METAL WORK STATION
42606
ASSEMBLY & OPERATING INSTRUCTIONS
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
©
®
Copyright
2000 by Harbor Freight Tools
. All rights reserved. No portion of this manual or any
artwork contained herein may be reproduced in any shape or form without the express written
consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Related Manuals for Harbor Freight Tools 42606
Summary of Contents for Harbor Freight Tools 42606
- Page 1 AND INSTRUCTIONS BEFORE USE. © ® Copyright 2000 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
-
Page 2: Technical Specifications
THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the owner’s record below: Model___________ Serial No._____________ Purchase Date_____________ Save This Manual You will need the manual for the safety warnings and precautions, assembly instructions, operating and maintenance procedures, parts list and diagram. - Page 3 When unpacking, check to make sure all the parts shown on the Parts List on page 10 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible.
-
Page 4: Right Hand Drawer Slide
Figure 1. Slide Panel and Drawer Assembly Slide stop 14-3/4” Panel Slide (1& 2) Guide Guide Guide hole in end Spring Drawer Slide w/Spring (5) Figure 1 SKU 42606 For technical questions, please call 1-800-444-3353. Page 4... -
Page 5: Spring Slide
The tip of the Spring works to secure the Drawers (7) in the Drawer Slides. REV 09/05 SKU 42606 For technical questions, please call 1-800-444-3353. Page 5... - Page 6 Slide the Slide Panel (6) down inside the rail of the Side Panel (9) making certain that the Drawer Slides face inward. Attach the Slide Panel (6) to the Side Panel (9) using four 1/4" Bolts, Lock Washers and Hex Nuts (17). SKU 42606 For technical questions, please call 1-800-444-3353. Page 6...
-
Page 7: Corner Brace Support
Corner Brace Support (8) rest against the Bottom Rail (11) and Side Panel (9). Secure in place with Bolt, Lock Washer and Hex Nut (17) -see Figure 8 next page. SKU 42606 For technical questions, please call 1-800-444-3353. -
Page 8: Back Wall Panel
Align the holes in the second Back Wall Panel (12) at each corner at the rear of the Shelves (14). Secure in place with Bolt, Lock Washer and Nut (17). SKU 42606 For technical questions, please call 1-800-444-3353. Page 8... -
Page 9: Please Read The Following Carefully
CENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. SKU 42606 For technical questions, please call 1-800-444-3353. Page 9... -
Page 10: Parts Diagram
Parts Diagram NOTE: Some parts are listed and shown for illustration purposes only and are not available indi- vidually as replacement parts. REV 09/05 SKU 42606 For technical questions, please call 1-800-444-3353. Page 10... -
Page 11: Assembly Diagram
17 ......1/4" x 1/2" Bolt, Lock Washer, Hex Nut (not shown) ..60 18 ......5/8" hex Screw (not shown) ..........4 Note: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. REV 09/05 SKU 42606 For technical questions, please call 1-800-444-3353. Page 11...
