Installation Manual
Table Of Contents:
Features and Options
Disarming Your System
Intrusion Signals and Tones
Valet Override, Programming & Safety Control Switch
Optional Remote Function Channels
Two Way Remote (Transceiver) Screen Icons & Indications
Two Way Remote Function Program Chart
New or Replacement Transmitters Programming
Functions At A Glance
Notes
PATENTED: www.voxxintl.com/company/patents
Rev b New Format 5/2013
Model APS-596C
5 Button Remote Security
System with Dual Stage
Shock Sensor
Owners Guide
Page 2
Page 3
Page 4
Page 5
Page 6
Page 6
Page 7
Page 7
Page 8 - 10
Page 10
Page 10
Page 11
Page 12
Page 13 - 16
Page 17
Page 18
Page 19
Page 20
128-8803b
1 of 20
Advertisement
Related Manuals for Audiovox APS-596C
Summary of Contents for Audiovox APS-596C
-
Page 1: Table Of Contents
Model APS-596C 5 Button Remote Security System with Dual Stage Shock Sensor Owners Guide Table Of Contents: Features and Options Page 2 Arming the System-Active Page 3 Protection While the System is Armed Page 4 Disarming Your System Page 5... - Page 2 IMPORTANT! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM"...
-
Page 3: Arming The System-Active
YOUR “ Code Hopping “ TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and retransmit at a later time to disarm your system. -
Page 4: Protection While The System Is Armed
2. Press and hold the Lock button on the keychain transmitter for 2 seconds. Dash mounted LED begins to flash slowly. Parking Lights flash one time. Siren will not sound. If the siren "chirped" three times, sometime after arming, the exclusive delayed dome light learn circuit has been programmed and the system detected a open entry point after the learned delay expired. - Page 5 Whenever the system is triggered, the vehicle’s parking lights will flash for the full 30 second alarm cycle, attracting visual attention to the vehicle. Optional - Whenever the system is armed, the vehicle’s starting circuit will be bypassed. If the thief should choose to ignore the siren, the vehicle can not be started.
-
Page 6: While The System Is Sounding
Open any door to suspend the automatic arming. Parking Lights flash two times. If the parking lights flashed three times, then the alarm was triggered in your absence. Before turning the key on, examine the LED to identify which zone was triggered. -
Page 7: Manually Overriding Your System
If the LED is flashing three times...pause...three times...pause...etc., then an intrusion attempt was made through one of the vehicle’s doors. These intrusion warning indicators are stored in the system’s memory and will only be erased when the ignition key is turned on. PUSH-BUTTON LED RECEIVER VALET/OVERRIDE/SAFETY CONTROLSWITCH The Push-Button LED switch located on the windshield receiver allows you to temporarily bypass all alarm functions, eliminating the need to hand your trans-... -
Page 8: Programming Your Custom Code Override
Programming Your Custom Override Code: Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security. To take advantage of this option, programmable feature # 10 must be selected for the Custom Code Option. - Page 9 1. Disarm the system by use of the transmitter, or by use of the emergency over- ride sequence. 2. Turn the ignition switch to the on position. 3. Within 10 seconds, press and release the Receivers Push-button switch, 3 times. 4.
-
Page 10: Eliminating The Normal Arm/Disarm Chirps
NOTE: The siren will sound. Within 5 seconds, press and release the Receivers Push-button switch 1 time. Within 5 seconds, turn the ignition switch off then on. Within 5 seconds, press and release the Receivers Push-button switch 1 time. Turn the ignition switch off then on and start the vehicle. NOTE: If you have changed the programmed override code then substitute your new code tenths for step 2 above, and units for step 5 above. - Page 11 or DISARM button is pressed and released, the Panic mode will be turned off immediately. The normal function of this transmitter button will be suspended during the Panic sounding period. 3. While in the Panic mode, pressing and releasing the ARM or DISARM buttons will, if the option is installed, lock and unlock the doors respectively.
-
Page 12: Telematic Upgrade
To activate the optional accessory, press the programmed button on the key- chain transmitter for up to 8 seconds for continuous output, or press and release for momentary activation. The optional accessory will immediately engage. Check with your installation center for more information on the optional accessory that may have been installed and how it is accessed. - Page 13 Included with your system is a two way remote transceiver that makes use of a LCD screen to ensure that the vehicle reacted to commands that you executed from the hand held transmitter(s). These screens are shown below for your reference.
- Page 14 If the alarm system has been triggered, the icon displayed on the transmitter LCD will in- dicate which zone has been activated, as well sound the beep tones, or vibrate dependent upon the setting as shown above. The fol- lowing trigger patterns will be displayed. Triggered and the entry attempt was made to one of the vehicle doors.
- Page 15 When the vehicle is armed and the vibration sensor input is active, the transmitter will chirp 3 times, the lights will flash and then the dis- play will flash as shown. When the input or the zone clears, the transmitter will chirp 1 time and the display will clear.
- Page 16 Parking Meter Counter: The transmitter has a built in clock that can count down from 10, 20, 30, 60, 90, or 120 minutes. This feature is useful when parking the vehicle in a metered parking lot. If the time on the parking meter is 30 minutes, you can set the count down timer to 20 minutes.
- Page 17 128-8803b 17 of 20...
- Page 18 PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1) Transmitter Model Name Is Found On Back Of Transmitter Case 1) Turn the ignition key to the on position. 2) Press and release the valet/programming switch 3 times (Siren Chirps). 3) Press the Lock Button of each transmitter you want programmed until you hear a chirp from the horn or siren.
- Page 19 Auto Unlock with ignition key Passive Arming No Lock in passive mode Hardwire doors, hood, and trunk Custom Code Override Valet Switch Override © 2013 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-8803b 128-8803b 19 of 20...
- Page 20 NOTES 128-8803b 20 of 20...
