- Page 1 H-LCD4201 LCD TV Instruction manual...
-
Page 2: Table Of Contents
Table of contents Table of contents ............................2 Important safety precautions ........................3 General introduction ............................ 5 Accessories..............................5 Controls and connection..........................6 OSD operations ............................10 Other Operations ............................14 Troubleshooting............................18 The causes of interference...........................19 Specifications .............................20 Thank you very much for buying our product – the most natural Colour Television Receiver. To enjoy your set to the full from the very beginning, read this manual carefully and keep it for future refer- ence. -
Page 3: Important Safety Precautions
Important safety precautions Warning Please unplug the power cord from the AC outlet and contact our service personnel to repair under the fol- lowing conditions: Any obvious abnormality appears in the product, such as smoky, peculiar smell or strange sound. When a liquid has been spilled or other objects have fallen into the product. - Page 4 Fasten the wheel of the product or shelf with wheels when installing this product. If it moves or is tipped over, it may be damaged. Do not place any fire source such as candlelight close to this product or place it on this product. If it is tipped over or fallen down, it may cause damage or fire.
-
Page 5: General Introduction
General introduction Size of the screen: 42”/107 cm Aspect ratio: 16:9 Screen resolution: 1366 x 768 Brightness: 500 cd/m2 Contrast: 1000:1 Wide viewing angle 176º/176º Response time: 8 ms Progressive scan Color systems: PAL, SECAM, NTSC Digital comb filter NICAM Stereo, 2 x 5 W “Picture in picture”... -
Page 6: Controls And Connection
Controls and connection Place your LCD TV on a flat surface in a well-ventilated location. Rear panel Earphone terminal Top panel button description Button Description MENU Open the menu or switch among the menus. TV/AV To switch among the signal source. VOL-/+ Decrease/increase the sound volume. - Page 7 Items Connection description Connect one end of the HDMI cable with HDMI output port, connect the HDMI 2 other end of the HDMI cable with the HDMI port on the TV, and tighten the HDMI 1 bolts clockwise on the each end of HDMI cable. Connect one end of the VGA cable with the VGA port on computer, con- nect the other end of the VGA cable with the VGA port on the TV, and tighten the bolts clockwise on the each end of VGA cable.
- Page 8 Remote control (RC) ZOOM button. In TV, AV, SVIDEO mode. RECALL button. The former channel can be restored if the last operation is changing channel; this button also can be also used go back to the last signal source if the last operation is changing the signal source.
- Page 9 Insert the batteries Remove the battery cover by pressing the symbol and pulling the cover space in the direction of the ar- row. Insert the two 1.5V (AAA size) batteries making sure the polarity (+ or -) of the batteries matches the polarity marks inside the unit.
-
Page 10: Osd Operations
OSD operations Note: In this manual the OSD (On Screen Display) may be different from your TV’s because it is just an ex- ample to help you with the TV operation. In the following contents, press MENU button to enter the menu; press P+/P- buttons or CH+/CH- buttons to select an item. - Page 11 During searching, press MENU button to quit the automatic search and go back to the previous menu. Automatic searching starts from Channel 1, all the searched channels will be stored automatically. Dur- ing searching, the modes of color and sound are automatically stored, thus to make sure the searched channel later can be played correctly.
- Page 12 Timer Press MENU button, and select the TIMER setting menu de- scribed as the following picture: Current Time. Set the current time by pressing V+/V- buttons and P+/P- buttons to change the time parameter (hour: minute), or you can directly input the time through the number buttons.
- Page 13 Power Manage. Power Management Mode, you can select Off, 2 hours, 3 hours and 4 hours by pressing V+/V- buttons, this operation means if there is no any operation to the TV in 2 or 3 or 4 hours, the TV will enter into the standby mode automatically.
-
Page 14: Other Operations
Other Operations Turning on/off the TV Turning on 1. Connect the power input port on TV with AC power cable, and then connect it with A power supply, turn on the AC switch of the TV, the indicator turns red, TV enters into standby mode. 2. -
Page 15: Picture Mode Selection
any of the following operation is made: pressing MUTE button, adjusting the TV’s volume or adjusting the sound “Balance”. Switching to stereo or bilingual, the mute mode can be quitted, but you cannot quit the mute mode by reducing the volume. The icon displayed on the lower left position is as the following picture: The volume setting menu MUTE mode is as the following picture: When TV is working in TV and HDMI mode, it will turn to MUTE mode automatically if there is no signal... - Page 16 COMP1 720P/60Hz COMP2 720P/60Hz TIME TIME AUTO -------- PIP function is “OFF” PIP function is “ON” “##” is the number of current PIP channel. “- - - -” is the name of the PIP channel (at most 7 letters), if the channel name is not changed, “----”...
- Page 17 System will power down Press OK to cancel “xx” is the remained number which indicates you with how many seconds the TV will enter into standby mode. The value will be deducted to 0 from 30. At this time, you can press MENU, EXIT, OK on the RC to quit the standby mode, which the TV will carry out about.
-
Page 18: Troubleshooting
Troubleshooting Before calling a technician, please check the following items to see whether you can easily diagnose and fix the encountered symptoms on your own. Symptoms Possible Cause Correction The power cord is not plugged in. Plug the power cord in. No picture, no sound, Contrast, sharpness, color and volume are Alter the value of contrast, sharpness,... -
Page 19: The Causes Of Interference
The causes of interference Incorporated in your TV receiver are the most up-to-date devices to eliminate interference. Local radiation however, can create disturbances, which visibly affect your picture. Proper installations, a good aerial are your best safeguards against these disturbances. RF INTERFERENCE Moving ripples across the screen are caused by nearby transmitting or receiving short-wave radio equipment. -
Page 20: Specifications
Specifications Items H-LCD4201 Size (diagonal) 42” (107 cm) Brightness 500 (cd/m Contrast 1000:1 LCD panel items Angle of view 176°/176° High speed response 8 ms Resolution 1366 x 768 Color system PAL, NTSC, SECAM Sound system DK, I, BG, M... - Page 21 ...............................21 ....................22 ..........................24 ...........................24 .....................25 ........................29 ............................33 ...................37 ............................38 ........................39 HYUNDAI!
- Page 22 –20° +50° .
- Page 23 LCD-...
- Page 24 : 42”/107 : 16:9 : 1366 x 768 : 500 ² : 1000:1 : 176º/176º : PAL, SECAM, NTSC NICAM, 2 x 5 « » : 2 HDMI, VGA, S-Video, 3 , RF- : 100-240 B, 50/60...
- Page 25 MENU TV/AV VOL-/+ CH+/- POWER...
- Page 26 100-240 HDMI 2 HDMI HDMI HDMI 1 S-Video S-Video S-Video Video (YPbPr) (YPbPr) 10 VGA (PC) S-Video...
- Page 27 ZOOM. TV, AV, S- Video. RECALL. P.MODE. MENU. V-/V+. DISPLAY. STILL. TEXT. MIX. HOLD. SIZE. E/W. FAVS/CH+. PIP. PIP. CH-. PIP. POWER. HDM. HDMI. S.MODE. EXIT. P+/P-. SLEEP. MUTE. NICAM/IGR STEREO/MONO; PROG. “ ”. SCAN.
- Page 28 (AAA) (+/-).
- Page 29 MENU, P+/P-, V+/V-, MENU, MENU EXIT, MENU NTSC). DNR ( DNR: MENU MENU V+/V- V+/V-, V+/V-,...
- Page 30 MENU, (236), MENU V+/V- V+/V-. AFT ( « », V+/V- V+/V-, P+/P-. V+/V- MENU, V+/V-, P+/P-, P+/P-, “ ” AV, SVIDEO, COMPONENT, PC HDMI SVIDEO. AUTO; VGA. V-/V+.
- Page 31 V-/V+. MENU, V+/V- P+/P- V+/V- P+/P- PROG. V+/V- P+/P- PROG. V+/V- (000-235). “ ”, “ ” “ .”. V+/V-, P+/P- V+/V-, V+/V-, P+/P- PROG V+/V-, « » MENU, TV, AV SVIDEO, ZOOM 16:9, 14:9, 4:3. PC, COMPO- NENT HDMI, ZOOM 16:9 4:3.
- Page 32 » V+/V-. (2, 3 (0, 1, 2, 3, 4, 5, 6, 7) PIP. P+/P- V+/V-, PIP”, “ ”, COMP1, COMP2, PC, HDMI, HDMI2; PIP. V+/V- PIP. PIP: TV, AV1, AV2, AV3. PIP. PIP. PIP. “PIP” TV/AV MP (COMP1, COMP2, PC, HDMI, HDMI2), PIP (TV, AV1, AV2, AV3).
- Page 33 POWER POWER POWER POWER TV/AV : TV, AV1, AV2, AV3, SVIDEO, COMP1, COMP2, PC HDMI, HDMI2 CH+/CH- P+/P- CH+/CH- P+/P- « », MENU AV, SVIDEO, COMP, PC HDMI VOL+/VOL- V+/V- 0-100,...
- Page 34 MUTE MUTE, HDMI, P.MODE S.MODE TV ( DISPLAY AUTO TIME -------- “##” , AFT “ ”, “- - - -” ); “AUTO/DK” ; “TIME” AV, SVIDEO, COMP, HDMI DISPLAY; SVIDEO AUTO TIME COMP1, COMP1 HDMI/HDMI2 NO SIGNAL (« ») 720P/60 COMP1 720P/60Hz COMP2...
- Page 35 “##” “- - - -” ); “AUTO/DK” “XX” COMP1, COMP2, HDMI HDMI2. VGA, HDMI HDMI2 NO SIG- NAL (« ») 1024*768/60 1024*768/60Hz 1024*768/60Hz TIME TIME AUTO -------- “##” “- - - -” ); “AUTO/DK” “XX” VGA, HDMI HDMI 2. SLEEP SLEEP, , 15, 30, 45, 60, 90 120;...
- Page 36 “xx” MENU, EXIT (Recall) RECALL « » – 10 FAVS. SCAN, (1-9). 2.5.
- Page 37 AUTO « - » CH+/CH-...
- Page 38 « » » « ».
- Page 39 H-LCD4201 42” (107 500 ( ²) 1000:1 176°/176° 1366 x 768 PAL, NTSC, SECAM DK, I, BG, M NICAM 2 x 5 YPbPr 480i, 480 , 576i, 576 , 720 , 1080i, 1080p (YPbPr) PC VGA HDMI Plug and Play »...
