  • Page 1 SACD Standard Super Audio THE LEADER IN AUDIO ENGINEERING Compact Disc Player Instructions for Use Owner’s Reference...
  • Page 2 This product is manufactured in the United States of America. Krell ® is a registered trademark of Krell Industries, Inc., and is restricted for use by Krell Industries, Inc., its subsidiaries, and authorized agents. Krell Current Mode™ is a trademark of Krell Industries, Inc. TosLink ®...

  • Page 3: Table Of Contents

    UNPACKING PLACEMENT AC Power Guidelines FRONT PANEL DESCRIPTION BACK PANEL DESCRIPTION REMOTE CONTROL DESCRIPTION Battery Installation and Removal CONNECTING THE SACD STANDARD TO YOUR SYSTEM Connection Steps OPERATING THE SACD STANDARD Power On How to Play a Disc WARRANTY RETURN AUTHORIZATION PROCEDURE...
  • Page 4 Illustrations Page FIGURE 1 The SACD Standard Front Panel FIGURE 2 The SACD Standard Remote Control FIGURE 3 The SACD Standard Back Panel FIGURE 4 Analog and Digital Connections for the SACD Standard Krell SACD Standard...

  • Page 5: Introduction

    Introduction Thank you for your purchase of the Krell SACD Standard. The SACD Standard is a music-only platform which plays single layer, dual layer, and hybrid super audio compact discs as well as conventional audio compact discs. This component features exceptional high quality two- channel stereo as well as the new multi-channel output, bringing you the excitement of six-channel sound.

  • Page 6: Definition Of Terms

    Stand-by Mode When the SACD Standard is connected to AC power, and the back panel power switch (30) is up, or in the “1” position, the red stand-by LED illuminates. This indicates that the component is in stand-by mode, a low power consumption status that keeps the audio and reg- ulator circuits at idle.
  • Page 7 TECHNOLOGY Krell Current Mode A proprietary Krell circuit topology in which the audio gain stages of a component operate in the current rather than the voltage domain. This unique technology provides the component with exceptional speed and a wide bandwidth.

  • Page 8: Unpacking

    Grasp the underside of the foam end-caps that encase the SACD Standard and lift it straight out of the shipping box. Place the SACD Standard in a safe location and remove the protective plastic wrapping.

  • Page 9: Placement

    For the dimensions of the SACD Standard, see Specifications, on page 18. Place the SACD Standard on a firm, level surface, away from exces- sive heat, humidity, or moisture. The SACD Standard requires at least two inches (5 cm) of clearance on each side and at least two inches (5 cm) of clearance above and below the component to pro- vide adequate ventilation.
  • Page 10 Figure 1 The SACD Standard Front Panel SACD Standard TRACK SEARCH OPEN/CLOSE SACD/CD PAUSE STOP PLAY FILTER SCAN REPEAT STAND-BY DISPLAY SHUFFLE REPEAT A-B POWER 4, 5, 6 Figure 2 The SACD Standard Remote Power SACD/CD SACD Press the amp key...
  • Page 11 See also, 21 Infrared Sensor disc transport. Using the Shuffle Button Receives commands or Key, on page 9. from the SACD Standard remote control. For 14 Repeat proper remote control Replays selected track operation, make sure until new feature is select- that nothing is obstruct- ed.
  • Page 12 Once a filter setting has been OR KEY (11) selected, it will be held in memory even if the SACD Standard is turned off and then returned to operational status. Filter 1, 2, 3, and 4 are available in the SACD format. Filters 1 and 2 are only available in the conventional compact disc format.
  • Page 13 It has a +3.5 dB increase in output gain over the entire audio pass band compared to Filter 1. Press this button or key once to enable the SACD Standard to select USING THE SHUFFLE and play tracks in a random sequence. To cancel this function, press BUTTON OR KEY (13) the shuffle button or key again.
  • Page 14 Figure 3 The SACD Standard Back Panel POWER ANALOG AUDIO OUTPUTS DIGITAL AUDIO OUT OPTICS COAX SELECT 12VDC FRONT RS-232 REAR 50/60 Hz SACD Standard NO USER SERVICEABLE PARTS INSIDE MADE IN USA 9 RS-232 25 Coax Output Features ANALOG AUDIO...

  • Page 15: Back Panel Description

    The 12 VDC input allows you to turn the SACD Standard on or off, or to and from stand-by, from other components. When the component is in the operational mode, the 12 VDC Out provides Notes 12 V of DC output.

  • Page 16: Remote Control Description

    7. All remote features can also be activated via the buttons on the front panel. Descriptions of special operational fea- tures are outlined on pages 8-9. Battery The SACD Standard remote control uses one CR2025 lithium bat- tery, which is included with the shipment. Installation and Removal To open the battery compartment on the back of the remote control: Place the remote face down on the table.

  • Page 17: Connecting The Sacd Standard To Your System

    Conventional CD Stereo SACD Multi-channel SACD Connection Follow these steps to connect the SACD Standard to your system. Steps Make sure all power sources and components are off before connecting inputs and outputs. Neatly organize the wiring between the SACD Standard and all system components.
  • Page 18 In addition, for conventional compact disc playback only, you may connect the SACD Standard digital coaxial output or digital optics output to the corresponding preamp/processor digital input. Plug the AC power cord into the IEC power connector on the back panel.

  • Page 19: Operating The Sacd Standard

    LED (3) on the front panel illuminates. Then press the power button on the front panel or the SACD key (1) on the remote control, to place the SACD Standard in the operational mode. When the blue stand-by LED (2) illuminates, the SACD Standard is in the opera- tional mode and ready to play a SACD or a conventional compact disc.

  • Page 20: Warranty

    Should this product fail to perform at for warranty benefits, please any time during the warranty, Krell will repair it at no cost to the owner, except as set forth in complete and return the this warranty.

  • Page 21: Return Authorization Procedure

    WEB SITE http://www.krellonline.com HOW TO RETURN To return a product to Krell, please follow this procedure so that we A PRODUCT may serve you better: 1. Obtain a Return Authorization Number (R/A number) and ship- ping address from the Krell Service Department.

  • Page 22: Specifications

    Krell Industries, Inc. SACD Standard 45 Connair Road Super Audio Orange, CT 06477-3650 USA Compact Disc Player TEL 203-799-9954, FAX 203-891-2028 v 03.0 E-MAIL krell@krellonline.com WEB SITE www.krellonline.com Specifications FREQUENCY RESPONSE DIGITAL AUDIO OUTPUT All operational features, functions, 1 S/PDIF via RCA connector 20 Hz–20 kHz...
