Instructions for Use Microwave Bedienungsanweisung Mikrowelle Instructions d’Utilisation Micro-ondes...
Page 2
First, we would like to thank you for choosing our product. We are sure that this modern, functional and practical microwave oven, manufactured from the best materials, will satisfy your requirements. You are advised to read our operation manual carefully and the enclosed pamphlet to enable you to get the best results from your Microwave oven.
........................................ 5 5 5 5 ........ The advantages of a microwave oven:..................5 How the microwave oven works ....................5 Why does the food heat up? ......................6 Operating Instructions Operating Instructions Operating Instructions Operating Instructions ........
Place the oven on a flat stable surface able to support its weight. To allow efficient cooling of the microwave, its installation is recommended in a unit with an opening in the upper part (refer to the installation instructions leaflet enclosed).
Eggs with their shell and whole boiled eggs shouldn’t be warmed up in microwave ovens as they may explode, even after microwave heating has ended. Only use utensils that are suitable for use in microwave ovens. Do not use any metal utensils inside the oven unless they were supplied with the oven and for that purpose.
On the other hand, in microwave ovens the heat is generated in the interior of the food itself, heating it from the inside outwards. There is therefore no loss of energy as the air, interior walls of the oven and recipients (when adequate) do not heat up with microwaves.
As the heat is formed inside the food: - It may be cooked with little or no liquid or fat; - Defrosting, heating or cooking in the microwave oven is quicker than in a conventional oven; - Vitamins, minerals and nutritive substances are preserved;...
2. 2. 2. 2. Enter the operating time (for example 10 minutes), by pressing the – (6) and + (14) keys. 3. 3. 3. 3. To alter the microwave oven power level, press – (5) and + (13) keys. If these P 0 5 keys are not pressed, then the oven will operate at maximum power.
Defrosting by Weight (Automatic) How to Proceed Screen (1) 1. 1. 1. 1. Press the DEFROST key (10). This key will illuminate in red. F 0 1 2. 2. 2. 2. Enter the type of food, by pressing the – (5) and + (13) keys. If these keys are not pressed, the oven will select food type 1 by default.
- If the food is at a higher temperature (because it is not a three-star freezer or because the food has been out of the freezer for more than twenty minutes), then the time calculated by the oven will be too long and there may be risk of fire.
For example, to defrost 800 gm of meat by weight, heat it in the microwave for ten minutes at power 4 and then use the Microwave + Grill for eight minute at power 3 in the following manner.
- Stir or shake the food in order to improve uniform cooking; - Adjust the microwave power level by pressing the pre– (5) or + (13) keys; - Select another function, by pressing the function (2, 3, 4, 9, 10, 11, 12) keys;...
Adjusting the Clock How to Proceed Screen (1) 1. 1. 1. 1. Press the CLOCK key (8) until the digits start to flash. 2. 2. 2. 2. Enter the time value Adjust the remaining operating time by pressing the – (6) and + (14) keys.
Advice for Good Usage of the Oven Working with microwaves Before using any dish, make sure that it is appropriate for use in microwaves (SEE ADVICE ON THE USE OF UTENSILS AND RECIPIENTS). Always make a slit in the food's shell before cooking it. Whenever heating liquids use a recipient with a large opening to allow the vapour to escape.
Advice on the use of Cookware Metal Do not use metal dishes, tinned food, food wrapped in tin foil and cutlery inside the microwave oven. The metal reflects the microwaves and food is not heated. The food should be removed from its tin foil containers and placed in dishes adequate for use in the microwave oven.
Recipient Test If in doubt about the use of glass, glazed ceramic or porcelain dishes in the microwave oven, do the following test: 1. Place the empty dish and a glass of water inside the microwave oven.
DOOR, DOOR SEAL, AND OVEN FRONT 1. These parts should always be clean, especially the contact surface between the door and the oven front, to prevent microwave leakage. 2. Use neutral detergent, warm water and dry the surface with a soft cloth.
Official Technical Assistance Service (T.A.S.) Solving Problems Repairs or interventions carried out by an unqualified serviceman can cause dangerous situations. Every and any kind of repair or intervention should be done by the manufacturer, authorised agents or qualified technicians. If you detect any abnormalities in the oven, check the following before you contact T.A.S: 1.
Page 19
SMEG S.p.A. VIA CIRCONVALLAZIONE NORD, 36 42016 GUASTALLA RE ITALIA Tel.: +39 0522 837 777 Fax: +39 0522 838 384...
Page 20
VORSICHT! Der Mikrowellenherd kann wáhrend der inbetribnahme na tür und türrahmen bohe temperaturen erreichen, vorsicht ist empfohlen. WARNING! During the functioning of the microwave oven, the frame and the door may reach temperatures which require care when using the appliance.
Page 21
• Potencia del grill. Grilleistung. Grill power. Puissance du gril. Potência do grelhador Vermogen van de grill. Potenza del grill. Ισχύς γκριλ. -------------------------------------------------------------------------------------------------------- 1050 W • Potencia de salida microondas. Mikrowellenausgangsleistung. Microwave output power. Puissance de sortie micro-ondes. Potência de saída microondas. Uitgangsvermogen magnetron.
