Summary of Contents for Cateye CC-RD310W
- Page 1 START Click the button and follow the instructions. CATEYE STRADA WIRELESS CC-RD310W Quick Start...
- Page 2 Thank you for purchasing our cyclocomputer CATEYE STRADA WIRELESS. This Quick Start Manual explains how to set up the computer and how to install the unit on your bicycle. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
- Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the Trust in the text Play “ ” or “ ” button to close the message. Click the screen again to play the movie. Next...
- Page 4 CATEYE STRADA WIRELESS Return to a Cover Quick Start Manual Contents Click the item you wish to view. Setting up the computer How to install the bracket (movie) How to install the speed sensor (movie) Useful functions : Setting the function to display...
- Page 5 Operation of buttons Set up the computer by operating the buttons as follows. Check the button position before you start setting up. Back MENU MODE MENU MODE Press the button and the button on the back of the computer. Next...
-
Page 6: Setting Up The Computer
CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Clear all data (initialization) Clear all data (initialization) Press the button on the back of the computer. After full lighting of the screen, the computer switch- Setting the speed unit es to the speed unit setting screen to start setup. - Page 7 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the speed unit Clear all data (initialization) MODE km/h When the button is pressed, either “ ” or “ ” is selected for the speed unit display. Select the Setting the speed unit unit of your choice.
- Page 8 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Entering the tire circumference Clear all data (initialization) Enter the tire circumference (mm) of your bicycle with 4 digits using the tire circumference reference table. Setting the speed unit...
- Page 9 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the clock display Clear all data (initialization) Clear all data (initialization) MODE When the button is pressed, either “ ” or “ ” is selected for the clock display. Select the display...
- Page 10 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the hour Clear all data (initialization) MODE Pressing the button increases the value flashing (“Hour” of the clock). Enter any value. Setting the speed unit MODE...
- Page 11 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Setting the minute Clear all data (initialization) Clear all data (initialization) MODE Pressing the button increases the value flashing (“Minute” of the clock). Enter any value. Setting the speed unit...
- Page 12 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Now, setup of the computer is completed. Clear all data (initialization) If the bracket and speed sensor are not installed on your Setting the speed unit bicycle, return to Contents, click the movies of how to...
-
Page 13: How To Install The Bracket (Movie)
CATEYE STRADA WIRELESS Return to Contents Quick Start Manual How to install the bracket... -
Page 14: How To Install The Speed Sensor (Movie)
CATEYE STRADA WIRELESS Return to Contents Quick Start Manual How to install the speed sensor... - Page 15 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting up the computer Tire circumference reference table Generally, the tire size or ETRTO is indicated on the side of the tire. ETRTO Tire size L (mm) ETRTO Tire size L (mm)
- Page 16 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting the function to display How to use How to use How to set Setting the function to display You can switch the screen quickly, by skipping the data less frequently used.
- Page 17 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting the function to display How to use How to set (1/3) How to set (1/3) Setting the function to display (1/3) MENU From the measuring screen, press the button to switch to the Menu screen.
- Page 18 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting the function to display How to use How to set (2/3) How to set (2/3) Setting the function to display (2/3) MODE Pressing and holding the button switches the flashing icon.
- Page 19 CATEYE STRADA WIRELESS Return to Contents Quick Start Manual Setting the function to display How to use How to set (3/3) How to set (3/3) Setting the function to display (3/3) MENU Pressing the button 2 times registers the changed settings, and returns to the measuring screen.
