Smeg DWAI149X Quick Start Manual

DWAI149X
EAN 8017709151614
size 598mmW x 868mmH maximum x
570mmD
capacity 14 placesettings
finish stainless steel control panel —
carpentry door panel to be added
programs five —
soak,normal ECO 45ºC, ECO 50ºC,
intensive 65ºC, Ultraclean
wash temperatures 45,50,65,70ºC
baskets grey rilson
upper: 3-level adjustment, EasyGlide
lower: single tilting rack
wash system orbital
upper spray arm
six wash directions
drying natural condenser
timer 3-6-9 hour delay timer
filtration 5-stage water filtration system
safety TOTAL ACQUASTOP
LED on/off light
end-cycle acoustic indicator
self-balancing hinges
noise 45 dBA
water 12.6 litres
energy 1.9 kWh, 10 amps
230-240V, 50Hz
smeg semi-integrated dishwasher
30cm
maximum
plate
diameter
ORBITAL WASH SYSTEM
Smeg's orbital wash system has two spray arms which
operate simultaneously in opposite directions to ensure
water is evenly distributed throughout the inner cavity for a
perfect wash.
DELAY START TIMER
Delay Start option allows for up to 24-hours delay start —
allowing you to take advantage of off-peak energy usage
times.
TOTAL ACQUASTOP
Acquastop is a water safety device that operates when the
dishwasher is not in operation by restricting mains pressure
at the tap, and not at the dishwasher.

 

 Flexi Tabs
Delay
SAVE ON ENERGY AND PROTECT THE ENVIRONMENT
6 always try to run the dishwasher full loaded
6 do not wash dishes in running water
6 use the washing program that is most appropriate for
each type of load
6 do not carry out any preliminary rinsing
6 if available, connect the dishwasher to a hot water
supply up to 60°C
The phosphates contained in dishwasher detergents are
harmful to the environment. To avoid using excessive
amounts of detergent and to save on electricity, observe
the following:
6 separate the more delicate items from dishes that
are more resistant to aggressive detergents and high
temperaures;
6 do not pour the detergent directly onto the dishes.
The more
stars the more
The more
energy efficient
stars the more
E N E R G Y
water efficient
W A T E R
RATING
RATING RATING
A joint government and industry program
Smeg dishwasher Model DWA149*/DWA147*/DWAU149*/DWAI149*/
DWAU149*N/DWAU147*/DWAFI149/DWAU149*O
A joint government and industry program 14 place settings
Smeg dishwasher Model DWA149*/DWA147*/DWAU149*/DWAI149*/
Energy consumption
DWAU149*N/DWAU147*/DWAFI149/DWAU149*O
14 place settings 264
Water consumption
12.6
kWh per year
Cold water connection, using
Normal Eco seven times per week
Litres per wash
When tested in accordance with STANDARD AS/NZS 2007.2.
Using Normal Eco program Actual energy use and running costs will depend on how you use the appliance
Energy consumption with hot
When tested in accordance with STANDARD AS/NZS6400.
water connection 345 kWh per year
For more information and to compare
appliances, refer to: For more information, refer to:
www.energyrating.gov.au
www.waterrating.gov.au
ID080812
Code DWAI149X
