Page 1
Rock, Roll ‘n Ride Rock, Roll ‘n Ride Deluxe Trike Deluxe Trike Model Number: B2488 Music and lights respond to baby’s rocking motion. Handle helps toddlers roll along. Turn signals flash, music plays when they steer left or right! Remove the handle, flip up...
#10 x " Screw - 11 • Always wear shoes or sneakers. • Never allow more than one (1) rider. Call Fisher-Price ® Consumer Relations, toll-free at 1-800-432-5437, 8 AM - 6 PM EST Monday through Friday. Hearing-impaired consumers using TTY/TDD equipment, #8 x "...
Page 3
Parts Parts Parts not shown: Note: The base/handle assembly can be attached to the trike in Label Sheet either the Rock (page 10) or Seat Pin Assembly Tool Roll (page 11) mode. Seat Electronic Handlebar Frame Cover 2 Base/Handle Covers Frame Straight Axle 2 Rear Wheels...
Page 4
Assembly Assembly • Please save all packaging material until assembly is complete to ensure that no parts are discarded. • Wipe each part with a clean, dry, cloth before assembling this product. CAUTION This product contains small parts in its unassembled state. Adult assembly is required.
Page 5
Assembly Assembly Assembly Tool Rear Wheel Pedal Axle Spoke Side Up Cap Nut Pedal Hub Slot Straight Axle • Fit two pedal hubs onto the pedal axle tabs. Make sure the tabs fit into the slot in each pedal hub. Pedal Hubs Pedal Axle Scrap Block...
Page 7
Assembly Assembly Knobbed End Seat Frame Opening Footrest ➥ Footrest Knobbed End • Insert the knobbed end of the footrest up through the opening in the underside, center of the frame • Rotate the footrest turn Seat Mount Top View •...
Page 8
Assembly Assembly Flared End Handle Trike Cover Handle Top Base Base/Handle • Position the base/handle covers so that the flared end Handle Bottom faces the front of the trike. • Fit the base/handle covers onto the trike rear frame near the rear wheels.
Battery Installation Storage Battery Installation Storage Flared End Handle Cover Handle Pin Battery Compartment Door 1.5V x 3 • Loosen both screws in the battery “AA” (LR6) compartment door and remove it. • Insert three “AA” (LR6) alkaline batteries. SHOWN •...
Page 10
Rock Mode Rock Mode IMPORTANT! This product emits flashing lights between 5 - Secure the Base 30 cycles per second in some modes of operation. Base/Handle Pin Wheel Retainer Front Wheel Wheel Retainer IMPORTANT! Be sure to adjust the seat in the most Horn forward position for Rock mode.
Roll Mode Roll Mode Convert to Roll Mode IMPORTANT! This product emits flashing lights between 5 - 30 cycles per second in some modes of operation. • If you are convert- ing from the rock mode, remove Handle the handle pin from the wheel retainers and front wheel.
Ride Mode Ride Mode Convert to Ride Mode IMPORTANT! This product emits flashing lights between 5 - 30 cycles per second in some modes of operation. • If you are converting from the roll mode, remove the handle pin from the base/handle Base/Handle and the back...
