OWNER`S MANUAL
ELDORADO, ADIRONDACK, JURASSIEN,
CELTIC AND SAVANNAH
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOODSTOVES
Verified and tested following
ULC S627 and UL 1482 Standards by:
Manufactured by: STOVE BUILDER INTERNATIONAL INC.
250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3
Tel: ( 418 ) 878-3040
Fax: ( 418 ) 878-3001
www.drolet.ca
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
Printed in Canada
45061A
14-12-2011

Advertisement

Table of Contents
loading

Related Manuals for Drolet Eldorado

Summary of Contents for Drolet Eldorado

  • Page 1 OWNER`S MANUAL ELDORADO, ADIRONDACK, JURASSIEN, CELTIC AND SAVANNAH US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOODSTOVES Verified and tested following ULC S627 and UL 1482 Standards by: Manufactured by: STOVE BUILDER INTERNATIONAL INC. 250, rue de Copenhague, Saint-Augustin-de-Desmaures (Quebec) G3A 2H3...

  • Page 2: Introduction

    INTRODUCTION SBI INC., one of the most important wood stove and fireplace manufacturers in Canada, congratulates you on your purchase and wishes to help you get maximum satisfaction from your wood stove. In the pages that follow, we will give you advice on wood heating and controlled combustion as well as technical specifications regarding installation, operation and maintenance of the model you have chosen.

  • Page 3: Table Of Contents

    GASKETING ..........................33   PAINT ............................33   DROLET LIMITED LIFETIME WARRANTY ..............34   REGISTER YOU WARRANTY ONLINE To receive full warranty coverage, you will need to show evidence of the date you purchased your stove. Keep your sales invoice. We also recommend that you register your warranty online at http://www.drolet.ca/en/service-support/warranty-registration...

  • Page 4: Technical Specifications

    7 5/8’’ x 18 1/4’’ (200 x 464 mm) W x H Pyroceram Glass Door: 8 ¾ ’’ x 16 ½ ’’ Adirondack, Celtic, Savannah, Eldorado: (222 x 419 mm) Jurassien: 10’’ x 18 ¼ ’’ (254 x 464 mm)
  • Page 5 *Why is the BTU indicated on the EPA label different than the one advertised? You will notice a difference between the BTU output indicated on the unit’s white EPA label affixed to the glass and the BTU advertised on our web site and/or product literature. The maximum BTU output we advertise for this unit is what will be obtained with a full load of seasoned cordwood inserted inside the firebox.

  • Page 6: Tips On Wood Heating

     The chimney is the engine that drives the wood-heating system. Use a chimney that is UL-listed, with an inner diameter to match the stove’s outlet collar (6” for all Drolet wood stoves);...

  • Page 7: Assembly

    ASSEMBLY PEDESTAL AND PANELS Pedestal Base Installation: 1. Slide the front part of the pedestal base around the pedestal and fix the rear part with the two supplied screws. 2. Slide the ash pan in position. Side Panels and Ash Lip Installation: 1.

  • Page 8: Legs And Ash Pan

    LEGS AND ASH PAN Ash Lip Installation: Just clip the ash lip into position, centred just below the door. Slide the ash pan in position.

  • Page 9: Door Adjustment

    DOOR ADJUSTMENT In order for your stove to operate properly, the door should be adjusted periodically to provide an air tight fit. To adjust:  Remove the lock pin (spring pin) by pulling and turning it using pliers ("wise grip") ...

  • Page 10: Ash Lip Installation For Jurassien Model

    ASH LIP INSTALLATION FOR JURASSIEN MODEL Your Jurassien can be equipped with an ash lip. Place it as shown on detail below and secure it in place using the two bolts supplied with the owner’s manual.

  • Page 11: The Benefits Of Installing A Blower

    THE BENEFITS OF INSTALLING A BLOWER A blower can be installed at the back of your DROLET stove (included on Eldorado.) This option is necessary if you wish to redistribute into a room the heat trapped at the back of your stove.

  • Page 12: Installation

    INSTALLATION SAFETY NOTICE  I F THIS STOVE IS NOT PROPERLY INSTALLED A HOUSE FIRE MAY RESULT O REDUCE THE RISK OF FIRE FOLLOW THE INSTALLATION INSTRUCTIONS AILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE BODILY INJURY OR EVEN DEATH ...

  • Page 13: Clearances To Combustibles And Floor Protector

    (see figure 2 to match each letter to a clearance) CLEARANCES (SINGLE WALL PIPE) CANADA & USA MODEL 15’’ 18’’ 12’’ 19’’ 28’’ 21’’ 48’’ 84’’ Eldorado (385 mm) (460 mm) (305 mm) (485 mm) (715 mm) (535 mm) (1220 mm) (213 cm) 15’’ 12’’ 10’’...
  • Page 14 Figure 2: Clearances to combustibles and floor protector...

  • Page 15: Floor Protector

    FLOOR PROTECTOR If the stove is to be installed on top of a combustible floor, it must be guarded by a non combustible material as shown on figure 2 (see the dotted line area). FLOOR PROTECTOR* CANADA 8’’ (205 mm) – Note 1 N/A (Canada only) 8’’...

  • Page 16: Reduced Clearances Using Shielding

    REDUCED CLEARANCES USING SHIELDING You may decrease the clearances by installing heat radiation shields between the walls or the ceiling and the stove. These heat radiation shields must be installed permanently, and can include sheet metal, a rigid non-combustible sheet or a masonry wall. Clearances of not less than 1"...
  • Page 17 Graphic 1 A- Minimum clearance required between the appliance and an unshielded combustible ceiling. B- 20 in. (500 mm) minimum; C- 1 in. (25 mm) minimum; D- Between 1 in. and 3 in. (25 mm and 75 mm); E- 3 in.(75 mm) minimum; F- 18 in.
  • Page 18 Graphic 2 A- 1 in.(25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- 0.024’’ (0.61 mm) sheet metal. Graphic 3 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- Non-combustible support; 4- Ceramic tile or non-combustible material. Graphic 4 A- 1 in.
  • Page 19 Graphic 5 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- Brick. Graphique 6 A- 1 in. (25 mm) minimum; 1- Combustible wall; 2- Non-combustible spacers; 3- 0.024’’ (0.61 mm) thick sheet metal; 4- Brick.

  • Page 20: Chimney

    CHIMNEY Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a factory built chimney, it must comply with UL 103 or ULC S629 standards; therefore it must be a Type HT (2100 °F). It is extremely important that it be installed according to the manufacturer's specifications.
  • Page 21 CHIMNEY CONNECTOR Your chimney connector (commonly called stove pipe) and chimney must have the same diameter as the  stove’s exhaust outlet. The stove pipe must be made of aluminized or cold roll steel with a minimum 24‐ gauge thickness (0.021" or 0.53 mm).  It is strictly forbidden to use galvanized steel.    The following recommendations may be useful for the installation of your chimney connector:     Your  chimney  connector  should  be  assembled  in  such  a  way  that  the  male  end  (crimped)  faces  down to prevent creosote dripping outside the joints. Attach each of the sections to one another  with  three  equidistant  metal  screws.    Also  use  three  equidistant  metal  screws  to  attach  the  connector to the stove’s exhaust collar.  See Figure 2.3 (A) and Figure 2.3 (B). ...
  • Page 22     FIGURE 2.3 (B) Minimum Slope  The assembly should be as short and direct as possible between the stove and chimney (See figure  2.4  (A)).  The  use  of  two  45  degree  elbows  (See  figure  2.4  (C))  is  often  preferable  to  a  single  90  degree elbow (See figure 2.4 (B)) because less turbulence is created in the exhaust flow and they  result in less horizontal run.      (A)  (B)  (C)  FIGURE 2.4 The use of elbows...

  • Page 23: Chimney Connector (Stove Pipe)

    DRAFT Your E.P.A Drolet stove’s performance will be optimised if it is installed with a chimney (flue) system that provides an adequate draft. The draft is the force that moves air from the appliance up through the chimney and is predominantly affected by the height and diameter of the chimney, as well as the stack temperatures of the stove.
  • Page 24 MASONRY CHIMNEY: C lay liner Thimb le C lean out door...
  • Page 25 FACTORY BUILT THIMBLE:...
  • Page 26 BRICK THIMBLE:...

  • Page 27: Outside Combustion Air

    OUTSIDE COMBUSTION AIR Your DROLET stove is approved to be installed with an outside air intake which is necessary for a mobile home. This type of installation is also required in air tight houses and houses with negative pressure problems. You can purchase this option through your DROLET dealer.

  • Page 28: Wood Stove Utilisation

    WOOD STOVE UTILISATION Your heating unit was designed to burn wood only; no other materials should be burnt. Wastes and other flammable materials should not be burnt in your wood stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others.

  • Page 29: Testing Your Wood

    Smaller pieces of wood will dry faster. All logs exceeding 6" in diameter should be split. The wood should not be stored directly on the ground. Air should circulate through the cord. A 24" to 48" air space should be left between each row of logs, which should be placed in the sunniest location possible.

  • Page 30: Heating

    If you push on it until it stops the combustion air is reduced to a minimum. Your DROLET stove burnt between .953 kg\h et 3.639 kg\h. of wood during EPA testing. Real operating conditions may give very different results than those obtained in the lab according to the species of wood used, it's moisture content, the size and density of the pieces, the length of the chimney, altitude and outside temperature.

  • Page 31: Reloading

    RELOADING Once you have obtained a good bed of embers, you should reload the unit. In order to do so, open the air controls to maximum a few seconds prior to opening the stove's door. Then proceed by opening the door very slowly; open it one or two inches for 5 to 10 seconds, before opening it completely to increase the draught and thus eliminate the smoke which is stagnant in a state of slow combustion in the stove.

  • Page 32: Ash Disposal

    AMAGE TO THE STOVE AND EVEN HOUSE FIRE MAY RESULT BLOWER OPERATION If your stove has a fan (Eldorado model) or if you have install an optional blower, allow the stove time to reach its operating temperature (approximately one hour), before starting the blower.

  • Page 33: Maintenance

    Do not abuse the glass door by striking or slamming shut. Do not use the stove if the glass is broken.  If the glass on your stove breaks, replace only with glazing supplied from the Drolet dealer.

  • Page 34: Drolet Limited Lifetime Warranty

    Firebrick *Pictures required Shall your unit or a components be defective, contact immediately your DROLET dealer. Prior to your call make sure you have the following information necessary to your warranty claim treatment: ...
