Related Manuals for Power Wheels Jeep Wrangler T6138
Summary of Contents for Power Wheels Jeep Wrangler T6138
- Page 1 (tools not included). (tools not included). (tools not included). • • • Use only with the Power Wheels Use only with the Power Wheels Use only with the Power Wheels ® ® 12 Volt Lead-Acid Rechargeable 12 Volt Lead-Acid Rechargeable...
-
Page 2: Electrical Hazard
- Use of the wrong type battery or charger could cause a fi re or explosion resulting in serious injury. - Use of Power Wheels® components in products other than Power Wheels® vehicles could cause overheating, fi re or explosion. - Page 3 • If you have any questions about your Power Wheels ® children 3 years of age and older. Do not exceed the vehicle, please call our toll-free service lines at maximum weight capacity of 130 lbs (59 kg).
- Page 4 ASSEMBLED PARTS • If you experience a problem with this product, please call us at 1-800-348-0751, rather than return this product to a store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
- Page 5 ASSEMBLED PARTS Key Assembly Steering Column Cap 12 Volt Battery 12 Volt Charger Light Cover – 4 Hood Latch – 2 Spacer - 2 Dash Cap - 2 #8-32 x 1 " Screw – 2 " x 1 " Pin – 1 #10 x "...
- Page 6 ASSEMBLED PARTS Note: Some parts shown are assembled on both sides of the vehicle. Fasteners not shown. T6138pr-0920...
-
Page 7: Prevent Fire
Battery can fall out and injure battery and will void your warranty. a child if vehicle tips over. • Use only a Power Wheels ® 12 volt charger with “12V” connector (input 120 VAC, 60Hz, with an output of 12 Always use battery retainer. -
Page 8: Front View
Assembly Key Assembly WARNING Dash Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle. -
Page 9: Bottom View
ASSEMBLY " x 1 " Pin End of Steering Column Hole Steering Column • Insert the " x 1 " pin through the hole in the end of the steering column. BOTTOM VIEW • Lower the steering column so that the pin fits inside the center of the steering wheel. - Page 10 ASSEMBLY Hood Latch End of Steering Steering Column Column Slot Steering Rod Hole Hood Latch BOTTOM VIEW Slot • Turn the vehicle on its side. FRONT VIEW • Insert the end of the steering column through the hole • Insert a hood latch into one of the slots in the front in the steering rod.
- Page 11 ASSEMBLY Windshield Spacers Large Large Large Slots Grille #8 x 3" Screws • Position the windshield so that the molded detail on the wipers faces the front end of the vehicle. • Insert and “snap” the two large tabs on the windshield into the large slots in the dash.
- Page 12 ASSEMBLY Seat Short Seat Belt Strap T-Loop (Pull through slot) Seat Back Tabs Fastener End Tabs T-Loops PUSH HERE Slot Slot Seat Slot • Turn the seat upside down. SIDE VIEW • Insert the fastener end of a short seat belt strap through the slot near the outer edge of the seat.
- Page 13 ASSEMBLY Sport Bar Sport Bar Support PUSH DOWN Side Fender PULL Supports SIDE VIEW • Fit the sport bar assembly into the holes in the top side of the vehicle. • Push down firmly on a sport bar support while pulling up on the side fender to fit the sport bar into •...
- Page 14 ASSEMBLY FCC STATEMENT (United States Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 Loosen These of the FCC Rules. These limits are designed to provide Screws reasonable protection against harmful interference in a residential installation.
-
Page 15: Rear View
DECORATION • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. • Place the labels exactly as shown in the illustrations and avoid repositioning the labels • After applying a label, rub it firmly with a clean dry cloth, starting at the center, to remove any air bubbles. DASH VIEW REAR VIEW T6138pr-0920... -
Page 16: Front Left Side
DECORATION FRONT LEFT SIDE FRONT RIGHT SIDE T6138pr-0920... -
Page 17: Battery Installation
BATTERY INSTALLATION IMPORTANT! Use only a Power Wheels 12 volt battery. ® Use of any other battery will damage your vehicle. Motor Harness Connector Hood Battery Compartment Hood • Plug the motor harness connector into the battery. Latches Hood • Turn the hood latches a turn. -
Page 18: Safe Driving Rules
SAFE DRIVING RULES Before children use this vehicle, an adult should carefully RIDING HAZARD evaluate the driving area as well as the child’s skill level and ability to drive the vehicle safely. Teach appropriate WARNING safety rules to your child before allowing operation of this vehicle. -
Page 19: Vehicle Operation
VEHICLE OPERATION Advanced Use – High Speed • Help your child practice steering to learn how far and how quickly to turn the steering wheel when driving, and automatically knows how to stop. Shifter Beginner Use – Low Speed Storage Position Lock-Out Position... -
Page 20: Battery Care
Return an exhausted battery to a federal or state workmanship. The six month limited warranty applies approved lead-acid battery recycler, such as only to the 12 volt battery included by Power Wheels ® a Power Wheels® authorized service center or a local with the original purchase of the vehicle. -
Page 21: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels Consumer Relations, or your local Power Wheels ® ®... - Page 22 Even with proper care, a rechargeable battery does not last forever. accept full charge Average battery life is 1 to 3 years depending on vehicle use and use conditions. Replace only with a Power Wheels® 12 Volt battery with built-in thermal fuse. Do not substitute parts. Tripped thermal fuse The built-in thermal fuse may “trip”...
- Page 23 Motor or electrical Contact your local Power Wheels® authorized service center for switch damage diagnosis and repair. When the foot pedal is Loose wire or connector Check all wires around the motors and all connectors the vehicle pressed, the vehicle won’t...
- Page 24 We're a toll-free phone call away, and we can help. If you are missing parts or need assistance, please call: 1-800-348-0751 Or contact your local independently owned and operated Power Wheels Authorized Service Center. ® For the location nearest you, visit us on-line at www.powerwheels.com.
