Tappan TMV151FBA Service Manual

OVER-RANGE MICROWAVE OVEN
This service manual is intended for use by persons having electrical and mechanical training
and a level of knowledge of these subjects generally considered acceptable in the appliance
repair trade. Electrolux Home Products cannot be responsible, nor assume any liability, for
injury or damage of any kind arising from the use of this manual.
Publication # 5995496154
ELECTROLUX HOME PRODUCTS NORTH AMERICA
SERVICE MANUAL
MODEL - TMV151FBA
& TMV151FSA

OVEN SPECIFICATIONS

Power Supply
Input Power
Cooking Power
Frequency
Outer Dimensions (WxHxD)
Cavity Volume
Net Weight
! ATTENTION !
120 VAC, 60 Hz
1,650 W
1,000 W
(IEC 60705 Standard)
2,450 MHz
29 " x 16 ½" x 15"
7
8
1.5 Cu. Ft.
45.4 lbs.
July 2007 P/N 316439251
