QUICK CLIPS
* Discard Quick Clips and use the following instructions to install the new Smart Clips
1.
Install net clips.
WARNING:
Use of this product without
proper installation of net clips, or when all net
clips are not present could result in bodily
harm. Be sure to follow directions carefully.
INCORRECT
Insert one "arm" of clip (19) into ram (18) as shown. Twist "body" of clip slightly so that
second "arm" slides over the top of the first "arm" as shown.
Push in direction indicated by arrows.
A A
Push second "arm" back and into ram as shown.
B B
Twist "body" of clip slightly again to spread "arms" of clip.
Clip "arms" must be flat and touching edge to edge as shown, not overlapping.
C C
Smart Clip Installation Instructions
SMART CLIPS
1
CORRECT
CLIP "ARM"
CLIP "BODY"
08/02
P/N 211971
