- Page 1 OPERATOR’S MANUAL BELT DRIVEN POWER WASHER CAUTION RISK OF INJURY! READ MANUAL BEFORE OPERATING! This manual is an important part of the power washer and must remain with this unit! Copyright 2011 0J7933 rev.A 1...
-
Page 2: Table Of Contents
table of contents introduction ........................3 important safety warnings................4-7 FIRE & VENTILATION PRECAUTIONS ..............4 SPRAY PRECAUTIONS ..................5 MISCELLANEOUS SAFETY PRECAUTIONS ............6 ADJUSTMENT PRECAUTIONS ................7 features drawing ......................8 safety decals ......................9 installation & preparation ................10-13 ATTIRE ........................10 SETUP .........................10 ENGINE FUEL TANK ..................10 QUICK CONNECT NOZZLES ................11 NOZZLE CONNECTION ..................11 WATER SUPPLY ....................12 UNLOADER ......................12 ThERMAL RELIEF VALVE . -
Page 3: Introduction
Congratulations on the purchase of your new cold water power washer! You can be assured your new cold water power washer was constructed with the highest level of precision and accuracy. Each component has been rigorously tested by technicians to ensure the quality, endurance and performance of this unit. This operator’s manual was compiled for your benefit. By reading and following the simple safety, installation, operation, maintenance and troubleshooting steps described in this manual, you will receive years of trouble free operation from your new cold water power washer. The contents of this manual are based on the latest product information available at the time of publication. Generac reserves the right to make changes in price, color, materials, equipment, specifications or models at any time without notice. ! important ! tHese paragrapHs are surrounded by a “safety alert boX”. tHis boX is used to designate and empHasize safety warnings tHat must be followed wHen operating tHis power wasHer. accompanying tHe safety warnings are “signal words” wHicH designate tHe degree or level of Hazard seriousness. -
Page 4: Important Safety Warnings
important safety warnings fire & ventilation precautions: 1. This unit was designed for outdoor use only. NEVER operate this unit in an enclosed area. ALWAYS make certain there is adequate air (oxygen) for combustion as well as ventilation to prevent the presence of poisonous carbon monoxide gases. Beware of poorly ventilated areas or exhaust fans which can cause inadequate combustion or engine overheating. 2. DANGER: Carbon monoxide produced during use CAN KILL in minutes. NEVER use indoors, in a vehicle or in other sheltered areas, EVEN IF doors and windows are open. Only use OUTSIDE and far away from windows, doors and vents. a. Carbon monoxide is an odorless, colorless, poison gas. Breathing carbon monoxide can cause headache, fatigue, dizziness, vomiting, confusion, seizures, nausea, fainting or death. If you start experiencing any of these symptoms, IMMEDIATELY move to fresh air. Seek medical attention. b. Keep exhaust gas from entering confined area through windows, doors ventilation intakes, or other openings. Warn any occupants inside about the symptoms of carbon monoxide so they know to move to fresh air if they begin to feel ill. c. The use of a carbon monoxide detector inside any occupied premise between the power washer and the occupant is recommended. d. Use a respirator or mask whenever there is a chance that harmful gas or vapors may be inhaled. e. Read all instructions with respirator or mask so you are certain the respirator or mask will provide the necessary protection against inhaling harmful gas or vapors. If you begin to experience any of the carbon monoxide symptoms listed above, IMMEDIATELY move to fresh air. -
Page 5: Spray Precautions
important safety warnings spray precautions: danger RIsk Of INjECTION OR sEvERE CUTTING INjURy! Keep clear of nozzle! do not direct discHarge stream at persons or pets! only trained operators sHould use tHis product. wHen operating tHis unit, basic precautions sHould always be observed including tHe following: 1. KEEP AWAY FROM ThE SPRAY: a. Because of the high pressure and velocity of the spray, fluids can... -
Page 6: Miscellaneous Safety Precautions
important safety warnings miscellaneous safety precautions: 1. NEVER ALLOW ChILDREN OR ADOLESCENTS TO OPERATE ThIS UNIT! 2. Read and follow all handling, operations, maintenance and safety instructions listed in this manual and the Engine Operator’s manual that accompanies this unit, and provide such information to ANYONE who will be operating this unit. 3. In freezing temperatures, the unit must always be warm enough to ensure there is no ice formation in the pump. DO NOT start this unit if it has been transported in an open or underheated vehicle without first allowing the pump to thaw. 4. When connecting the water inlet to the water supply mains, local regulations of your water company must be observed. In some areas the unit must not be connected directly to the public drinking water supply. This is to ensure that there is no feedback of the detergents into the water supply. (Direct connection is permitted if a back flow preventer is installed.) 5. DO NOT allow any part of your body or the high pressure hose to make contact with the muffler. Avoid dragging the hose over an abrasive surface such as cement. This causes wear and eventual rupturing. -
Page 7: Adjustment Precautions
1. NEVER alter or modify the equipment, be sure any accessory items and system components being used will withstand the pressure developed. Use ONLY genuine Generac parts for repair of your power washer. Failure to do so can cause hazardous operating conditions and will void warranty. 2. NEVER make adjustments to the machinery while it is connected to the engine without first removing the ignition cable from spark plug. Turning the machinery over by hand during adjustment or cleaning might start the engine and machinery with it, causing serious injury to the operator. 3. Know how to stop the power washer and bleed pressures quickly. Be thoroughly familiar with controls. 4. Before servicing the unit; turn the unit off, relieve the water pressure, and allow the unit to cool down. Do not make repairs while unit is running. Service in a clean, dry, flat area. Block the wheels to prevent the unit from moving. 5. Follow the maintenance instructions specified in this manual. ! save tHese instructions ! -
Page 8: Features Drawing
features features listing 1 Gun holder 7 Water Outlet 2 Wand holder 8 Water Inlet 3 Engine 9 Quick Connect Nozzle 4 Oil Sight Glass 10 Aux Gun handle 5 Pump Dipstick 11 Gun Assembly 6 Unloader 12 high Pressure Discharge hose ... -
Page 9: Safety Decals
safety decals !!!DO NOT REmOvE sAfETy DECAls fROm UNIT UNlEss REplACING WITh mOsT CURRENT sAfETy DECAl!!! Reference #6 Decal: Danger-Engine Fuel DANGER/PELIGRO RISK OF FIRE RIESGO DE FUEGE Do not add fuel when No ponga combustible cuando product is operating. Allow el producto este en operacion. engine to cool for two (2) Permita que el motor se enfrie minutes before refueling. -
Page 10: Installation & Preparation
installation & preparation attire: Proper attire is essential to your safety. It is advised to utilize whatever means necessary to protect eyes, ears, and skin. Additional safety attire (such as respiratory mask) may be required when using detergent cleaning agents with this washer. set-up: DANGER 1. This unit should only be placed on a level surface to ensure proper lubrication for the engine and water pump while operating. NEVER spray water directly risK of eXplosion or fire! on the unit! do not place unit in an area wHere flammable 2. Do not use unit in an area: gas vapors may be present. -
Page 11: Quick Connect Nozzles
installation & preparation DANGER nozzle review: risK of injection causing severe injury! Various nozzles may be quick-connected into the end of the wand to change never looK directly at tHe the spray pattern. When using Quick Connects (Q.C.), be certain the nozzle orifice unless it connection is securely locked. If not, the high pressure water may shoot is disconnected from tHe the nozzle from the wand, causing severe injury or serious damage. To gun/wand assembly! determine spray fan, refer to the actual number stamped on the nozzle. -
Page 12: Water Supply
installation & preparation water supply: 1. Select a water supply hose which is a quality grade of garden hose measuring at least 3/4” ID and no longer than 50 feet. 2 Check the water inlet strainer to ensure it is clean and free of any obstructions. Periodic cleaning of the water strainer will help prevent pump problems. As a strainer becomes obstructed, it restricts proper flow of water to the pump. This can result in cavitations which will cause premature failure of pump packings. a. Using a screw driver, remove the screen from the water inlet. b. Clean or replace if necessary. 3. Connect the hoses: a. Connect one end of the water supply hose to the water inlet of the unit. b. Connect the other end of the hose to your pressurized water supply. When connecting the water inlet to the water supply mains, local regulations of your water company must be observed. In some areas, the unit must not be connected directly to the public drinking water supply. This is to ensure that there is no feedback of the detergents into the water supply. (Direct connection is permitted if a back flow preventer is installed.) c. Quick-connect the high pressure discharge hose to the water outlet of the unit. -
Page 13: Pre-Start Inspection Procedures
installation & preparation pre-start inspection procedures: Before starting the unit, perform the following procedures: 1. Check the oil level in the pump and engine. 2. Inspect the water inlet strainer. Clean or replace if necessary. See “Water Supply”, #2, pg. 12. 3. Check all hose connections to ensure they are securely tightened. See “Water Supply”, #3, pg. 12. 4. Inspect for system fuel leaks. If a fuel leak is found, DO NOT START UNIT! See “Fire & Ventilation Precautions”, #2 and #4, pg. 4. Be sure that all damaged parts are replaced and that the mechanical problems are corrected prior to operation of the unit. If you require service, contact Customer Service. -
Page 14: Operating Instructions
operating instructions priming tHe pump: CAUTION 1. It is essential to prime the pump on initial start-up and each time the water supply is disconnected from the unit after initial use. risK of unit damage. 2. Lay the high pressure hose out to remove any loops. Water flow will constrict be certain tHe nozzle is the hose, creating tight loops if the hose is not straight. not connected to tHe unit wHile priming tHe pump. 3. Securely connect the gun assembly to the high pressure hose. priming allows mineral NOTE: The nozzle assembly should NOT be connected to the gun assembly deposits to be released at this time. -
Page 15: Shutdown
operating instructions sHut-down: 1. Turn engine “OFF” as directed in the Engine Manual. 2. Turn the water supply “OFF”. 3. Pointing the gun in a safe direction, trigger gun momentarily to relieve any trapped pressure. 4. Once pressure is relieved, disconnect the nozzle assembly. 5. Disconnect and drain gun, wand and hoses. 6. Wipe unit clean and store with gun, wand and hoses in a safe, non-freezing area. storage & maintenance specific maintenance: ENGINE: The engine instructions that accompany your unit detail specific procedures for maintenance of the engine. Following the engine manufacturer’s recommendations will extend engine work life. PUMP: The pump oil must be changed after the first 25 hours of operation. Once the initial oil change has been completed, it is recommended the oil be changed every 3 months or 250 hour intervals. If oil appears dirty or milky, changes may be required at a greater frequency. Use SAE 30 oil, fill only to the center of the oil sight glass and fill only to the center of the oil sight glass. DO NOT OVERFILL! -
Page 16: Storage & Maintenance
2. The pumping system in this unit may be permanently damaged if frozen. and render your unit FREEZE DAMAGE IS NOT COVERED BY WARRANTY. inoperable. If you must store your unit in an area where the temperature may fall below 32°F, you can protect your unit by following the procedure outlined below. 1. Gather the following items: a. Two 5 gallon containers. b. One gallon of antifreeze. (Generac recommends an environmentally safe antifreeze.) c. Water supply. d. Three foot hose, 1/2-3/4 I.D. with a 3/4 inch male garden hose fitting. 2. Procedure: 32˚F 0˚C a. To start winterizing, unit must be run and primed according to the “Start- up Procedures” listed on page 14. -
Page 17: Troubleshooting
troublesHooting SYMPTOM PROBABLE CAUSE REMEDY Engine will not start. Various engine problems. Refer to the Engine Manual accompanying your unit. Unit components are frozen. Allow to thaw. If any part of the unit becomes frozen; excessive pressure may build up in the unit which could cause the unit to burst resulting in possible serious injury to the operator or bystanders. No discharge at nozzle when Inadequate water supply. Ensure hose is 3/4” diameter and trigger mechanism is squeezed. incoming water supply is turned on. Kink in water inlet hose. Remove kink. Low or fluctuating pressure. Kink in high pressure discharge hose. Replace hose. Water inlet strainer obstructed. Remove screen, clean or replace. Pump sucking air. (Prime eliminated) Tighten all water intake connections Eliminate leaks in intake line. Not in high pressure mode. Insert high pressure nozzle. Obstructed or worn spray nozzle. Remove, clean or replace. Damaged or obstructed valve assy. Remove, inspect, clean or replace. on pump. Pump packings worn. Replace packings. Unloader valve not operating correctly. Repair or replace. Water is leaking from the “heat Water temperature is too high. -
Page 18: Statement Of Warranty
Generac Power Systems, Inc. (Generac) warrants its Power Washers will be free from defects in materials and workmanship from the date of purchase for the items and period set forth below. Generac will, at its option, repair or replace any part which, upon examination, inspection and testing by Generac or a Generac Authorized Warranty Service Dealer, is found to be defective.
