Latest software and documentation are available at http://support.dlink.com.
1
Computer must adhere to Microsoft' s recommended System Requirements.
2
3 Maximum wireless signal rate derived from draft IEEE 802.11ac specifications. D-Link makes no warranties as to forward compatibility with future standards or compatibility with draft 802.11ac devices from other manufacturers. Actual data
throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors may adversely
affect wireless signal range. Up to 867Mbps wireless speeds achieved when connecting to other 802.11ac devices.
24/7 Basic Installation Support is available only in the USA for the first 30 days from date of original purchase.
4
5 1-Year Limited Warranty available only in the USA and Canada.
Zero Configuration requires a D-Link Cloud Router and a Zero Configuration-enabled device.
6
All references to speed and range, including the performance chart, are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted on
the package. See inside package for warranty details.
U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com
©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, the D-Link RoHS Logo, Xtreme N, SharePort, and the D-Link Green logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in
the United States and/or other countries. Other trademarks or registered trademarks are the property of their respective owners.
Updated 04/01/13
DIR-820L
USB SharePort™
Stream and share media using the
SharePort™ Mobile app
WPS Push Button
Easily and securely connect new
devices with the push of a button
4 LAN Ports
Connects up to 4 wired devices
Internet Port
Connects to your modem

Power Button

Power Connector
Wireless AC1000 Dual Band Cloud Router

Technical Specifications

Standards
2.4GHz
• IEEE 802.11n
• IEEE 802.11g
5GHz
• IEEE 802.11ac (draft)
• IEEE 802.11n
• IEEE 802.11a
Physical Interfaces
• 4 Fast Ethernet Ports
• 1 Fast Ethernet WAN Port
• WPS (Wi-Fi Protected Setup) Push Button
• USB 2.0 Port
• Reset Button
Antenna Type
• Internal Antennas
Ethernet Interface
• 4 10/100 Fast Ethernet Ports
• 1 10/100 Fast Ethernet WAN Ports
Security
• Wi-Fi Protected Access (WPA/WPA2)
• WPS™ (Wi-Fi Protected Setup)
Advanced Firewall Features
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI)
LEDs
• Power/WPS
• Internet
Power
• DC 12V/2A
Mobile Apps
• SharePort Mobile
• QRS Mobile
• mydlink Lite
Advanced features
• VPN pass through
• Guest Zone Support
• IPv6
Operating Temperature
• 30º to 104º F (0º to 40º C)

Operating Humidity

• 10% to 90% non-condensing
Certifications
• FCC
• IC
• Wi-Fi Certified
• CE
Dimensions
• Item: 4.37 x 3.66 x 5.71 inches
• Box: 10.79 x 8.19 x 4.64
Weight
• Item: 0.642 lbs
• Box: 1.85 lbs
Warranty
• 1-Year Limited Warranty
3
Building Networks for People
