IKEA EXEMPLARISK User Manual

Built-in oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

EXEMPLARISK
GB
GENAST

Advertisement

Table of Contents
loading

Related Manuals for IKEA EXEMPLARISK

Summary of Contents for IKEA EXEMPLARISK

  • Page 1 EXEMPLARISK GENAST...
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Door safety device Daily use Electrical connection Cleaning and maintenance Environmental concerns What to do if ... IKEA GUARANTEE Safety Information Read carefully and keep for future the appliance in a safe way and understand reference. the hazards involved. Do not heat, or use flammable materials in Children shall not play with the appliance.
  • Page 5 ENGLISH not be operated until it has been repaired short time, stirring again before carefully by a trained service technician. removing the container from the oven. Important precautions Careful Always refer to a microwave cookbook for General details. Especially, if cooking or reheating This appliance is designed for domestic use food that contains alcohol.

  • Page 6: Product Description

    ENGLISH Product description Control Panel Cavity Lamp Door Grill element Accessories Turntable support Baking plate Wire rack Glass turntable...
  • Page 7 ENGLISH General Glass turntable There are a number of accessories available Place the Glass turntable on the turntable on the market. Before you buy, ensure they support. are suitable for microwave use. Use the Glass turntable with all cooking Ensure that the utensils you use are oven methods.

  • Page 8: Control Panel

    ENGLISH Control panel EXEMPLARISK GENAST Multifunction knob OK button Stop button Start button Back button Adjust knob Display...

  • Page 9: Daily Use

    ENGLISH Daily use 2. Use the Adjust knob to choose one of Start protection / key lock the following settings to adjust This automatic safety function is activated Clock one minute after the oven has returned to Sound “stand by mode“. (The oven is in “stand by” when the 24-hour clock is displayed or if the Brightness clock has not been set, when the display is...
  • Page 10 ENGLISH Jet Start automatically starts with full microwave power level and the cooking time set to 30 seconds. Each additional press increases the time with 30 seconds. You may also alter the time by the Adjust knob to increase or decrease the time. Cook and reheat with microwaves 1.
  • Page 11 ENGLISH Power level 6. Turn the Adjust knob to set the cooking time. Microwaves only 7. Press the Start button. Power Suggested use: 900 W Reheating of beverages, water, The Max. possible microwave power level clear soups, coffee, tea or other when using the Grill is limited to a factory food with a high water content.
  • Page 12 ENGLISH Ensure that the utensils used are heat If the food is colder than deep-freeze resistant and ovenproof before grilling with temperature (-18°C), choose higher weight them. of the food. IMPORTANT: Do not use plastic utensils when grilling. They will melt. Food Hints Items of wood or paper are not suitable...
  • Page 13 ENGLISH Separate pieces as they begin to defrost. 5. Press the OK button to confirm your Individual slices defrost more easily. selection. You will automatically be Shield areas of food with small pieces of taken to the next setting. aluminum foil if they start to become warm 6.
  • Page 14 ENGLISH Always use the Wire rack to put food on to Kitchen timer allow the air to circulate properly around Use this function when you need a kitchen the food. timer to measure exact time for various Use the Baking plate when baking small purposes such as cooking eggs or letting the items like cookies or rolls.

  • Page 15: Cleaning And Maintenance

    ENGLISH Cleaning and maintenance Cleaning is the only maintenance normally The Grill element does not need cleaning required. since the intense heat will burn off any Failure to maintain the oven in a clean splashes, but the cavity ceiling near it may condition could lead to deterioration of the need regular cleaning.

  • Page 16: What To Do If

    1. See if you can solve the problem on your own (see the “What to do if ...” table). 2. Switch the appliance off and on again to see if the problem has disappeared. If the fault persists after the above checks, contact IKEA After Sales Service. Always specify: the type of fault;...

  • Page 17: Technical Data

    ENGLISH Technical data Supply Voltage 230 V/50 Hz Rated Power Input 2800 W Fuse 16 A MW output power 900 W Grill 1600 W Convection 1200 W Outer dimensions (HxWxD) 455 x 595 x 565 Cavity inner dimensions (HxWxD) 210 x 450 x 420 The technical informations are situated in the rating plate inside the appliance.
  • Page 18 ENGLISH Data for test heating performance in accordance with IEC 60705. The International Electrotechnical Commission has developed a standard for comparative testing of heating performance of different microwave ovens. We recommend the following for this oven: Test Amount Approx. time Power level Container 12.3.1...

  • Page 19: Installation

    ENGLISH Installation Mounting the appliance Follow the supplied separate mounting instructions when installing the appliance. Door safety device To release the door with the door safety The door safety device can be removed by device see Fig 1. following the sequence of images (see Fig. Fig.

  • Page 20: Electrical Connection

    ENGLISH Electrical connection Prior to connecting Do not operate this appliance if it has a Check that the voltage on the rating plate damaged mains cord or plug, if it is not corresponds to the voltage in your home. working properly, or if it has been damaged Do not remove the microwave inlet or dropped.

  • Page 21: Environmental Concerns

    ENGLISH Environmental concerns The packing box may be fully recycled as confirmed by the recycling symbol ( Follow local disposal regulations. Keep The symbol on the product, or on the potentially hazardous packaging (plastic documents accompanying the product, bags, polystyrene etc.) out of the reach of indicates that this appliance may not be children.

  • Page 22: Ikea Guarantee

    IKEA five (5) years guarantee? • Consumable parts including batteries and The range of appliances named LAGAN and lamps. all appliances purchased in IKEA before 1st of • Non-functional and decorative parts which August 2007. do not affect normal use of the appliance,...
  • Page 23 IKEA appliance in the dedicated IKEA However, if an IKEA appointed Service kitchen furniture; Provider or its authorized service partner • ask for clarification on functions of IKEA repairs or replaces the appliance under appliances. the terms of this guarantee, the appointed...
  • Page 24 BELGIË - BELGIQUE - BELGIEN NEDERLAND Telefoon/Numéro de téléphone/Telefon-Nummer: 02620031 1 Telefoon: 09002354532 en/of 0900 BEL IKEA Tarief/Tarif/Tarif: Lokaal tarief/Prix d’un appel local/Ortstarif Tarief: Lokaal tarief € 0,10 p/min Openingstijd: Maandag t/m - Vrijdag 9.00 - 21.00 Openingstijd: Maandag - Vrijdag 8.00 - 20.00...
  • Page 28 © Inter IKEA Systems B.V. 2013 18535 AA-720626-1...
