This service manual describes the latest technical
information for the IC-F3001/F3002/F3003/F3006/F3008
VHF TRANSCEIVERS TRANSCEIVER, at the time of
publication.
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without notice
or obligation.
MODEL
IC-F3001
IC-F3002
IC-F3003
IC-F3006
IC-F3008

ORDERING PARTS

Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1110003491 S.IC
8820001210 Screw 2438 screw
Addresses are provided on the inside back cover for your
convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
fineline6
INTRODUCTION
CHANNEL
VERSION SPACING
(kHz)
USA-11
USA-12 15.0/25.0
USA-13
EUR-21
EUR-22
EUR-23
15.0/20.0/25.0
UK-01
UK-02
UK-03
EXP-11
EXP-12
EXP-13
EXP-21
EXP-22
EXP-23
EXP-01
EXP-03
15.0/25.0
EXP-31
AUS-21
AUS-22
AUS-23
RUS-21
RUS-22
RUS-23
CHN-31
TA31136FNG IC-F3001 MAIN UNIT
IC-F3003 Top cover
NEVER connect the transceiver to an AC outlet or to a DC
power supply that uses more than the specified voltage.
This will ruin the transceiver.
DO NOT expose the transceiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the transceiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW) to
the antenna connector. This could damage the transceiver's
FREQUENCY
front-end.
RANGE
(MHz)
136–174
1. Make sure that the problem is internal before
disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts.
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
transceiver is defective.
5 pieces
6. DO NOT transmit power into a Standard Signal
10 pieces
Generator or a Sweep Generator.
7. ALWAYS connect a 50 dB to 60 dB attenuator between
the transceiver and a Deviation Meter or Spectrum
Analyzer, when using such test equipment.
8. READ the instructions of the test equipment throughly
before connecting it to the transceiver.
CAUTION

REPAIR NOTES

(IC-F3001)
An
