What's Included in the box
□ CMR-986 Mini-N Broadband Router
□ Quick Installation Guide
□ User Manual on CD-ROM
Step 1: Device Setup
Switch to Router mode. Connect power and insert a
USB modem. Insert one end of the Ethernet cable to
the LAN port and the other end to your PC.
3
. USB Modem
4
. Ethernet cable to PC
Step 2: Login
On your PC or laptop, open web browser
and type http://192.168.1.1 into the Address
bar. Press Enter.
When login screen appears, type admin for
both Username & Password. Click Login
button to continue.
Step 3: Connect to the Internet
Through 3.5G USB Modem
Click on One Button Setup from the left
navigation pane.
Insert your 3.5G USB Modem into the USB
port. Select 3.5G usb dongle in WAN
interface drop-down menu. Fill in
information provided by your 3G service
provider. Click Finish button to finish setup
process. The router will be restarted
shortly. Once the login page shows up, you
are ready to surf the Internet!
Note: APN & Phone Number are required.
User Name & Password can be optional.
The common APN name is internet and the
phone number is *99#.
Quick Installation Guide
2
. Connect one of the power sources
DC IN / 5V
DC 5V1000mA
Note: Only 5V allowed
1
Switch
.
to Router
AC 100-240
Connect to the Internet through 3.5G USB Modem
CMR-986
Mini-N Broadband Router
Innovative & Multi-purpose
Battery Pack
USB Car Charger
USB Cable to PC
OR
Electrical Outlet
Advertisement
Related Manuals for CNET CMR-986
Summary of Contents for CNET CMR-986
-
Page 1: Quick Installation Guide
What’s Included in the box CMR-986 □ CMR-986 Mini-N Broadband Router Mini-N Broadband Router □ Quick Installation Guide Innovative & Multi-purpose □ User Manual on CD-ROM Quick Installation Guide Step 1: Device Setup . Connect one of the power sources Switch to Router mode. -
Page 2: Technical Information
If your USB modem is not working with the router. Check the support list to ensure you are using a supported device. CNet’s supported device list changes regularly. We update our supported device list after a device is approved. If the device you have is not on the list, that means we do not support it at this time.
