DutchWest DW1000L02 Owner's Manual

Epa certified high efficiency wood stove
Hide thumbs Also See for DW1000L02:
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

D
UTCH
This manual describes the installation and operation of the DW1000L02, DW1500L02
and DW2000L02 non-catalytic, wood heaters. This heater meets US Environmental
Protection Agency emission limits for wood heaters.
SAfEty NotiCE
Read this entire manual before you install and
use your appliance.
If not properly installed, a house fire may result.
To reduce the risk of fire, follow the installation
instructions.
Failure to follow instructions may result in prop-
erty damage, bodily injury or even death.
Contact local building, fire officials or authori-
ties having jurisdiction about permits, restric-
tions and installation inspection requirements in
your area.
This stove is listed by OMNI-Test Laboratories of Port-
land, Oregon to meet UL1482 for the US and ULC-627
for Canada
Do Not Discard this Manual: Retain for future Use
Models:
DW1000L02
DW1500L02
W
EST
DW2000L02
EPA Certified High
Efficiency Wood
Stove
owner's Manual
for Residential installation
6" flue required
30004580 3/10 Rev. 5

Advertisement

Table of Contents
loading

Related Manuals for DutchWest DW1000L02

Summary of Contents for DutchWest DW1000L02

  • Page 1 Residential installation Models: DW1000L02 DW1500L02 UTCH DW2000L02 This manual describes the installation and operation of the DW1000L02, DW1500L02 and DW2000L02 non-catalytic, wood heaters. This heater meets US Environmental Protection Agency emission limits for wood heaters. 4580 DW1000 COVER SAfEty NotiCE Read this entire manual before you install and use your appliance.

  • Page 2: Before Installation Of Your Appliance

    DW1000/15000/2000 Today’s solid fuel appliances are much more efficient CAUtioN than in the past. The units are designed to give you controlled combustion, as well as maximum heat trans- After reading these instructions, if you have any doubt fer, using less fuel to do so. about your ability to complete your installation in a professional like manner you should obtain the services The design of your new appliance is such that the...
  • Page 3 DW1000/1500/2000 Figure 1 Stove Dimensions 10 ” (267 mm) Model DW1000L02 29” 26C\v” 17Z\x” 20Z\x” 24C\,” 10C\v” 23C\v” 737 mm 679 mm 445 mm 521 mm 619 mm 273 mm 603 mm 4580 DW1500L02 30” 27C\v” 17C\v” 22Z\v” 28C\v” 10C\v”...

  • Page 4: Installation

    2) The stove must be installed on a noncombustible surface as shown on Page 7, Figure 4. This Homeowner’s Manual describes the instal- lation and operation of the models: DW1000L02, 3. If noncombustible materials have been installed on DW1500L02, DW2000L02 non-catalytic wood heater.

  • Page 5: Item Description

    DW1000/1500/2000 2 Full Bricks (Be sure to install two (2) full bricks in baffle as shown) 2  2  Baffle Assembly 1  1  3  3  3  3  1  1  1  1  6  1  1  1  4  Figure 3 Fire Brick Installation 2 ...
  • Page 6 DW1000/15000/2000 Stove Pipe 2“ (51 mm) 2“ (51 mm) Wall Line 1. A clearance of 18” (457 mm) between the stovepipe and combustible materials may be required. Check Chimney Connector with authorities having jurisdiction in your area. 2. All pipe sections must be connected with the male 8”...

  • Page 7: Operation

    DW1000/1500/2000 Do Not BURN: Treated Wood Solvents Trash Coal 2’ (610 mm) Higher 3’ (1 m) Min. Garbage Cardboard Colored Paper than Nearest Point of from Roof Roof within 10’ (3 m) instructions for first Burn - Curing the Stove Paint Penetration Your stove has been painted with the highest quality stove paint and has special break-in procedures.

  • Page 8: Glass Care

    Since so many variables affect performance, consult your Dutchwest Authorized Dealer to determine realistic expectations for your home.

  • Page 9: Ash Disposal

    DW1000/1500/2000 all combustible materials, pending final disposal. If Creosote the ashes are disposed of by burial in soil or otherwise When wood is burned slowly, it produces tar and other locally dispersed, they should be retained in the closed organic vapors. These combine with moisture to form container until all cinders have thoroughly cooled.

  • Page 10: Environmental Conditions

    DW1000/15000/2000 2. What type of wood is best to use as firewood? chimney can be either outside the home, inside the home or both. Outside the home, a high-pres- Dry seasoned hardwood should be used. Avoid sure day (clear and cool) generally creates a bet- green unseasoned wood.
  • Page 11 DW1000/1500/2000 8  6  7  9  1  5  10  13  3  4  14  2  11  12  UTCH MHSC reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. DW1000 Series, DW1500 Series, DW2000 Series Wood Stoves item Description Qty.
  • Page 12 DW1000/15000/2000 DW1000 Series, DW1500 Series, DW2000 Series Wood Stoves (continued) item Description Qty. DW1000 DW1500 DW2000 1/4” Spring Handle 90000070 90000070 90000070 Ash Drawer S31331 S31333 S31336 Leg Casting S25076 S25080 S25084 Ashfender S25077 S25082 S25082 Airmate S25088 S25092 S25093 Removable Rear Heat Shield 90000037 90000038...

  • Page 13: Limited Lifetime Warranty

    The appliance has been subjected to willful or accidental the original owner and residential use. abuse or misuse. 1. The new Dutchwest product must be installed and operated at all • Corrosive driftwood, manufactured logs or other fuels are used other than as outlined in the installation and operating times in accordance with the installation and operation instruc- instructions.
  • Page 14 DW1000/15000/2000 Approuv par l’EPA comme pole  bois haute performance Guide du propritaire Pour installation rsidentielle Modles: DW1000L02 DW1500L02 UTCH DW2000L02 AViS DE Scurit Lisez le guide en entier avant d’installer et d’utiliser votre pole. W1000 Une installation inadquate pourrait occasion- ner un incendie.
  • Page 15 DW1000/1500/2000 Mise En Garde fonctionnement prcaution Aprs avoir lu ces instructions, si vous avez des doutes Pourquoi un conduit d’vacuation de 6 po (152 quant  votre capacit de faire toute l’installation d’une mm)? manire professionnelle, vous devriez retenir les servic- Le tirage est le dplacement de l’air dans le conduit d’ es d’un installateur qui s’y connat relativement  tous vacuation et la chemine, vers l’exterieur.
  • Page 16 CAUSES  SoN CoNtACt. iL fAUt tRE PARtiCULiREMENt PRUDENt EN PRSENCE D’ENfANtS. Figure 1 Dimensions du pole 10 ” 267 mm (267 mm) (10Z\x po) Modle DW1000L02 737 mm 679 mm 445 mm 521 mm 619 mm 273 mm 603 mm (29 po) (26C\v po)
  • Page 17 Cette guide du propritaire dcrit l’installatin et d gagement minimales respecter par rapport aux l’utilisation des modles DW1000L02, DW1500L02, mati res combustibles. Le po le doit tre install sur DW2000L02 de poles  bois non catalytiques. Cet une surface non combustible. ( la page 21, Fig. 4) appareil de chauffage rpond aux limites d’mission de...
  • Page 18 DW1000/15000/2000 2 briques complte (assurez-vous d’installer deux briques compltes dans le dflecteur qu’indiqu 2  2  Dflecteur 1  1  3  3  3  3  1  1  1  1  6  1  1  1  4  Srie de DW1000 Figure 3 Fire Brick Installation Srie de DW1000 et DW1500 2 ...
  • Page 19 DW1000/1500/2000 tuyau  fume 51 mm (2 po) 2“ (51 mm) 51 mm (2 po) 2“ (51 mm) 1. Prvoyez au moins 18 po de dgagement entre le Ligne du mur tuyau  fume et les autres matraux combustibles. Connecteur de la chemine Vrifier avec les autorits ayants juridiction dans votre rgion.
  • Page 20 DW1000/15000/2000 au-dessus du point d’entre dans la toiture et au Bois moins  (610 mm) 2 pi au-dessus de tout point de la Cet appareil est conu pour la combustion de bois na- couverture situ dans un rayon de 3 m (10 pi). turel seulement.
  • Page 21  votre rsidence. Comme il existe quantit de variables qui effecient la rendement, Consultez votre distributeur autoris de proudiuts Dutchwest afin de dterminer les valeurs probables pour votre rsidence. 3. Dans les conditions spcifiques runies au cours des essais effectus pour mesurer les missions selon les normes de l’Agence pour la protection de l’environnement des tats-Unis.
  • Page 22 DW1000/15000/2000 non abrasif devrait suffire. Autrement, utilisez un Si elle s’enflamme, la crosote produit un feu intense. nettoyant pour le four. Inspectez la chemine rgulirement pendant la saison du chuffage pour dterminer s’il y a accumulation de 5. Ne jamais mettre dans l’appareil une substance qui crosote.
  • Page 23 DW1000/1500/2000 bien  distance de tout matriau combustible, en at- a suffisamment d’espace dans la chambre  com- tendant l’limination finale. Si la cendre doit tre enfoule bustion. Rglez la commande d’admission d’air  dans le sol ou disperse en surfacxe, elle doit d’abord la positoni dsire.
  • Page 24 DW1000/15000/2000 queront des dpts de suie sur le verre. Une fois c. tempratures froides dans la chemine que la temprature de la chambre  combustion et le Conservez un eu vif pendant les quinze  quar- tirage augmentant, la sule brlers. ante premires minutes, sans exagrer.
  • Page 25 DW1000/1500/2000 8  6  7  1  9  5  10  13  3  4  14  2  11  12  UTCH MHSC se rserve le droit de faire des changements en ce qui concerne la conception, les matriaux, les spcifications et les prix et de discontinuer des couleurs et des produits  tout moment sans pravis.
  • Page 26 DW1000/15000/2000 Pole  bois Sries DW1000, DW1500 et DW2000 (seule) Description Qte. DW1000 DW1500 DW2000 Poigne  ressort1/4 po 90000070 90000070 90000070 Tiroir  cendres S31331 S31333 S31336 Pattes moules S25076 S25080 S25084 Garde-feu S25077 S25082 S25082 Convecteur S25088 S25092 S25093 cran arrire dtachable 90000037...
  • Page 27 MHSC garantit que les poles  bois en fonte ou les foyers  bois en pierres 6. Toutes les autres garanties - expresses ou implicites - relatives au de marque Dutchwest sont exemple de tout dfaut de fabrication et de mat produit,  ses compaosantes et accessoires ou  toute obligation ou...
  • Page 28 MHSC 149 Cleveland Drive • Paris, Kentucky 40361 www.mhsc.com...
