Menu 3 - Remote start

Menu Feature
Item
1 Transmission Mode
2 Engine Checking Mode
3 Cranking Time
4 Remote Start Runtime
5 Activation Pulse Count
6 Turbo Mode
7 Timer Mode Runtime
8 Flex Relay Function
9 Diesel Start Delay
10 Accessory during Diesel Start
Delay
11 Status 2 Output
12 Parking Light Output
13 Anti-grind Output
14 Tach Mode Starter Release
15 Vehicle Temp
Auto Report
16 Remote Start Safelock
1. Transmission Mode
1. Manual: requires 'Tachometer' for the Engine Checking Mode, and requires the user to successfully
perform a procedure when parking the vehicle before remote starter will engage
2. Automatic: uses any of the Engine Checking Modes and does not require any special procedures
when parking
2. Engine Checking Mode
1. VirtualTach: battery voltage drop/rise during cranking determines when the starter output is released.
During runtime, constant voltage level is monitored to determine if the engine is running
2. Voltage: starter output during cranking is a programmed duration (Set in Cranking Time). During
runtime, constant voltage level is monitored to determine if the engine is running
3. Off: starter output during cranking is a programmed duration (Set in Cranking Time). The remote start
will keep the ignition/accessories active for the programmed runtime whether the engine is running
or not
4. Tachometer: tachometer input signal during cranking and runtime to determine when the starter out-
put is released and if the engine is running.
3. Cranking Time
• 0.6/0.8/1.0/1.2/1.4/1.6/1.8/2.0/4.0 seconds: determines the starter output duration during
cranking for the 'Voltage' and the 'Off' Engine Checking Mode options
4. Remote Start Runtime
• 12/24/60 minutes: sets engine runtime during normal remote start operations
5. Activation Pulse Count
• 1/ 2 pulses: sets the number of remote control commands received or Activation Input required to
activate and de-activate remote start
Opt. 1 Opt. 2
Automatic
Manual
Virtual Tach Voltage
0.6 sec. 0.8 sec.
12 min. 24 min.
2
1
No Turbo Mode On-1 min.
3 min.
12 min.
Ignition 2 Accessory 2
Wait-to Start Timed 15 sec.
input
Off
On
Latch Rear
Status
Defogger
Pulsed
Constant
On Off
Normal Increase
Off On
Off On
Opt. 3 Opt.4
Off Tachometer
1.0 sec. 1.2 sec.
60 min.
On-3 min. On-5 min.
6 min. 9 min.
Starter 2
Timed 30 sec. Timed 45 sec.
Pulse Rear
Defogger
Off
Decrease
Opt. 5+
1.4 (5)/ 1.6
(6)/ 1.8 (7)
2.0 (8)/ 4.0
(9)
On- 10 min.
