Manual No. INVO-1
08/11 invo-.man
NORTH AMERICA • 3900 Coral Ridge Drive, Coral Springs, Florida 33065, USA • Tel: +1 954-346-2442 • Fax: +1 954-340-7901 • sales@unipower-corp.com
EUROPE • Parkland Business Centre, Chartwell Road, Lancing BN15 8UE, ENGLAND • Tel: +44(0)1903 768200 • Fax: +44(0)1903 764540 • telecom@unipower-europe.com
OPERATING MANUAL
INVO Series
5KVA INVERTER / CHARGER
INVC4850H – 48V Battery
INVC9650H – 96V Battery
WWW.UNIPOWERCORP.COM
UNIPOWER Corporation
© 2011 UNIPOWER Corp.
All Rights Reserved
Advertisement
Table of Contents
Related Manuals for Unipower INVC4850H
Summary of Contents for Unipower INVC4850H
- Page 1 UNIPOWER Corporation NORTH AMERICA • 3900 Coral Ridge Drive, Coral Springs, Florida 33065, USA • Tel: +1 954-346-2442 • Fax: +1 954-340-7901 • sales@unipower-corp.com EUROPE • Parkland Business Centre, Chartwell Road, Lancing BN15 8UE, ENGLAND • Tel: +44(0)1903 768200 • Fax: +44(0)1903 764540 • telecom@unipower-europe.com...
- Page 2 INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Page 2 Manual No. INVO-1 08/11 invo-man...
-
Page 3: Table Of Contents
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Contents ABOUT THIS MANUAL ....................... 4 Purpose ..............................4 Scope ..............................4 IMPORTANT SAFETY INSTRUCTIONS ................... 4 General Precautions ..........................4 Personal Precautions .......................... 5 INSTALLATION ..........................6 Unpacking and Inspection ......................... 6 Basic Configuration .......................... -
Page 4: About This Manual
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL ABOUT THIS MANUAL Purpose The purpose of this manual is to provide explanations and procedures for installation, operation and troubleshooting. This manual should be read carefully before installation and operation. Please retain this manual for future reference. Scope This document defines the functional requirements of the inverter/charger, which is intended for worldwide use in electronic data processing applications. -
Page 5: Personal Precautions
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL 8. No terminals or lugs are required for hook-up of the AC wiring. AC wiring must be no less than 10 AWG gauge copper wire and rated for 75 C or higher. Battery cables must be rated for 75 C or higher and should be no less than as stated in table 1. -
Page 6: Installation
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL INSTALLATION Unpacking and Inspection Carefully unpack the inverter/charger from its shipping carton. Verify all of the items listed below are present. Please call customer service if any items are missing: The Inverter/Charger ... -
Page 7: Batteries
GEL/AGM lead-acid batteries so ensure that your batteries are in one of these categories. The battery must be wired to match the inverter/chargers DC input voltage specifications. We recommend that the battery capacity not smaller than 100AH (INVC4850H) / 50AH (INVC9650H). Figure 2.1 - INVC5048H battery string wiring Figure 2.2 - INVC5096H battery string wiring... -
Page 8: Dc Disconnect And Over-Current Protection
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL DC Disconnect and Over-Current Protection For safety and to comply with regulations, battery over-current protection and disconnect devices are required. Fuses and disconnects must be sized to protect the DC cable size used, and must be rated for DC operation. -
Page 9: Ac Cable Size
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL AC Cable Size Before wiring the input and output of the inverter, refer to table 2 for minimum recommended cable sizes and torque values. Model Number AC Input AC Output Torque value INVC5048H 10AWG 10AWG 1.2~1.8 Nm... - Page 10 INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL 4. Connect the AC Line output wiring to the terminal marked AC Line (output) following the wiring guide inside the compartment. Connect the AC neutral out to the AC neutral out terminal. Torque the wires into the terminal block.
-
Page 11: Operation
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL OPERATION Front Panel Controls and LCD Indicators Figure 5 shows the controls and indicator lights on the front of the INVO Series inverter/charger. They control and provide information in both inverter and battery charging modes of operation. LCD indicator On/Off Configuration switches... -
Page 12: Lcd Indicator
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL LCD Indicator The LCD display provides system status, and the user-friendly panel eases program settings. See Figure Figure 6 - LCD display interface AC Mode Indicator The line mode symbol will show and the indicator will display the input voltage, output voltage and load. -
Page 13: Battery Charger
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Load indicator The load indicator shows the load percentage in VA or W, whichever is bigger, the overload indicator will flash when an overload is present. Battery Charger Inverter to Charger Transition The internal battery charger and automatic transfer relay allow the inverter/charger to operate as either a battery charger or an inverter (but not both at the same time). -
Page 14: Specifications
INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL SPECIFICATIONS Table 5 - Line Mode Specifications MODEL INVC5048H INVC5096H Input Voltage Waveform Sinusoidal (Utility or Generator) Nominal Input Voltage 230Vac 170Vac (Normal) Low Line Disconnect 90Vac (Generator / Wide Range) 180Vac (Normal) Low Line Reconnect 100Vac (Generator / Wide Range) High Line Disconnect... - Page 15 INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Table 6 - Inverter Mode Specifications MODEL INVC5048H INVC5096H Output Voltage Waveform Pure Sine Wave Rated Output Power 5,000VA Power Factor 0.84 Nominal Output Voltage 230Vac Output Frequency 50Hz / 60Hz ± 1Hz Output Voltage Regulation ±10% rms Nominal Efficiency...
- Page 16 INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Table 7 - Charge Mode Specifications MODEL INVC5048H INVC5096H Nominal Input Voltage 230Vac 180V~ 270Vac (Normal range) Input Voltage Range 100V~ 270Vac (Generator / Wide Range) Nominal Output Voltage Determined by battery type 20A(95-175V, gen/wide only) 10A(95-175V, gen/wide only) Nominal Charge Current...
- Page 17 INVO SERIES INVERTER/CHARGER INSTALLATION & OPERATING MANUAL Table 8 - General Specifications Safety Certification CE(EN60950) EMI Classification EN62040-2, CLASS A Operating Temperature Range 0°C to 45°C Storage temperature -15°C ~ 60°C Altitude, operational Elevation: 0 ~ 1500 Meters Relative humidity 5% to 95% non-condensing Audible Noise 60dB max.
-
Page 18: Troubleshooting
No LCD display 3. Power switch is not pressed 3. Press and hold power switch 4. Battery polarity reversed Can’t start up the 4. Return to UNIPOWER for repair inverter/charger 1. AC input missing 1. Check AC input connections Mains normal but operates in inverter mode 2.
