Vauxhall MY14 ASTRA Quick Start Manual

Air Vent Driver Information Centre
1 6
Infotainment Display Display Dials
2 7
Radio Controls Steering Wheel Controls
3 8
Climate Controls Bonnet Release
4 9
Cruise Controls Lighting Controls
5 10
Infotainment Controls:
Want to take a call safely, or
need to find your way home?
Infotainment has everything in
one clear location to help.
Vehicle Personalisation Audio
PERSONALISATION: RADIO - SETTING UP PRE-SETS:
Various Vehicle, comfort and Infotainment system Using the integrated audio system you
settings can be separately memorised for each can easily add and organise your favourite radio
stations. Choosing a soundtrack for your journey is
driver, of the car, based on their individual key.
only a touch away.
By removing the vehicle's key from the ignition,
some settings are automatically saved to the MANUALLY STORE:
individual key. PRESS: RADIO to open the radio main menu
ACTIVATING/DEACTIVATING PRESS: RADIO again to switch to another
PERSONALISATION: waveband
PRESS: CONFIG button to open PRESS: Search buttons << or >> to search
the system settings menu for the available stations. When the desired
frequency has been reached, the station is
SELECT: Vehicle settings
played automatically.
SELECT: Comfort settings
TAP: AS button to open the autostore list
SET: Personalisation by driver to On or Off
PRESS: The number (1-6) button you would
EDITABLE SETTINGS INCLUDE:
like to save the station to until a confirmation
• Lighting preferences
message is displayed
• Infotainment system settings
AUTOMATIC STATION STORING:
• Central locking system
For quick setup you can have the 12 strongest
• Sport mode, comfort settings and more.
stations on the current wave band identified and
Note: Refer to Owner's Manual for more detail.
stored automatically.
Editable settings depending on vehicle equipment
PRESS: AS button until the autostore
message is displayed
The 12 strongest stations in the current waveband
are stored in the two autostore lists.
*Manually stored stations are overwritten in an
automatic station storing process
5
1 2 3 4
Bluetooth
®
*where fitted
MOBILE DEVICE - ACTIVATING BLUETOOTH
First, connect your mobile device to the Infotainment
system. Let's get your mobile device and car
communicating.
TO CONNECT YOUR MOBILE DEVICE:
Activate: Bluetooth ® on your mobile device.
PRESS: CONFIG button and select the Phone Settings
menu item and then Bluetooth
®
ACTIVATING BLUETOOTH
If the Bluetooth ® function of the Phone portal is deactivated:
set Activation to On and confirm the subsequent message.
DEVICE LIST
When a mobile phone is connected to the Phone portal via
Bluetooth ® for the first time, the mobile phone is stored
in the device list.
CONNECTING A MOBILE PHONE AS
A HANDS FREE DEVICE
SELECT: Bluetooth menu and chose Add Device
®
(hands free). The Bluetooth code to be entered into the
®
mobile phone is displayed.
As soon as the mobile phone is detected in the Phone
portal the Bluetooth code can be entered into the
®
mobile phone and the connection set-up confirmed.
The mobile phone is then adopted in the device list and
can be operated via the Phone portal.
Note: Not every mobile device supports all functions of the
Phone portal. Deviations from the range of functions available
are possible - compatibility list available at www.vauxhall.co.uk/
manuals.html.
6 8 9
7 10
Aux In
AUDIO DEVICE – HOW TO CONNECT:
:
®
Directly connect your audio devices with one
simple port. In the centre console there is an
AUX socket for the connection of external audio
sources. It's possible to connect an MP3 player or
a portable CD player with a 3.5 mm jack plug to
the AUX input.
TO CONNECT YOUR AUDIO DEVICE:
CONNECT: Device to Aux In (as seen
in image below)
PRESS: CD/AUX or AUX button once or
several times to activate the AUX mode.
An audio source that is connected to the AUX
input can be operated only via the control
elements of the audio source.
Lighting
9
EXTERIOR LIGHTING:
Be seen, be safe. Equipped as standard on Astra, Daytime running lights increase visibility of the vehicle during
daylight and are activated automatically when ignition is on.
LIGHT SWITCH
BASIC OPERATION:
= Activation or deactivation of
automatic light control. (switch returns
to AUTO)
AUTO = Automatic light control
Headlights are switched on and off
automatically
= Sidelights
= Low beam or high beam
PRESS BUTTON:
= Front fog lights
= Rear fog light
TURN THUMB WHEEL:
= Headlight range adjustment
= Instrument panel illumination
*Automatic Light Control is Model Specific
Seating
s
Have a seat and make yourself comfortable. For maximum control and satisfaction, both seats and steering are
adjustable. All adjustments are within easy reach of your seat to easily find your perfect driving position.
Using the seat controls shown below, you can adjust the seat to your liking.
The following are recommended:
Sit with buttocks are as far back Adjust height so the belt lies across
against backrest as possible. Adjust the shoulder. It must not lie across
distance between seat and pedals the throat or upper arm. Do not adjust
so that your legs are slightly angled while driving.
when depressing pedals.
*Certain Seat controls are model specific
The upper edge of the head restraint
should be at upper head level.
