Baxi 939 Owner's Manual

Baxi 939 Owner's Manual

Open decorative gas fire
Hide thumbs Also See for 939:
Table of Contents

Advertisement

Quick Links

See also: Installation & Owner's Manual
Model 939
OPEN DECORATIVE GAS FIRE
(GC No. 32-032-54)
We trust that this guide gives
sufficient details to enable this
appliance to be operated and
maintained satisfactorily. However, if
further information is required, our
Baxi Fires Division Technical
Helpline will be pleased to help.
Telephone 08706 061 065 (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone 0044 8706 061 065.
This guide is intended to help you care
for your Baxi Fires Division gas fire.
Please read thoroughly before using
and keep for future reference.
This guide to be left with the owner
©
Baxi Heating U.K. Limited 2006.
OWNER GUIDE
5116231/02

Advertisement

Table of Contents
loading

Related Manuals for Baxi 939

Summary of Contents for Baxi 939

  • Page 1 5116231/02 OWNER GUIDE Model 939 OPEN DECORATIVE GAS FIRE (GC No. 32-032-54) We trust that this guide gives sufficient details to enable this appliance to be operated and maintained satisfactorily. However, if further information is required, our Baxi Fires Division Technical Helpline will be pleased to help.
  • Page 2 Bathroom suites Radiators Kitchen sinks & taps Heating controls Showers Wet rooms Cylinders Towel warmers Fires Bathroom furniture Renewable energy & much more visit our website plumbnation.co.uk 0 8 4 4 8 0 0 3 4 6 0 CALL US ON...
  • Page 3 OWNER GUIDE THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20). WHEN CONVERTED USING CONVERSION KIT NO. 0595211 THIS APPLIANCE IS FOR USE WITH PROPANE GAS (G31). THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE). ©...
  • Page 4 OWNER GUIDE Safety First. Baxi Fires Division fires are CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence. At the heart of every Baxi Fires Division fire. All Baxi Fires Division fires are manufactured to the highest standards of quality and excellence and are manufactured under a BS EN ISO 9001 quality system accepted by the British Standards Institute.

  • Page 5: Table Of Contents

    OWNER GUIDE LIST OF CONTENTS Section Page SAFETY GAS CONSUMPTION APPLIANCE DIMENSIONS OPERATING THE FIRE The Oxysafe flame sensing & flue blockage safety system. To light the fire. Lighting with a taper. CLEANING Metal parts. Ceramic fuel effect. Burner. CERAMIC FUEL EFFECT REFITTING FITTING THE LOWER FIREFRONT MAINTENANCE Regular maintenance.

  • Page 6: Safety

    OWNER GUIDE SAFETY IF YOU SMELL GAS DON’T SMOKE. EXTINGUISH ALL NAKED FLAMES. DON’T TURN ELECTRICAL SWITCHES ON OR OFF. TURN OFF THE GAS SUPPLY AT THE METER. OPEN DOORS AND WINDOWS TO GET RID OF THE GAS. IMMEDIATELY CALL THE GAS EMERGENCY SERVICE FROM A NEIGHBOURS PHONE - SEE YOUR LOCAL TELEPHONE DIRECTORY.

  • Page 7: Gas Consumption

    Has a maximum natural gas input of 6.85kW (Gross) Has a minimum natural gas input of 2.3kW Model 939 when converted using kit number 0595211 Has a maximum propane gas input of 6.7kW (Gross) Has a minimum propane gas input of 4.0kW ©...

  • Page 8: Appliance Dimensions

    OWNER GUIDE APPLIANCE DIMENSIONS Firefront Dimension 'X' (mm) Dimension 'Y' (mm) Azure Quattro / Anthem Majestic Portland Figure 1. Appliance dimensions (Firefront may differ from that shown) © Baxi Heating U.K. Limited 2006. Page 7...

  • Page 9: Operating The Fire

    OWNER GUIDE OPERATING THE FIRE PLEASE NOTE When operating your fire for the first time, some vapours may be given off which may cause a slight odour and could possibly set off any smoke alarms in the immediate vicinity. These vapours are quite normal with new appliances. They are totally harmless and will disappear after a few hours use.

  • Page 10: Lighting With A Taper

    OWNER GUIDE knob slightly to release from the ‘LOW’ position and turn back (clockwise) to the Pilot ignition position. The main burner should extinguish but the pilot should remain alight. Depress the control knob slightly and turn back (clockwise) to turn OFF. This will extinguish the pilot.

  • Page 11: Cleaning

    OWNER GUIDE CLEANING Turn the fire off and allow it to cool completely before attempting any cleaning. Note that the fire will retain heat for some time after it has been turned off. If large pieces of debris are found anywhere in the fireplace, have the chimney inspected before further use.

  • Page 12: Ceramic Fuel Effect Refitting

    OWNER GUIDE CERAMIC FUEL EFFECT REFITTING The installer and owner guide for the ceramic fuel effect is separate from this guide. The installer may have attached it to this guide or placed it inside. It is important that the installer and owner guide for the ceramic fuel effect is followed correctly. If replacing the ceramic fuel effect, where a new guide is supplied, follow the installer and owner guide supplied with the replacement fuel effect.

  • Page 13: Maintenance

    OWNER GUIDE MAINTENANCE Regular maintenance. In order to achieve and maintain high levels of personal safety and performance efficiency, it is essential that the opening at the back of the fire and the flue are kept clear of any form of obstruction. It is possible that deposits of mortar or soot could fall and accumulate causing the flue to be blocked or restricted and so preventing proper clearance of dangerous exhaust fumes.

  • Page 14: Useful Telephone Numbers

    OWNER GUIDE USEFUL TELEPHONE NUMBERS General advice about gas and your gas fire: BAXI FIRES DIVISION TECHNICAL HELPLINE 08706 061 065. To report faults or arrange for your fire to be serviced: BAXI FIRES DIVISION SERVICE 08706 090 081. For sales or product information: BAXI FIRES DIVISION SALES 08706 061 067.
