Summary of Contents for Philips LFH 0955
- Page 1 Conference Recording System LFH 0955 www.philips.com/dictation User manual Manual del usuario Benutzerhandbuch Gebruikershandleiding Manuel de l‘utilisateur Manuale di istruzioni...
-
Page 3: Table Of Contents
Playback Install the batteries 3.3.1 Overview playback functions Recharge the batteries 3.3.2 Noise reduction 2.2.1 Recharge the batteries using the Philips Delete power supply 3.4.1 Delete a file 2.2.2 Recharge the batteries through the USB 3.4.2 Delete part of a recording cable 3.4.3 Delete all dictations... -
Page 4: User Manual
Welcome Congratulations on your purchase and welcome to Philips! To fully benefi t from the support that Philips off ers, visit our Website for support information such as user manuals, software downloads and more: www.philips.com/dictation. • The Philips Conference Recording System is a compact, easy-to-use solution for all your conference recording needs. -
Page 5: Overview - Controls And Connections
Overview – controls and connections Interview microphone Remote control REC (Record) button Index mark button EOL (end-of-letter) button Digital Pocket Memo Built-in microphone Status LED EOL (end-of-letter) button REC (Record) button REW (Rewind) button FWD (Forward) button Menu button On/off switch Microphone socket Headphone / remote control socket Display... -
Page 6: Overview - Display Indicators And Symbols
Download indicator LED Power supply socket Mini-USB socket for connection to the PC Conference microphone Overview – display indicators and symbols 10 11 9 : 2 3 D P M 0 9 5 5 . M P 3 PLAY Current function of the left smart button Voice-activated recording in progress File name Remaining recording time... -
Page 7: Get Started
Recharge the batteries Get started The Digital Pocket Memo can be operated with the rechargeable Philips AAA batteries. To recharge these batteries, use the Philips power Install the batteries supply, the Docking Station or the cable. The Digital Pocket Memo can be operated with the two rechargeable AAA batteries delivered 2.2.1... -
Page 8: Recharge The Batteries Through The Docking Station
Make sure that the docking station is Memo until it clicks. connected to the main power supply with Release the memory card. It will slightly the Philips power supply. emerge from the memory card slot. Simply Insert the Digital Pocket Memo into the slide it out. -
Page 9: Format A New Memory Card
To insert a memory card: Locate the memory card slot on the top D e l e t Delete all ? e a l l Format memory Delete all ? Yes - format Y e s - back side of the Digital Pocket Memo. f o r m a Volume All files... -
Page 10: Set The Language
2.5.1 Set the language Press the – button to select a When using the Digital Pocket Memo for the 12-hour or 24-hour clock, AM or PM (if a first time, you will be prompted to set the 12-hour clock is selected), and to change language. -
Page 11: Using Your Conference Recording System
Using your Conference Recording System Before recording The Digital Pocket Memo has a built-in monaural microphone that is used for recording when no external microphone is connected. To enhance sound quality and cover a wider range during recording, use the conference microphones (for conference recording) or the click-on interview microphone (for interviews). -
Page 12: Connect The Remote Control
3.1.2 Connect the remote control Connect the plug of the remote control to the remote control socket of the Digital Pocket Memo. 2 m / 6.5 ft. 13 m / 42.5 ft. Connect and position up to 6 conference microphones 2 m / 6.5 ft. -
Page 13: Recording
Recording The following information is displayed: Remaining recording time Recording mode 3.2.1 Create a new recording Current position in the recording Follow these steps to create your first recording Recording time with the Digital Pocket Memo: File name Recording level meter (left channel) A memory card must be inserted into the Recording level meter (right channel) memory card slot. -
Page 14: Add To A Recording (Append)
D P M 0 9 5 5 . M P 3 BEGIN recording. E Tip Philips SpeechExec software can be configured - 2 7 to download finished files only from the Digital 2 : 3 4 Pocket Memo to the PC. -
Page 15: Adjust The Microphone Sensitivity
D Note Setup Microphone Language Conference C A N C PCM recording mode is not available by default BACK ENTER BACK ENTER and must be enabled through Philips SpeechExec Dictate. See Advanced configuration on page 20 for more information. User manual... -
Page 16: Set The Sound Filter
3.2.6 Set the sound filter 3.2.7 Monitor recording Activate the sound filter to minimize low- and Headphones can be connected to the Digital high-frequency sounds and optimize voice Pocket Memo to hear the sound being recorded recordings. and to monitor the record level. Press the button while stopped to... -
Page 17: Playback
Playback 3.3.1 Overview playback functions Press the – button while stopped to select the recording to play back. Fast Press the button briefly while Press the smart button to start PLAY rewind stopped. Press the STOP smart button playback. to stop winding or the PLAY smart button to stop winding and start playback. -
Page 18: Noise Reduction
3.3.2 Noise reduction Delete The noise reduction function reduces interfering background noise and improves sound quality D Note during playback. Before deleting a file, make sure that it is not marked finished and that the memory card is not Press the button while stopped to set to read-only (locked). -
Page 19: Delete Part Of A Recording
3.4.2 Delete part of a recording 3.4.3 Delete all dictations Follow these steps to delete a section from a Caution recording: Navigate to the beginning of the section to Files marked finished (EOL) are deleted when be deleted by playback or forward/rewind. the delete-all-dictations function is used. -
Page 20: Use More Of Your Conference Recording System
4.1.1 Advanced confi guration Use more of your The Digital Pocket Memo Confi guration Wizard is part of the Philips SpeechExec Dictate Conference Recording software and guides users through the device confi gurations and settings of their Digital System Pocket Memo. The wizard assists users in... -
Page 21: Download Recordings To The Pc
Digital Pocket Memo will automatically drive. pause recording after three seconds of silence, and resume only when you begin speaking again. Use Philips SpeechExec software for automatic download, conversion and routing of files. Press the button while stopped to MENU open the Digital Pocket Memo menu. -
Page 22: Work With Index Marks
Work with index marks threshold sound level , recording pauses af- ter three seconds and the status LED flashes. Index marks can be used to mark certain points Press the – button to adjust the in a recording as points of reference. A point threshold sound level while recording. -
Page 23: Delete All Index Marks
Delete indices menu item and press the D Note smart button ENTER Press the smart button Author names must first be set up with Philips ENTER smart button to confirm the SpeechExec software. See Advanced configuration deletion, or press the smart button on page 20 for more information. -
Page 24: Display And Sound Functions
Display and sound functions 4.5.2 Setting date and time When using it for the first time, you will be prompted to set the date and times. If the 4.5.1 Setting the language settings are not correct follow these steps to When using it for the first time, you will be set them: prompted to set the language of the user... -
Page 25: Backlight
D Note 4.5.4 Record lamp If a mistake is made in the date/time settings, When enabled, the status LED/record lamp ← use the smart button any time during the glows red during recording. procedure to step back to make corrections. Press the button while stopped to... -
Page 26: Lcd Contrast
4.5.5 LCD contrast 4.5.6 Device beep The contrast of the LCD screen can be adjusted The Digital Pocket Memo is by default set to for the level of light in your environment and give sound feedback (beeps) when: your viewing preferences. •... -
Page 27: Menu List
Some settings, such as defining author names or Press the button MENU switching to simple display mode, are available only through Philips SpeechExec Dictate. See (see 3.4.1 page 18) DELETE DICTATION Advanced configuration on page 20 for more (see 4.3 page 22) - Page 28 Disclaimer and Notices Philips performs extensive testing with the most popular configurations. However, since PC add- ons and device drivers are updated continually, conflict-free operation cannot be guaranteed. User manual...
