appliance.
3. The heater is hot when in use. To avoid burns, DO
NOT let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers,
clothes, and curtains at least 3 ft (0.9 m) from the
front of the heater and keep them away from the
sides and rear.
4. DO NOT run cord under carpeting. DO NOT cover
cord with throw rugs, runners, or the like. Arrange
cord away from traffic area and where it will not be
tripped over.
5. This heater is not intended for use in bathrooms,
laundry areas and similar indoor location. NEVER
locate heater where it may fall into a bathtub or other
water container.
6. Extreme caution is necessary when any heater is used
by, or near children or invalids, and whenever the
heater is left operating and unattended.
7. Always unplug the heater when not in use.
8. When unplugging, be sure to pull by the plug and not
the cord.
9. DO NOT insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
10.DO NOT operate heater with a damaged cord or plug,
or after the heater malfunctions, has been dropped or
damaged in any manner. Take appliance to authorized
service center for examination, electrical or mechanical
Read instructions before operating.
adjustment, or repair.
Retain for future reference.
11.A heater has hot and arcing or sparking parts inside.
Instruction Leaflet
DO NOT use it in areas where gasoline, paint, or
flammable liquids are used or stored.
12.Use appliance only for intended household use as
described in this manual. Any other use not
recommended by the manufacturer may cause fire,
electric shock, or injury to persons. The use of
Fig. 1
attachments not recommended or sold by the
manufacturer may cause hazards.
13.DO NOT use outdoors.
14.To prevent a possible fire, DO NOT block air intakes
or exhaust in any manner. DO NOT use on soft
surfaces, like a bed, where openings may become
blocked.
15.To disconnect heater, turn controls to OFF, then
remove the plug from outlet.
16.DO NOT attempt to repair or adjust any electrical or
B
mechanical functions on this unit. Doing so will void
your warranty. The inside of the unit contains no user
serviceable parts. All servicing should be performed
by qualified personnel only.
17.Discontinue use if plug or outlet is hot. It is
recommended that the outlet be replaced if plug or
A. Thermostat Control
outlet is hot to touch.
B. Selector Control/ Mode
18.If the heater will not operate, see specific instructions
HI (II) LO (I) OFF (O)
on Auto Safety Shut-off.
C. Power Indicator Light
PLEASE SAVE THESE
Fig. 2
INSTRUCTIONS
CONSUMER SAFETY INFORMATION
This plug fits a specific outlet only. This is a safety feature
intended to help reduce the risk of electrical shock. If the
plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
DO NOT DEFEAT THE SAFETY PURPOSE OF THIS
POLARIZED PLUG IN ANY WAY.
OPERATING INSTRUCTIONS
B
Setting the Power Level
1. For heater operation, turn Thermostat Control (A) to HI
( ) (See Figure 2).
2. When the desired temperature is reached, slowly turn
2. Turn Selector Control (B) to II or I. the Thermostat Control back (counter-clockwise) until
the heater switches off.
NOTE: Power Indicator Light (C) will illuminate when
heater is plugged into the mains. 3. The control will now automatically maintain the pre-set
temperature level by turning the heater ON and OFF.
Setting the Thermostat
4. The Power Indicator Light will remain lit to indicate the
The thermostat maintains the desired temperature level
heater in on.
by switching on and off.
NOTE: It is normal for the heater to cycle ON and OFF
1. Turn the Thermostat Control all the way to the right
as it maintains the preset temperature. To prevent the
(clockwise) to the maximum temperature level.
unit from cycling, you need to change the thermostat
setting.
FROST-GUARD SETTING
This special setting will automatically turn on the heater if
C
the room's temperature reaches freezing. To set, turn the
Thermostat Control all the way to LO (
A
Selector Control to either HI ( II ) or LO ( I ).
COLOR CHANGING DISPLAY
Your heater features the revolutionary technology and
safety of Color Changing Display. As your heater warms
up, parts of the front grill will change color, a visual
reminder that the grill is warm and the heater is on. The
exact timing of the color change may vary. When the
heater is turned off, the grill will return to its original color,
thus indicating the grill is cool to the touch. This may take
up to an hour depending on the environment surrounding
the heater and the cooling down time of the element.
NOTE: If left in extreme cold temperatures (-22°F/-30°C)
the Color Changing Display may not perform. The heater
itself will function normally. Store heater in a cool and dry
location.
NOTE: The color changing effect may wear off after
continuous, heavy use of the heater or in time. The heater
will continue to operate normally.
A
C
AUTO SAFETY SHUT-OFF
This heater is equipped with a technologically-advanced,
safety system that requires the user to reset the heater if
), and turn the there is a potential overheat situation. When a potential
overheat temperature is reached, the system will
automatically shut the heater off. It can only resume
operation when the user resets the unit.
To Reset the Heater:
1. Turn the Selector Control (B) to OFF (O) and
Thermostat to HI ( ).
2. Unplug unit, wait 30 minutes.
3. Plug in and turn ON.
SAFETY BACK-UP FUSE
In the unlikely case the heater does not respond to an
overheat situation, the safety back-up fuse will engage. In
this case, the heater will not reset. Please contact your
local service number on the back of the manual for
advice.
How To Obtain Warranty Service: Please see the
country specific warranty insert or contact your
local authorized distributor for Bionaire appliances.
PLEASE DO NOT RETURN THIS PRODUCT TO THE
PLACE OF PURCHASE.
