Pacific hydrostar 95618 Set Up And Operating Instructions Manual

6 hp gas pressure washer
Hide thumbs

Advertisement

Table of Contents

6 HP Gas Pressure Washer
Set uP And OPerAtinG inStructiOnS
Due to continuing improvements, actual product may differ slightly from the product described herein.
read this material before using this product.
Failure to do so can result in serious injury.
SAVe tHiS MAnuAl.
Copyright
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
Diagrams within this manual may not be drawn proportionally.
distributed exclusively by Harbor Freight tools
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
2007 by Harbor Freight Tools
©
95618
. All rights reserved. No portion of this
®
.
®

Advertisement

Table of Contents
loading

Related Manuals for Pacific hydrostar 95618

Summary of Contents for Pacific hydrostar 95618

  • Page 1 6 HP Gas Pressure Washer Model 95618 Set uP And OPerAtinG inStructiOnS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. distributed exclusively by Harbor Freight tools ®...

  • Page 2: Specifications

    Gasoline fuel and fumes are flammable and potentially explosive. Use proper fuel handling procedures. Always have multiple ABC class fire extinguishers in the area when handling fuel. reV 07c Page 2 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 3 The handles must be kept clean, dry, and free from oil and grease at all times. turn OFF power . Turn OFF engine and water supply when not in use. Page 3 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 4 Damage to the hose may occur possibly causing the hose to burst or leak under high pressure. Page 4 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 5 It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator. Page 5 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 6 13 and 14 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual. REV 07d, 08a Page 6 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 7 (included) that has a small breather hole in it. That breather plug must be used whenever the Pressure Washer is used. The white plastic plug (without the breather hole) should be used when transporting only. REV 08a Page 7 SKU 95618 For technical questions please call 1-800-444-3353...
  • Page 8 Coil the High Pressure Hose (44) and hang it on the Hose Bracket (8). Hang the Spray Gun on the Gun Bracket (14). Connect a garden hose water supply to the garden hose connector. Page 8 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 9: Using Detergent

    Slide the Spray Nozzle out for low pressure. The pressure washer will draw the detergent up through the Detergent Suction Hose (46) and mix the water and detergent automatically, at about a 6% detergent 94% water ratio. See Figure d. Page 9 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 10: Engine Setup

    Fuel Tank Oil Cap Remove Gas Cap and fill the Fuel Tank with unleaded gasoline. Do not over- fill. Be careful not to spill gasoline. Clean any spills before starting engine. Page 10 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 11: Operation

    Turn the Speed Control Lever (C) to the right, or stop position. The engine will stop. Turn the Fuel Valve (D) up to the left, or closed position (see photo page 9). Page 11 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 12: Cleaning Recommendations

    If several different surfaces are to be cleaned, be careful not to damage any of the less solid surfaces while trying to clean the harder ones. This is espe- Page 12 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 13: Maintenance

    Many maintenance procedures will need to be performed by a qualified technician. REV 07d, 08a Page 13 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 14: Troubleshooting

    Open faucet all the way Water inlet screen is clogged Remove inlet screen and rinse out Nozzle is clogged Remove nozzle and clean Nozzle has mineral build up Remove nozzle and clean with vinegar Page 14 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 15: Assembly Drawing

    Assembly drawing Note: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. Page 14 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 16: Parts List

    ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 14 SKU 95618 For technical questions please call 1-800-444-3353...

  • Page 17: Limited 1-Year Warranty

    This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 Page 15 SKU 95618 For technical questions please call 1-800-444-3353...
