Tannoy CVS 8 Technical Specifications

CVS 8

Product Description

The Tannoy CVS 8 is a full bandwidth large-format in-ceiling speaker system of
class-leading performance and exceptional value. The design comprises of 200mm
(8.00") mid bass driver with a coaxially mounted 19mm (0.75") high frequency section
mounted in a vented, injection moulded, paintable front baffle manufactured from UV/
weather resistant UL94V-0 ABS material. The new device is currently pending UL Listed
status (UL-1480 and UL-2043).
The mineral loaded polypropylene cone material and nitrile rubber surround provide
durability and long-term reliability, minimising system maintenance costs and future
disruption to any facility. This compact unit is specifically designed for applications
requiring the combination of music and speech reinforcement at higher SPLs with
consistent functionality and full bandwidth sound quality. Typical applications include
shopping malls, large conference facilities, hotel lobbies and ballrooms, and larger
bars and high-end restaurants where higher BGM specifications are often specified
and demanded.
The CVS 8 is equipped with a low insertion loss 60W line transformer easily
configurable to the following settings via front baffle mounted rotary tapping switch:
70V systems: 60W / 30W / 15W / 7.5W / OFF & low Impedance operation
100V systems: 60W / 30W / 15W / OFF & low Impedance operation
The CVS 8 is supplied with an integral painted steel back can, with recessed
termination box, to satisfy the vast majority of installation application requirements.
The removable locking connector has screw terminals for secure wire termination and
"loop through" facility. Strain relief is provided by a clamping mechanism for use with
plenum rated cable or conduit. Security toggle clamps make for quick and easy
installation, while two tile support rails and one C-ring are also included in the package.
A plaster (mud) ring is available as an optional accessory.
Tannoy (Direct UK) T: 00 44 (0) 1236 420199
TCGI (ROW sales) T: 00 45 8742 7000
TCGA (Americas sales) T: 00 1 (519) 745 1158
Tannoy Middle East T: 00 971 (04) 4401208
Tannoy adopts a policy of continuous improvement and product specification is subject to change
E: enquiries@tannoy.com
E: info@tcgroup-international.com
E: info@tcgroup-americas.com
E: enquiries@tannoy.com
251.0
[9.88"]
251.0
[9.88"]
19.6
[0.77"]
19.6
[0.77"]
315.2
[12.41"]
315.2
[12.41"]
Features
• Coaxially mounted 200mm (8.00") mineral loaded
woofer with rubber surround and 19mm (0.75")
soft dome diffraction loaded tweeter
• High power & high sensitivity with extended
frequency response and very low distortion
• Wide, controlled constant directivity dispertion for
optimum coverage
• UV/weather resistant UL94V-0 ABS front baffle
• Easily accessible tapping switch on front baffle
• Low insertion loss 60W line transformer
• Ferrofluid cooled neodymium HF
• Packaged with tile rails and C-ring for quick & easy
installation and simple stocking logistics
Applications
• Multizone Foreground Music & Paging Systems
• Boardrooms & Offices
• Business Music Systems
• Airports, Convention Centres, Hotels
• Reception / Waiting Rooms
• Houses of Worship
• Retail Outlets / Shopping Malls
• Lounges / Bars
• Cruise Ships
• Courtrooms
264.0
[10.39"]
264.0
[10.39"]
CVS 8 // issue 1.03 // 02.03.11
