SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
R410A
[Model names]
SUZ-KA25VA3
SUZ-KA35VA3
SUZ-KA50VA3
SUZ-KA60VA3
SUZ-KA71VA3
SUZ-KA25VA3.TH
SUZ-KA35VA3.TH
[Service Ref.]
SUZ-KA25VA3.TH
SUZ-KA35VA3.TH
SUZ-KA60VA3.TH
SUZ-KA71VA3.TH
Indication of
model name
NOTE:
• This service manual describes
technical data of the outdoor
units.
CONTENTS
2. TECHNICAL CHANGES .................................... 3
3. PART NAMES AND FUNCTIONS ...................... 6
4. SPECIFICATION ................................................. 7
5. NOISE CRITERIA CURVES ............................... 9
6. OUTLINES AND DIMENSIONS ........................ 10
7. WIRING DIAGRAM ........................................... 12
8. REFRIGERANT SYSTEM DIAGRAM .............. 15
9. ACTUATOR CONTROL .................................... 18
10. SERVICE FUNCTIONS ..................................... 19
11. TROUBLESHOOTING ...................................... 19
12. DISASSEMBLY INSTRUCTIONS ..................... 49
PARTS CATALOG (OCB530)
October 2012
No.OCH530
HFC
utilized
R410A
