EchoStar HDT-610R Wi-Fi Quick Start Manual

Using the Remote
IMPORTANT: Remove the battery insulator tab from the remote control.
Change TV input source
(see
(see
Display text services for current
channel (if available)
View main menu for advanced
View programme guide
Display information for
channel and programme
You can register your product and
Close menu/guide and
receive the latest news on updates
and support by visiting us at:
Choose options in menus, library,
guide, settings and info bar
www.myechostar.com
Increase/decrease TV volume
(see
Customer Helpline: 0845 123 3003
Follow EchoStar on www.twitter.com/myechostar
and www.facebook.com/myechostar
Rewind/Play/Fast Forward
For further information about Freeview,
Skip Forward/Skip Back
please go to www.freeview.co.uk
Record current programme
Switch between TV and Radio
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby laboratories.
services when in Live TV
HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
The Freeview service is subject to coverage. An aerial upgrade may be required.
The FREEVIEW+HD words and logos are trademarks of DTV Services Ltd and are used
under license. © DTV Services Ltd.
Copyright © 2013 EchoStar Technologies L.L.C.
All other brand and product names are or may be trademarks of, and are used to identify
products or services of, their respective owners.
EchoStar, Beckside Design Centre, Millennium Business Park
Station Road, Steeton, Keighley, West Yorkshire BD20 6QW
Part No: 199785
TV AV
(e.g. DVD, video)
Remote Control
Blue status LED
Programming )
TV On/Standby
On/Standby
TV TV AV
Remote Control
HDT-610T on/standby
Programming )
1 2 3
., abc def Numeric keypad
Audio
Choose channel directly by number/
Display Audio menu 4
5 6 enter SMS style text in menus
ghi jkl mno
Text
7 8 9 AD
pqrs tuv wxyz
Enable Audio Description
for programme (if available)
AUDIO 0 &@_ AD
Main Menu
Subtitles
options and settings TEXT MENU SUB
Display subtitles for current
Guide
programme (if available)
GUIDE LIB
Library
Info
View recorded programme list
Mute
OK
Stop audio output from TV
Exit
(see

Remote Control Programming

Back
return to viewing
BACK
EXIT
Return to previous guide
Navigation
page or menu
Coloured buttons
Choose text and menu options
Volume
Channel
VOL PAGE CH
Remote Control
View previous/next channel
Programming )
Page
Playback control
Navigate guide or text pages
Pause/Stop/
Record
TV/R
or guide selection
TV/Radio
Remote Control Programming
The remote is capable of controlling your TV (for example, changing the volume or
putting the TV on standby). However, to be able to do this, you will need to program the
remote with a 4-digit code. This identifies the correct signals for your TV.
The User Guide, which is available for download from www.myechostar.com/support
has an extensive list of codes covering the majority of TV models.
I have the code for my TV
To program the remote:
1. Hold down both the CH+ and VOL- keys simultaneously for at
least 2 seconds. The blue LED gives two slow flashes to
indicate successful entry into the setup mode.
2. Using the numbered keys, enter the 4 digit code within 30
seconds. The LED will flash for each entry.
3. After the fourth digit entry, the blue LED gives two slow flashes to indicate that the
code has been successfully programmed.
In the event of an error, the LED gives four rapid flashes. If this occurs, you will need to
repeat this process.
)
There are several codes for my TV
Where several codes are listed by a manufacturer, it may be necessary to repeat the
above sequence with each code until the correct one is found.
I don't have a code for my TV
If you can't find the 4-digit code, or the specified code does not work, use the following
procedure to scan through all programmed remote codes.
1. Switch your TV on.
2. Point the remote at the TV. Hold down both the CH+ and VOL- simultaneously (see
above) for at least 2 seconds. The blue LED gives two slow flashes to indicate
successful entry into setup mode.
3. Press . The blue LED is turned on.
4. Press repeatedly until the TV switches off.
5. Press . The blue LED gives two slow flashes to indicate that the code has been
stored successfully.
If your TV does not turn off then it is not supported in the current revision of the remote's
database. This will be updated regularly (visit www.myechostar.com/support
information),
Ultra Slim Box
,
HDT-610R Wi-Fi

Quick Start Guide

for more
