Page 1 NBG4115 Wireless N-lite 3G Home Router Default Login Details IP Address http://192.168.1.1 Password 1234 Firmware Version 1.0 Edition 4, 10/2010 www.zyxel.com www.zyxel.com Copyright © 2010 ZyXEL Communications Corporation...
Page 3: About This User's Guide
User’s Guide PDF. Related Documentation • Quick Start Guide The Quick Start Guide is designed to help you get your NBG4115 up and running right away. It contains information on setting up your network and configuring for Internet access.
Page 4 About This User's Guide Documentation Feedback Send your comments, questions or suggestions to: techwriters@zyxel.com.tw Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 30099, Taiwan. Need More Help? More help is available at www.zyxel.com.
Page 5 ZyXEL office for the region in which you bought the device. See http://www.zyxel.com/web/contact_us.php for contact information. Please have the following information ready when you contact an office. • Product model and serial number. • Warranty Information. • Date that you received your device. NBG4115 User’s Guide...
Page 6: Document Conventions
Syntax Conventions • The NBG4115 may be referred to as the “NBG4115”, the “device”, the “product” or the “system” in this User’s Guide. • Product labels, screen names, field labels and field choices are all in bold font.
Page 7 Document Conventions Icons Used in Figures Figures in this User’s Guide may use the following generic icons. The NBG4115 icon is not an exact representation of your device. NBG4115 Computer Notebook computer Server DSLAM Firewall Telephone Switch Router Modem NBG4115 User’s Guide...
Page 8: Safety Warnings
Your product is marked with this symbol, which is known as the WEEE mark. WEEE stands for Waste Electronics and Electrical Equipment. It means that used electrical and electronic products should not be mixed with general waste. Used electrical and electronic equipment should be treated separately. NBG4115 User’s Guide...
Page 9: Table Of Contents
Static Route ..........................163 Bandwidth Management ......................167 Remote Management ......................175 UPnP ............................179 WoL ............................189 NetUSB ............................ 191 System ............................. 193 Logs ............................199 Tools ............................201 Sys OP Mode .......................... 207 Language ..........................211 Troubleshooting ........................213 NBG4115 User’s Guide...
Page 10 Contents Overview NBG4115 User’s Guide...
Page 11: Table Of Contents
Introduction ..........................21 1.1 Overview ..........................21 1.2 Applications ......................... 21 1.3 Ways to Manage the NBG4115 ................... 22 1.4 Good Habits for Managing the NBG4115 ................22 1.5 LEDs ............................ 22 Chapter 2 The WPS Button........................25 2.1 Overview ..........................25 Chapter 3 ZyXEL NetUSB Share Center Utility ..................
Page 12 5.6 Connection Wizard Complete ....................64 Chapter 6 AP Mode........................... 65 6.1 Overview ..........................65 6.2 Setting your NBG4115 to AP Mode ..................65 6.3 The Status Screen in AP Mode ................... 66 6.3.1 Navigation Panel ......................68 6.4 LAN Settings ........................69 6.5 WLAN and Maintenance Settings ..................
Page 13 Tutorials ........................... 73 7.1 Overview ..........................73 7.2 Set Up a 3G Connection ...................... 73 7.3 Set Up the NBG4115 for Gaming ..................75 7.4 Set Up a Wireless Network with WPS ................. 78 7.4.1 Push Button Configuration (PBC) ................78 7.4.2 PIN Configuration .......................
Page 14 12.5.5 Two Points To Remember About Trigger Ports ............148 Chapter 13 DDNS............................149 13.1 Overview ......................... 149 13.1.1 What You Can Do in this Chapter ................149 13.1.2 What You Need To Know ..................149 13.2 General .......................... 150 NBG4115 User’s Guide...
Page 15 17.3.5 Services and Port Numbers ................... 174 Chapter 18 Remote Management......................175 18.1 Overview .......................... 175 18.1.1 What You Can Do in this Chapter ................175 18.1.2 What You Need To Know ..................175 18.2 WWW ........................... 176 NBG4115 User’s Guide...
Page 16 23.2 View Log .......................... 199 Chapter 24 Tools............................201 24.1 Overview .......................... 201 24.1.1 What You Can Do in this Chapter ................201 24.2 Firmware .......................... 202 24.3 Configuration ........................204 24.3.1 Backup Configuration ..................... 204 24.3.2 Restore Configuration .................... 205 NBG4115 User’s Guide...
Page 17 27.2 Power, Hardware Connections, and LEDs ..............213 27.3 NBG4115 Access and Login .................... 214 27.4 Internet Access ........................ 216 27.5 Resetting the NBG4115 to Its Factory Defaults ............... 218 27.6 Wireless Router/AP Troubleshooting ................218 27.7 ZyXEL NetUSB Share Center Utility Problems ............... 220 Appendix A Product Specifications..................
Page 18 Table of Contents NBG4115 User’s Guide...
Page 19: User's Guide
User’s Guide...
Page 21: Introduction
1.2 Applications Your can create the following networks using the NBG4115: • Wired. You can connect network devices via the Ethernet ports of the NBG4115 so that they can communicate with each other and access the Internet. • Wireless. Wireless clients can connect to the NBG4115 to access network resources.
Page 22: Ways To Manage The Nbg4115
NBG4115 using a (supported) web browser. 1.4 Good Habits for Managing the NBG4115 Do the following things regularly to make the NBG4115 more secure and to manage the NBG4115 more effectively. • Change the password. Use a password that’s not easy to guess and that consists of different types of characters, such as numbers and letters.
Page 23 The NBG4115 is sending/receiving data through the LAN. The LAN is not connected. Green The NBG4115 has a 3G card installed and is communicating with routers. Blinking The NBG4115 is transmitting and/or receiving data from routers through an installed 3G card.
Page 24 Chapter 1 Introduction NBG4115 User’s Guide...
Page 25: The Wps Button
H A P T E R The WPS Button 2.1 Overview Your NBG4115 supports WiFi Protected Setup (WPS), which is an easy way to set up a secure wireless network. WPS is an industry standard specification, defined by the WiFi Alliance.
Page 26 Chapter 2 The WPS Button NBG4115 User’s Guide...
Page 27: Zyxel Netusb Share Center Utility
The ZyXEL NetUSB Share Center Utility allows you to work with the USB devices that are connected directly to the NBG4115 as if they are connected directly to your computer. This allows you to easily share USB-based devices such as...
Page 28: Quick Setup
NBG4115. Connect a USB device to the USB port on the NBG4115. Note: If you are connecting multiple devices to the NBG4115, first connect a USB hub to the NBG4115 then connect your other USB devices to it. Run the ZyXEL NetUSB Share Center Utility to display a list of all connected USB devices, then use it to connect your computer to them.
Page 29: The Zyxel Netusb Share Center Utility
To open the ZyXEL NetUSB Share Center Utility double-click its system tray icon. 3.2 The ZyXEL NetUSB Share Center Utility This section describes the ZyXEL NetUSB Share Center Utility main window. Figure 3 ZyXEL NetUSB Share Center Utility Main Window NBG4115 User’s Guide...
Page 30: The Menus
Table 2 ZyXEL NetUSB Share Center Utility Main Window Icons ICON DESCRIPTION Configure Server Click to open the NBG4115’s built-in Web Configurator, which you can use to set up the NBG4115 (see Chapter 4 on page 37 for details). Auto-Connect Printer Click this if you want to automatically connect to the printer each time your start your computer.
Page 31 Note: You first must install the appropriate drivers for the printer that you intend to use. Delete Auto-Connect Printer This removes the auto-connect option from the selected printer. NBG4115 User’s Guide...
Page 32: The Share Center Configuration Window
This section describes the utility’s configuration window, which allows you to set certain options for the utility. These options do not apply to the USB devices connected to the NBG4115. You can open it by clicking the Tools > Configuration menu command.
Page 33: The Auto-Connect Printer List Window
Click this to close the window. 3.3 Manually Connecting to USB Devices This example shows you how to connect to a USB device over your NBG4115 network. Makes sure that you have first installed the ZyXEL NetUSB Share Center Utility on the computer to which you want to connect the USB devices.
Page 34 Chapter 3 ZyXEL NetUSB Share Center Utility Connect a USB device to the NBG4115. In the ZyXEL NetUSB Share Center Utility, select the device and click Connect. NBG4115 User’s Guide...
Page 35: Automatically Connecting To A Usb Printer
This example shows you how to set your computer to automatically connect to a shared USB printer over your NBG4115 network each time you log into your computer. Makes sure that you have first installed the ZyXEL NetUSB Share Center Utility.
Page 36 Open the ZyXEL Sharing Center Utility on the computer that you want to use to connect to the printer. Click the Connect button. You may be prompted to install a printer driver or to configure other settings. Finally, click the Auto-Connect Printer menu and select Set Auto-Connect Printer from the menu. NBG4115 User’s Guide...
Page 37: The Web Configurator
Internet Explorer. 4.2 Accessing the Web Configurator Make sure your NBG4115 hardware is properly connected and prepare your computer or computer network to connect to the NBG4115 (refer to the Quick Start Guide). Launch your web browser. Type "http://192.168.1.1" as the website address.
Page 38 Select the setup mode you want to use. • Click Go to Wizard Setup to use the Configuration Wizard for basic Internet and Wireless setup. • Click Go to Advanced Setup to view and configure all the NBG4115’s settings. NBG4115 User’s Guide...
Page 39: Resetting The Nbg4115
If you forget your password or IP address, or you cannot access the Web Configurator, you will need to use the RESET button at the back of the NBG4115 to reload the factory-default configuration file. This means that you will lose all configurations that you had previously saved, the password will be reset to “1234”...
Page 40: The Status Screen In Router Mode
Table 6 Status Screen Icon Key ICON DESCRIPTION Click this icon to open the setup wizard. Click this icon to view copyright and a link for related product information. Click this icon at any time to exit the Web Configurator. NBG4115 User’s Guide...
Page 41 This is the firmware version and the date created. WAN Information - SIM Card Status (3G Only) When a 3G USB device is attached to the NBG4115, this provides information specific to it. - MAC Address This shows the WAN Ethernet adapter MAC Address of your device.
Page 42 3G Connection Status This displays the type of the 3G network (such as WCDMA) to which the NBG4115 is connected when the 3G connection is up or No Service when the 3G connection is down or not activated. Service Provider This displays the name of your network service provider.
Page 43: Navigation Panel
Use this screen to view the wireless stations that are currently associated to the NBG4115. 4.5.1 Navigation Panel Use the sub-menus on the navigation panel to configure NBG4115 features. The following table describes the sub-menus. Table 8 Screens Summary LINK...
Page 44 Wireless LAN General Use this screen to configure wireless LAN. MAC Filter Use the MAC filter screen to configure the NBG4115 to block access to devices or block the devices from accessing the NBG4115. Advanced This screen allows you to configure advanced wireless settings.
Page 45 LINK FUNCTION DHCP Server General Use this screen to enable the NBG4115’s DHCP server. Advanced Use this screen to assign IP addresses to specific individual computers based on their MAC addresses and to have DNS servers assigned by the DHCP server.
Page 46: Summary: Dhcp Table
TCP/IP configuration at start-up from a server. You can configure the NBG4115’s LAN as a DHCP server or disable it. When configured as a server, the NBG4115 provides the TCP/IP configuration for the clients. If DHCP service is disabled, you must have another DHCP server on that network, or else the computer must be manually configured.
Page 47: Summary: Packet Statistics
Table 10 Summary: Packet Statistics LABEL DESCRIPTION Port This is the NBG4115’s port type. Status For the LAN ports, this displays the port speed and duplex setting or Down when the line is disconnected. For the WAN port, it displays the port speed and duplex setting if you’re using Ethernet encapsulation and Idle (line (ppp) idle), Dial...
Page 48: Summary: Wlan Station Status
4.5.4 Summary: WLAN Station Status Click the WLAN Station Status (Details...) hyperlink in the Status screen. View the wireless stations that are currently associated to the NBG4115 in the Association List. Association means that a wireless client (for example, your network or computer with a wireless network card) has connected successfully to the AP (or wireless router) using the same SSID, channel and security settings.
Page 49: Connection Wizard
Guide to know what to enter in each field. Leave a field blank if you don’t have that information. After you access the NBG4115 Web Configurator, click the Go to Wizard setup hyperlink. You can click Go to Advanced setup hyperlink to skip this wizard setup and configure basic or advanced features accordingly.
Page 50: Step 1: System Information
• In Windows XP, click Start > My Computer > View system information and then click the Computer Name tab. Note the entry in the Full computer name field and enter it as the NBG4115 System Name. NBG4115 User’s Guide...
Page 51: Domain Name
LABEL DESCRIPTION System System Name is a unique name to identify the NBG4115 in an Ethernet Name network. Enter a descriptive name. This name can be up to 30 alphanumeric characters long. Spaces are not allowed, but dashes "-" and underscores "_"...
Page 52: Step 2: Wireless Lan
Enter a descriptive name (up to 32 printable 7-bit ASCII characters) for the (SSID) wireless LAN. If you change this field on the NBG4115, make sure all wireless stations use the same SSID in order to access the network. Security Select a Security level from the drop-down list box.
Page 53: Extend (Wpa-Psk Or Wpa2-Psk) Security
Chapter 5 Connection Wizard Note: The wireless stations and NBG4115 must use the same SSID, channel ID, WPA-PSK (if WPA-PSK is enabled) or WPA2-PSK (if WPA2-PSK is enabled) for wireless communication. 5.4.1 Extend (WPA-PSK or WPA2-PSK) Security Choose Extend (WPA-PSK) or Extend (WPA2-PSK) security in the Wireless LAN setup screen to set up a Pre-Shared Key.
Page 54: Ethernet Connection
Select the Mobile 3G option for a USB 3G connection. 5.5.1 Ethernet Connection Choose Ethernet when the WAN port is used as a regular Ethernet. Continue to Section 5.5.5 on page Figure 20 Wizard Step 3: Ethernet Connection NBG4115 User’s Guide...
Page 55: Pppoe Connection
By implementing PPPoE directly on the NBG4115 (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the NBG4115 does that part of the task. Furthermore, with NAT, all of the LAN's computers will have Internet access.
Page 56: Pptp Connection
Internet. Refer to the appendix for more information on PPTP. Note: The NBG4115 supports one PPTP server connection at any given time. Figure 22 Wizard Step 3: PPTP Connection The following table describes the fields in this screen...
Page 57 Select this radio button if your ISP did not assign you a fixed IP automatically address. from ISP Use fixed IP Select this radio button, provided by your ISP to give the NBG4115 a address fixed, unique IP address. My IP Type the (static) IP address assigned to you by your ISP.
Page 58: Mobile 3G
Mobile 3G is a set of international “third generation” standards for the sending and receiving of voice, video, and wireless data in a mobile environment. For the NBG4115, this type of wireless connection requires a connected 3G-compatible USB device (see the included Quick Start Guide for installation information), and a 3G account with your local ISP.
Page 59: Your Ip Address
5.5.5 Your IP Address The following wizard screen allows you to assign a fixed IP address or give the NBG4115 an automatically assigned IP address depending on your ISP or network administrator. Figure 24 Wizard Step 3: Your IP Address...
Page 60: Ip Address And Subnet Mask
Once you have decided on the network number, pick an IP address that is easy to remember, for instance, 192.168.1.1, for your NBG4115, but make sure that no other device on your network is using that IP address.
Page 61: Wan Ip And Dns Server Address Assignment
Chapter 5 Connection Wizard The NBG4115 can get the DNS server addresses in the following ways. The ISP tells you the DNS server addresses, usually in the form of an information sheet, when you sign up. If your ISP gives you DNS server addresses, enter them in the DNS Server fields in the Wizard and/or WAN >...
Page 62: Wan Mac Address
The DNS server is extremely important because without it, you must know the IP address of a computer before you can access it. The NBG4115 uses a system DNS server (in the order you specify here) to resolve domain names for DDNS and the time server.
Page 63 Select this option and enter the MAC address you want to use. Address Back Click Back to return to the previous screen. Next Click Next to continue. Exit Click Exit to close the wizard screen without saving. NBG4115 User’s Guide...
Page 64: Connection Wizard Complete
Chapter 5 Connection Wizard 5.6 Connection Wizard Complete Click Finish to complete the wizard setup. Figure 27 Connection Wizard Complete You have successfully set up your NBG4115 to operate on your network and access the Internet. NBG4115 User’s Guide...
Page 65: Ap Mode
AP mode. Use your NBG4115 as an AP if you already have a router or gateway on your network. In this mode your device bridges a wired network (LAN) and wireless LAN (WLAN) in the same subnet.
Page 66: The Status Screen In Ap Mode
Chapter 6 AP Mode To set your NBG4115 to AP Mode, go to Maintenance > Sys OP Mode > General and select Access Point. Figure 29 Maintenance > Sys OP Mode > General A pop-up appears providing information on this mode. Click OK in the pop-up message window.
Page 67 This shows the current status of the Wireless LAN - On, Off or Off by scheduler. - Name (SSID) This shows a descriptive name used to identify the NBG4115 in the wireless LAN. - Channel This shows the channel number which you select manually.
Page 68: Navigation Panel
Use this screen to view the wireless stations that are currently associated to the NBG4115. 6.3.1 Navigation Panel Use the menu in the navigation panel to configure NBG4115 features in AP Mode. The following screen and table show the features you can configure in AP Mode. Figure 31 Menu: AP Mode The following table describes the sub-menus.
Page 69: Lan Settings
Wireless General Use this screen to configure wireless LAN. MAC Filter Use the MAC filter screen to configure the NBG4115 to block access to devices or block the devices from accessing the NBG4115. Advanced This screen allows you to configure advanced wireless settings.
Page 70: Wlan And Maintenance Settings
Chapter 6 AP Mode Note: If you change the IP address of the NBG4115 in the screen below, you will need to log into the NBG4115 again using the new IP address. Figure 32 Network > LAN > IP The table below describes the labels in the screen.
Page 71: Logging In While In Ap Mode
6.6 Logging in while in AP Mode Connect your computer to the LAN port of the NBG4115. The default IP address of the NBG4115 is “192.168.1.2”. In this case, your computer must have an IP address in the range between “192.168.1.3” and “192.168.1.254”.
Page 72 Chapter 6 AP Mode NBG4115 User’s Guide...
Page 73: Tutorials
This chapter provides tutorials for setting up your NBG4115. 7.2 Set Up a 3G Connection This section shows you how to make a 3G connection with your NBG4115. There are two ways to set up your 3G options. Use the Wizard, which was introduced in the Quick Start Guide. The wizard is good for getting up and running in as little time as possible.
Page 74 Connect to the Web Configurator, as described in the Quick Start Guide. When presented with the option to choose either Wizard or Advanced, click Go to Advanced setup. Expand the Network submenu on the navigation pane, then click WAN. NBG4115 User’s Guide...
Page 75: Set Up The Nbg4115 For Gaming
Service (QoS) prioritization. If the data packets from a game are assigned a lower priority by the NBG4115, then they may take longer to reach their destination; but if they are given a higher priority, then they should arrive at their destination marginally faster.
Page 76 Chapter 7 Tutorials Bandwidth management allows you to set up custom parameters on the NBG4115 so that whenever you play a game, the QoS is automatically upgraded to the highest priority in order to ensure your game data packets are plucked first from the pool of incoming information and sent on ahead of lower priority packets.
Page 77 Chapter 7 Tutorials Enable the Gaming check box and set its Priority to High. The following gaming ports are preconfigured on your NBG4115 and are enabled when you select the ‘gaming’ Service in the Management > Bandwidth MGMT > Advanced screen:...
Page 78: Set Up A Wireless Network With Wps
7.4.1 Push Button Configuration (PBC) Make sure that your NBG4115 is turned on and that it is within range of your computer. Make sure that you have installed the wireless client (this example uses the NWD210N) driver and utility in your notebook.
Page 79 Log into NBG4115’s Web Configurator and press the Push Button button in the Network > Wireless Client > WPS Station screen. Note: Your NBG4115 has a WPS button located on its panel, as well as a WPS button in its configuration utility. Both buttons have exactly the same function; you can use one or the other.
Page 80: Pin Configuration
Chapter 7 Tutorials 7.4.2 PIN Configuration When you use the PIN configuration method, you need to use both NBG4115’s configuration interface and the client’s utilities. Launch your wireless client’s configuration utility. Go to the WPS settings and select the PIN method to get a PIN number.
Page 81: Configure Wireless Security Without Wps
WPA-PSK (Pre-Shared Key: ThisismyWPA-PSKpre-sharedkey) Follow the steps below to configure the wireless settings on your NBG4115. The instructions require that your hardware is connected (see the Quick Start Guide) and you are logged into the Web Configurator through your LAN connection (see Section 4.2 on page...
Page 82: Configure Your Notebook
Note: We use the ZyXEL M-302 wireless adapter utility screens as an example for the wireless client. The screens may vary for different models. The NBG4115 supports IEEE 802.11b, IEEE 802.11g and IEEE 802.11n wireless clients. Make sure that your notebook or computer’s wireless adapter supports one of these standards.
Page 83 Figure 37 Connecting a Wireless Client to a Wireless Network t Select WPA-PSK and type the security key in the following screen. Click Next. Figure 38 Security Settings The Confirm Save window appears. Check your settings and click Save to continue. Figure 39 Confirm Save NBG4115 User’s Guide...
Page 84: Bandwidth Management
7.6 Bandwidth Management This section shows you how to configure the bandwidth management feature on the NBG4115 to limit the bandwidth for specific kinds of outgoing traffic. ZyXEL's bandwidth management feature allows you to specify bandwidth management rules based on an application or subnet.
Page 85: Custom Bandwidth Management
E-mail. For the rest of the applications, click Enable if you need these services and set the priority to Low. Note: You can also leave the Enable field blank for the rest of the applications. In doing so, the NBG4115 does not apply bandwidth management to these services. 7.6.2 Custom Bandwidth Management Aside from the VOIP and e-mail services, you need to set the priority for MSN Messenger.
Page 86: Bandwidth Management By Ip Or Ip Range
TCP or UDP 554 VDO LIVE TCP 7000 TCP 20 ~ 21 Click the Edit icon in Management > Bandwidth MGMT > Advanced to open the following screen. The following screen appears. Figure 43 Tutorial: Bandwidth Allocation Example NBG4115 User’s Guide...
Page 87 Note: The Policy column displays either Max (maximum) or Min (minimum). This is directly directed to the value in the Rate column. For example, you selected Min and entered 30M as the rate for the VoIP service. The NBG4115 allocates at least 30 megabytes for the VoIP service.
Page 88 Chapter 7 Tutorials NBG4115 User’s Guide...
Page 89: Technical Reference
Technical Reference...
Page 91: Wireless Lan
Wireless LAN 8.1 Overview This chapter discusses how to configure the wireless network settings in your NBG4115. See the appendices for more detailed information about wireless networks. The following figure provides an example of a wireless network. Figure 45 Example of a Wireless Network The wireless network is the part in the blue circle.
Page 92: What You Can Do In This Chapter
• Use the MAC Filter screen (Section 8.3 on page 100) to allow or deny wireless stations based on their MAC addresses from connecting to the NBG4115. • Use the Advanced screen (Section 8.4 on page 102) to allow intra-BSS networking and set the RTS/CTS Threshold.
Page 93 Some wireless devices, such as scanners, can detect wireless networks but cannot use wireless networks. These kinds of wireless devices might not have MAC addresses. Hexadecimal characters are 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, A, B, C, D, E, and F. NBG4115 User’s Guide...
Page 94 When you select WPA2 or WPA2-PSK in your NBG4115, you can also select an option (WPA Compatible) to support WPA as well. In this case, if some wireless...
Page 95: General
Use this screen to enable the Wireless LAN, enter the SSID and select the wireless security mode. Note: If you are configuring the NBG4115 from a computer connected to the wireless LAN and you change the NBG4115’s SSID, channel or security settings, you will lose your wireless connection when you press Apply to confirm.
Page 96 This displays the channel the NBG4115 is currently using. Channel Channel Select whether the NBG4115 uses a wireless channel width of 20 or 40 Width MHz. A standard 20 MHz channel offers transfer speeds of up to 150Mbps whereas a 40MHz channel uses two standard channels and offers speeds of up to 300 Mbps.
Page 97: No Security
Select No Security to allow wireless stations to communicate with the access points without any data encryption. Note: If you do not enable any wireless security on your NBG4115, your network is accessible to any wireless networking device that is within range.
Page 98 ZyXEL Device occurs. Select Shared Key to force the clients to provide the WEP key prior to communication. ASCII Select this option in order to enter ASCII characters as WEP key. NBG4115 User’s Guide...
Page 99: Wpa-Psk/Wpa2-Psk
Key 1 to Key The WEP keys are used to encrypt data. Both the NBG4115 and the wireless stations must use the same WEP key for data transmission. If you chose 64-bit WEP, then enter any 5 ASCII characters or 10 hexadecimal characters ("0-9", "A-F").
Page 100: Mac Filter
Click Reset to reload the previous configuration for this screen. 8.3 MAC Filter The MAC filter screen allows you to configure the NBG4115 to give exclusive access to up to 16 devices (Allow) or exclude up to 16 devices from accessing the NBG4115 (Deny).
Page 101 Chapter 8 Wireless LAN To change your NBG4115’s MAC filter settings, click Network > Wireless LAN > MAC Filter. The screen appears as shown. Figure 50 Network > Wireless LAN > MAC Filter The following table describes the labels in this menu.
Page 102: Advanced
This value can be set from 1 to 100. Preamble A preamble affects the timing in your wireless network. There are two preamble modes: long and short. If a device uses a different preamble mode than the NBG4115 does, it cannot communicate with the NBG4115. NBG4115 User’s Guide...
Page 103 When set to Always, the NBG4115 improves performance within mixed wireless modes. Select Auto to let the NBG4115 determine whether to turn this feature on or off in the current environment. Tx Power This field controls the transmission power of the NBG4115. When using...
Page 104: Qos
LABEL DESCRIPTION WMM QoS Policy Select Default to have the NBG4115 automatically give a service a priority level according to the ToS value in the IP header of packets it sends. WMM QoS (Wifi MultiMedia Quality of Service) gives high priority to voice and video, which makes them run more smoothly.
Page 105: Application Priority Configuration
Configuration screen. Click the Remove icon to delete an application entry. Apply Click Apply to save your changes to the NBG4115. 8.5.1 Application Priority Configuration Use this screen to edit a WMM QoS application entry. Click the edit icon under Modify.
Page 106 Priority Select a priority from the drop-down list box. Apply Click Apply to save your changes back to the NBG4115. Cancel Click Cancel to return to the previous screen. NBG4115 User’s Guide...
Page 107: Wps
This displays Unconfigured if WPS is disabled and there are no wireless or wireless security changes on the NBG4115 or you click Release_Configuration to remove the configured wireless and wireless security settings.
Page 108: Wps Station
Table 37 WPS LABEL DESCRIPTION Apply Click Apply to save your changes back to the NBG4115. Refresh Click Refresh to get this screen information afresh. 8.7 WPS Station Use this screen when you want to add a wireless station using WPS. To open this screen, click Network >...
Page 109: Scheduling
Select Everyday or the specific days to turn the Wireless LAN on or off. If you select Everyday you can not select any specific days. This field works in conjunction with the Except for the following times field. NBG4115 User’s Guide...
Page 110 Note: Entering the same begin time and end time will mean the whole day. Apply Click Apply to save your changes back to the NBG4115. Reset Click Reset to reload the previous configuration for this screen. NBG4115 User’s Guide...
Page 111: Wan
Area Network) and other networks, so that a computer in one location can communicate with computers in other locations. The NBG4115 also supports a 3G WAN connection. You can use 3G as your primary WAN or use the 3G WAN connection as a backup.
Page 112: What You Need To Know
(and service name) for user authentication. WAN IP Address The WAN IP address is an IP address for the NBG4115, which makes it accessible from an outside network. It is used by the NBG4115 to communicate with other devices in other networks. It can be static (fixed) or dynamically assigned by the ISP each time the NBG4115 tries to access the Internet.
Page 113 DNS server fields. If your ISP dynamically assigns the DNS server IP addresses (along with the NBG4115’s WAN IP address), set the DNS server fields to get the DNS server address from the ISP. WAN MAC Address...
Page 114 Auto-Bridge In the rear panel of your NBG4115, you can see two LAN ports (1 to 2) and one WAN port. The WAN port is for your Internet access connection, and the LAN ports are for your network devices.
Page 115: The General Screen
Chapter 9 WAN Auto-IP-Change When the NBG4115 gets a WAN IP address which is in the same subnet as the LAN IP address 192.168.1.1, Auto-IP-Change allows the NBG4115 to change its LAN IP address to 10.0.0.1 automatically. If the NBG4115’s original LAN IP address is 10.0.0.1 and the WAN IP address is in the same subnet, such as 10.0.0.3, the...
Page 116 3G wireless adapter connected to the USB port on the NBG4115. Operation Mode Active/ The NBG4115 uses the second highest priority WAN interface as a back Passive(Fail up. This means that the NBG4115 will normally use the highest priority Over) Mode (primary) WAN interface (depending on the priority you configure in the Primary WAN fields).
Page 117: The Wan1 Internet Connection Screen
Check Timeout Type the number of seconds (1 to 10) for your NBG4115 to wait for a response to the ping before considering the check to have failed. This setting must be less than the Check Period. Use a higher value in this field if your network is busy or congested.
Page 118: Ethernet
Enter your WAN IP address in this field if you selected Use Fixed IP Address. IP Subnet Enter the IP Subnet Mask in this field. Mask Gateway IP Enter a Gateway IP Address in this field. Address DNS Servers NBG4115 User’s Guide...
Page 119: Pppoe
DESCRIPTION First DNS Server Select From ISP if your ISP dynamically assigns DNS server information (and the NBG4115's WAN IP address). The field to the right Second DNS displays the (read-only) DNS server IP address that the ISP assigns. Server Select User-Defined if you have the IP address of a DNS server.
Page 120 By implementing PPPoE directly on the NBG4115 (rather than individual computers), the computers on the LAN do not need PPPoE software installed, since the NBG4115 does that part of the task. Furthermore, with NAT, all of the LANs’ computers will have access.
Page 121: Pptp
DESCRIPTION First DNS Select From ISP if your ISP dynamically assigns DNS server information Server (and the NBG4115's WAN IP address). The field to the right displays the (read-only) DNS server IP address that the ISP assigns. Second DNS Server Select User-Defined if you have the IP address of a DNS server.
Page 122 PPTP supports on-demand, multi-protocol, and virtual private networking over public networks, such as the Internet. The NBG4115 supports only one PPTP server connection at any given time. To configure a PPTP client, you must configure the User Name and Password fields for a PPP connection and the PPTP parameters for a PPTP connection.
Page 123 DNS Servers First DNS Server Select From ISP if your ISP dynamically assigns DNS server information (and the NBG4115's WAN IP address). The field to the Second DNS Server right displays the (read-only) DNS server IP address that the ISP assigns.
Page 124: Mobile 3G
Set WAN MAC Select this option and enter the MAC address you want to use. Address Apply Click Apply to save your changes back to the NBG4115. Reset Click Reset to begin configuring this screen afresh. 9.4.4 Mobile 3G 3G is an International Telecommunication Union (ITU) mobile networking standard that provides high-speed connectivity, greater network capacity, and a significantly improved broadcast range to compatible devices.
Page 125 DNS Servers First DNS Server Select From ISP if your ISP dynamically assigns DNS server information (and the NBG4115's WAN IP address). The field to the Second DNS Server right displays the (read-only) DNS server IP address that the ISP assigns.
Page 126: The Advanced Screen
Auto-bridge or Auto-IP-Change. Note: The three categories shown in this screen are independent of each other. To change your NBG4115’s advanced WAN settings, click Network > WAN > Advanced. The screen appears as shown. Figure 65 Network > WAN > Advanced...
Page 127 Auto-Subnet Configuration None Select this option to have the NBG4115 do nothing when it gets a WAN IP address in the range of 192.168.x.y (where x and y are from zero to nine) or in the same subnet as the LAN IP address.
Page 128 Chapter 9 WAN NBG4115 User’s Guide...
Page 129: Lan
10.1.1 What You Can Do in this Chapter Use the IP (Section 10.3 on page 131) screen to change your basic LAN settings. 10.2 What You Need To Know The following terms and concepts may help as you read through this chapter. NBG4115 User’s Guide...
Page 130 WAN network as shown next. Figure 66 LAN and WAN IP Addresses The LAN parameters of the NBG4115 are preset in the factory with the following values: • IP address of 192.168.1.1 with subnet mask of 255.255.255.0 (24 bits) •...
Page 131 Table 46 Network > LAN > IP LABEL DESCRIPTION IP Address Type the IP address of your NBG4115 in dotted decimal notation 192.168.1.1 (factory default). IP Subnet Mask The subnet mask specifies the network number portion of an IP address. Your NBG4115 will automatically calculate the subnet mask based on the IP address that you assign.
Page 132 Chapter 10 LAN NBG4115 User’s Guide...
Page 133: Dhcp Server
TCP/IP configuration at start-up from a server. You can configure the NBG4115’s LAN as a DHCP server or disable it. When configured as a server, the NBG4115 provides the TCP/IP configuration for the clients. If DHCP service is disabled, you must have another DHCP server on your LAN, or else the computer must be manually configured.
Page 134: General
Leave the Enable DHCP Server check box selected unless your ISP instructs you to do otherwise. Clear it to disable the NBG4115 acting as a DHCP server. When configured as a server, the NBG4115 provides TCP/IP configuration for the clients.
Page 135: Advanced
This screen allows you to assign IP addresses on the LAN to specific individual computers based on their MAC addresses. You can also use this screen to configure the DNS server information that the NBG4115 sends to the DHCP clients.
Page 136: Client List
User-Defined, and enter the same IP address, the second User- Defined changes to None after you click Apply. Select DNS Relay to have the NBG4115 act as a DNS proxy. The NBG4115's LAN IP address displays in the field to the right (read- only).
Page 137 Reserve Select this check box in the DHCP Setup section to have the NBG4115 always assign the IP address(es) to the MAC address(es) (and host name(s)). After you click Apply, the MAC address and IP address also display in the Advanced screen (where you can edit them).
Page 138 Chapter 11 DHCP Server NBG4115 User’s Guide...
Page 139: Nat
You assign the LAN IP addresses to the devices (A to D) connected to your NBG4115. The ISP assigns the WAN IP address. The NAT network appears as a single host on the Internet. All traffic coming from A to D going out to the Internet use the IP address of the NBG4115, which is 192.168.1.1.
Page 140: What You Can Do In This Chapter
The following terms and concepts may help as you read through this chapter. Inside/Outside This denotes where a host is located relative to the NBG4115, for example, the computers of your subscribers are the inside hosts, while the web servers on the Internet are the outside hosts.
Page 141 It replaces the original IP source address in each packet and then forwards it to the Internet. The NBG4115 keeps track of the original addresses and port numbers so incoming reply packets can have their original values restored. The following figure illustrates this.
Page 142: General
A default server receives packets from ports that are not specified in the Application screen. If you do not assign a Default Server IP address, the NBG4115 discards all packets received for ports that are not specified in the Application screen or remote management.
Page 143: Application
Network > NAT > Application. The screen appears as shown. Note: If you do not assign a Default Server IP address in the NAT > General screen, the NBG4115 discards all packets received for ports that are not specified in this screen or remote management.
Page 144 This field displays the inside IP address of the server. Address Modify Click the Edit icon to display and modify an existing rule setting in the fields under Add Application Rule. Click the Remove icon to delete a rule. NBG4115 User’s Guide...
Page 145: Advanced
Trigger The trigger port is a port (or a range of ports) that causes (or triggers) the NBG4115 to record the IP address of the LAN computer that sent the traffic to a server on the WAN. Start Port Type a port number or the starting port number in a range of port numbers.
Page 146: Technical Reference
Table 53 Network > NAT > Advanced LABEL DESCRIPTION Apply Click Apply to save your changes back to the NBG4115. Reset Click Reset to begin configuring this screen afresh. 12.5 Technical Reference The following section contains additional technical information about the NBG4115 features described in this chapter.
Page 147: Trigger Port Forwarding
(a "trigger" port). When the NBG4115's WAN port receives a response with a specific port number and protocol ("incoming" port), the NBG4115 forwards the traffic to the LAN IP address of the computer that sent the request. After that computer’s connection for that service closes, another computer on the LAN can use the service in the same manner.
Page 148: Trigger Port Forwarding Example
Figure 77 Trigger Port Forwarding Process: Example Jane requests a file from the Real Audio server (port 7070). Port 7070 is a “trigger” port and causes the NBG4115 to record Jane’s computer IP address. The NBG4115 associates Jane's computer IP address with the "incoming"...
Page 149: Ddns
Use the DDNS screen (Section 13.2 on page 150) to enable DDNS and configure the DDNS settings on the NBG4115. 13.1.2 What You Need To Know The following terms and concepts may help as you read through this chapter. What is DDNS?
Page 150: General
Chapter 13 DDNS 13.2 General To change your NBG4115’s DDNS, click Network > DDNS. The screen appears as shown. Figure 78 Dynamic DNS The following table describes the labels in this screen. Table 54 Dynamic DNS LABEL DESCRIPTION Dynamic DNS Setup Enable Dynamic Select this check box to use dynamic DNS.
Page 151 Type the IP address of the host name(s). Use this if you have a Address static IP address. Apply Click Apply to save your changes back to the NBG4115. Reset Click Reset to begin configuring this screen afresh. NBG4115 User’s Guide...
Page 152 Chapter 13 DDNS NBG4115 User’s Guide...
Page 153: Firewall
H A P T E R Firewall 14.1 Overview Use these screens to enable and configure the firewall that protects your NBG4115 and your LAN from unwanted or malicious traffic. Enable the firewall to protect your LAN computers from attacks by hackers on the Internet and control access between the LAN and WAN.
Page 154: What You Need To Know
It is a stateful inspection firewall and is designed to protect against Denial of Service attacks when activated (click the General tab under Firewall and then click the Enable Firewall check box). The NBG4115's purpose is to allow a private Local Area Network (LAN) to be securely connected to the Internet. The NBG4115 can be used to prevent theft, destruction and modification of data, as well as log events, which may be important to the security of your network.
Page 155 Chapter 14 Firewall The NBG4115 has one Ethernet WAN port and four Ethernet LAN ports, which are used to physically separate the network into two areas.The WAN (Wide Area Network) port attaches to the broadband (cable or DSL) modem to the Internet.
Page 156: General
Chapter 14 Firewall 14.2 General Use this screen to enable or disable the NBG4115’s firewall, and set up firewall logs. Click Security > Firewall to open the General screen. Figure 80 Security > Firewall > General l The following table describes the labels in this screen.
Page 157 Do not respond Select this option to prevent hackers from finding the NBG4115 by to requests for probing for unused ports. If you select this option, the NBG4115 will not unauthorized respond to port request(s) for unused ports, thus leaving the unused services ports and the NBG4115 unseen.
Page 158 Chapter 14 Firewall NBG4115 User’s Guide...
Page 159: Content Filtering
A content filtering profile conveniently stores your custom settings for the following features. Keyword Blocking URL Checking The NBG4115 checks the URL’s domain name (or IP address) and file path separately when performing keyword blocking. The URL’s domain name or IP address is the characters that come before the first slash in the URL.
Page 160: Filter
URL www.zyxel.com.tw/news/pressroom.php, the file path is news/pressroom.php. Since the NBG4115 checks the URL’s domain name (or IP address) and file path separately, it will not find items that go across the two. For example, with the URL www.zyxel.com.tw/news/pressroom.php, the NBG4115 would find “tw”...
Page 161: Technical Reference
Domain Name or IP Address URL Checking By default, the NBG4115 checks the URL’s domain name or IP address when performing keyword blocking. This means that the NBG4115 checks the characters that come before the first slash in the URL.
Page 162 (or not extend) the keyword blocking search to include the URL's full path. File Name URL Checking Filename URL checking has the NBG4115 check all of the characters in the URL. For example, filename URL checking searches for keywords within the URL www.zyxel.com.tw/news/pressroom.php.
Page 163: Static Route
This chapter shows you how to configure static routes for your NBG4115. The NBG4115 usually uses the default gateway to route outbound traffic from computers on the LAN to the Internet. To have the NBG4115 send data to devices not reachable through the default gateway, use static routes.
Page 164: Ip Static Route
NBG4115 that will forward the packet to the destination. On the LAN, the gateway must be a router on the same segment as your NBG4115; over the WAN, the gateway must be the IP address of one of the remote nodes.
Page 165: Static Route Setup Screen
NBG4115 that will forward the packet to the destination. On the LAN, the gateway must be a router on the same segment as your NBG4115; over the WAN, the gateway must be the IP address of one of the Remote Nodes.
Page 166 Chapter 16 Static Route NBG4115 User’s Guide...
Page 167: Bandwidth Management
• Use the Advanced screen (Section 17.3 on page 169) to configure bandwidth management rules for the pre-defined services and applications. 17.1.2 What You Need To Know The following terms and concepts may help as you read through this chapter. NBG4115 User’s Guide...
Page 168: General
Note: You cannot apply both bandwidth management types at the same time. Click Management > Bandwidth MGMT to open the bandwidth management General screen. Figure 87 Management > Bandwidth MGMT > General NBG4115 User’s Guide...
Page 169: Advanced
Table 60 Management > Bandwidth MGMT > General LABEL DESCRIPTION Service Management Bandwidth This field allows you to have NBG4115 apply bandwidth management. Management Select Priority Queue or Bandwidth Allocation to enable Type bandwidth management. Select Priority Queue to allocate bandwidth based on the pre-defined priority assigned to an application.
Page 170 Use this table to allocate specific amounts of bandwidth based on the pre-defined service. This is the number of an individual bandwidth management rule. Enable Select this check box to have the NBG4115 apply this bandwidth management rule. NBG4115 User’s Guide...
Page 171 IP or IP range. This is the number of an individual bandwidth management rule. Enable Select this check box to have the NBG4115 apply this bandwidth management rule. LAN IP Range This displays the range of IP addresses for which the bandwidth management rule applies.
Page 172: Pre-Configured Gaming Ports
Chapter 17 Bandwidth Management 17.3.1 Pre-Configured Gaming Ports The following gaming ports are preconfigured on your NBG4115 and are enabled when you select the ‘gaming’ Service in this screen: Table 62 Preconfigured Gaming Ports APPLICATION TCP PORTS UDP PORTS XBox 360...
Page 173: Predefined Bandwidth Management Services
To WAN applies bandwidth management to traffic from LAN/WLAN to WAN (i.e., uplink). Select Both applies bandwidth management to traffic that the NBG4115 forwards to both the LAN and the WAN. LAN IP Range Specify the range of IP addresses for which the bandwidth management rule applies.
Page 174: Services And Port Numbers
Online gaming services lets you play multiplayer games on the Internet via broadband technology. One example is Microsoft’s Xbox Live, which uses port 3074. As of this writing, your NBG4115 supports Xbox, Playstation, Battlenet and MSN Game Zone. 17.3.5 Services and Port Numbers Appendix F on page 293 for commonly used services and port numbers.
Page 175: Remote Management
You have disabled that service in one of the remote management screens. The IP address in the Secured Client IP Address field does not match the client IP address. If it does not match, the NBG4115 will disconnect the session immediately.
Page 176: Www
Chapter 18 Remote Management Remote Management and NAT When NAT is enabled: • Use the NBG4115’s WAN IP address when configuring from the WAN. • Use the NBG4115’s LAN IP address when configuring from the LAN. System Timeout There is a default system management idle timeout of five minutes (three hundred seconds).
Page 177 A secured client is a “trusted” computer that is allowed to communicate IP Address with the NBG4115 using this service. Select All to allow any computer to access the NBG4115 using this service. Choose Selected to just allow the computer with the IP address that you specify to access the NBG4115 using this service.
Page 178 Chapter 18 Remote Management NBG4115 User’s Guide...
Page 179: Upnp
NAT. UPnP network devices can automatically configure network addressing, announce their presence in the network to other UPnP devices and enable exchange of simple product and service descriptions. NAT traversal allows the following: • Dynamic port mapping NBG4115 User’s Guide...
Page 180: General
When a UPnP device joins a network, it announces its presence with a multicast message. For security reasons, the NBG4115 allows multicast messages on the LAN only. All UPnP-enabled devices may communicate freely with each other without additional configuration.
Page 181: Technical Reference
Reset Click Reset to begin configuring this screen afresh. 19.3 Technical Reference The following section contains additional technical information about the NBG4115 features described in this chapter. 19.3.1 Installing UPnP in Windows XP Follow the steps below to install the UPnP in Windows XP.
Page 182: Using Upnp In Windows Xp Example
This section shows you how to use the UPnP feature in Windows XP. You must already have UPnP installed in Windows XP and UPnP activated on the NBG4115. Make sure the computer is connected to a LAN port of the NBG4115. Turn on your computer and the NBG4115.
Page 183 Click Start and Control Panel. Double-click Network Connections. An icon displays under Internet Gateway. Right-click the icon and select Properties. Figure 95 Network Connections In the Internet Connection Properties window, click Settings to see the port mappings there were automatically created. Figure 96 Internet Connection Properties NBG4115 User’s Guide...
Page 184 When the UPnP-enabled device is disconnected from your computer, all port mappings will be deleted automatically. Select Show icon in notification area when connected option and click OK. An icon displays in the system tray. Figure 99 System Tray Icon NBG4115 User’s Guide...
Page 185 Web Configurator Easy Access With UPnP, you can access the web-based configurator on the NBG4115 without finding out the IP address of the NBG4115 first. This comes helpful if you do not know the IP address of the NBG4115. Follow the steps below to access the Web Configurator.
Page 186 Figure 101 Network Connections An icon with the description for each UPnP-enabled device displays under Local Network. Right-click on the icon for your NBG4115 and select Invoke. The Web Configurator login screen displays. Figure 102 Network Connections: My Network Places...
Page 187 Chapter 19 UPnP Right-click on the icon for your NBG4115 and select Properties. A properties window displays with basic information about the NBG4115. Figure 103 Network Connections: My Network Places: Properties: Example NBG4115 User’s Guide...
Page 188 Chapter 19 UPnP NBG4115 User’s Guide...
Page 189: Wol
20.2 The WoL General Screen Use this screen to remotely turn on a device on the network. Click the Management > WoL to open the following screen. Figure 104 Management > WoL NBG4115 User’s Guide...
Page 190 Settings Enable WOL over WAN Select this option to have the NBG4115 forward a WoL “Magic Packet” to all devices on the LAN if the packet comes from the WAN or remote network and uses the port number specified in the Server Port field.
Page 191: Netusb
The following terms and concepts may help as you read through this chapter. NetUSB This is the name of the feature on the NBG4115 that allows you to share USB devices that are connected to the NBG4115 with the rest of the network. NetUSB supports both standard USB devices and 3G USB devices.
Page 192: The Netusb General Screen
LABEL DESCRIPTION Auto Mode Select this to allow the NBG4115 to support both 3G wireless and NetUSB functionality through its USB port. If you connect a USB hub and then a 3G USB dongle, the NBG4115 can support both concurrently.
Page 193: System
195) to change your NBG4115’s time and date. 22.2 General Use this screen to enter a name to identify the NBG4115 in the network and set the password. Click Maintenance > System. The following screen displays. Figure 106 Maintenance > System > General...
Page 194 DESCRIPTION System Setup System Name System Name is a unique name to identify the NBG4115 in an Ethernet network. It is recommended you enter your computer’s “Computer name” in this field (see the chapter about wizard setup for how to find your computer’s name).
Page 195: Time Setting
Chapter 22 System 22.3 Time Setting To change your NBG4115’s time and date, click Maintenance > System > Time Setting. The screen appears as shown. Use this screen to configure the NBG4115’s time based on your local time zone. Figure 107 Maintenance > System > Time Setting he following table describes the labels in this screen.
Page 196 When you set Time and Date Setup to Manual, enter the new date in this field and then click Apply. Get from Time Select this radio button to have the NBG4115 get the time and date Server from the time server you specified below.
Page 197 Germany for instance, you would type 2 because Germany's time zone is one hour ahead of GMT or UTC (GMT+1). Apply Click Apply to save your changes back to the NBG4115. Reset Click Reset to begin configuring this screen afresh.
Page 198 Chapter 22 System NBG4115 User’s Guide...
Page 199: Logs
This chapter contains information about configuring general log settings and viewing the NBG4115’s logs. Refer to the appendices for example log message explanations. The Web Configurator allows you to look at all of the NBG4115’s logs in one location. 23.1.1 What You Can Do in this Chapter Use the View Log screen (Section 23.2 on page...
Page 200 This is the index number of the log entry. Time This field displays the time the log was recorded. See the chapter on system maintenance and information to configure the NBG4115’s time and date. Message This field states the reason for the log.
Page 201: Tools
Tools 24.1 Overview This chapter shows you how to upload a new firmware, upload or save backup configuration files and restart the NBG4115. 24.1.1 What You Can Do in this Chapter • Use the Firmware screen (Section 24.2 on page 202) to upload firmware to your NBG4115.
Page 202: Firmware
(.zip) files before you can upload them. Upload Click Upload to begin the upload process. This process may take up to two minutes. Note: Do not turn off the NBG4115 while firmware upload is in progress! NBG4115 User’s Guide...
Page 203 After you see the Firmware Upload In Process screen, wait two minutes before logging into the NBG4115 again. Figure 110 Upload Warning The NBG4115 automatically restarts in this time causing a temporary network disconnect. In some operating systems, you may see the following icon on your desktop.
Page 204: Configuration
24.3.1 Backup Configuration Backup configuration allows you to back up (save) the NBG4115’s current configuration to a file on your computer. Once your NBG4115 is configured and functioning properly, it is highly recommended that you back up your configuration file before making configuration changes. The backup configuration file will be useful in case you need to return to your previous settings.
Page 205: Restore Configuration
Upload Click Upload to begin the upload process. Note: Do not turn off the NBG4115 while configuration file upload is in progress After you see a “configuration upload successful” screen, you must then wait one minute before logging into the NBG4115 again.
Page 206: Back To Factory Defaults
Configurator for more information on the RESET button. 24.4 Restart System restart allows you to reboot the NBG4115 without turning the power off. Click Maintenance > Tools > Restart. Click Restart to have the NBG4115 reboot. This does not affect the NBG4115's configuration.
Page 207: Sys Op Mode
25.1 Overview The Sys OP Mode (System Operation Mode) function lets you configure whether your NBG4115 is a router or AP. You can choose between Router Mode and AP Mode depending on your network topology and the features you require from your device.
Page 208: General
Use this screen to select how you connect to the Internet. Figure 120 Maintenance > Sys OP Mode > General If you select Router Mode, the following pop-up message window appears. Figure 121 Maintenance > Sys Op Mode > General: Router NBG4115 User’s Guide...
Page 209 Select Access Point if your device bridges traffic between clients on the same network. Apply Click Apply to save your settings. Reset Click Reset to return your settings to the default (Router) Note: If you select the incorrect System Operation Mode you cannot connect to the Internet. NBG4115 User’s Guide...
Page 210 Chapter 25 Sys OP Mode NBG4115 User’s Guide...
Page 211: Language
This chapter shows you how to change the Web Configurator’s display language. 26.2 Language Use this screen to change the language for the Web Configurator display. Click the language you prefer. The Web Configurator language changes after a while without restarting the NBG4115. Figure 123 Language NBG4115 User’s Guide...
Page 212 Chapter 26 Language NBG4115 User’s Guide...
Page 213: Troubleshooting
Make sure you are using the power adaptor or cord included with the NBG4115. Make sure the power adaptor or cord is connected to the NBG4115 and plugged in to an appropriate power source. Make sure the power source is turned on.
Page 214: Nbg4115 Access And Login
IP address from a DHCP server on the network. If your NBG4115 is a DHCP client, you can find your IP address from the DHCP server. This information is only available from the DHCP server which allocates IP addresses on your network.
Page 215 Appendix B on page 225. Make sure your computer is in the same subnet as the NBG4115. (If you know that there are routers between your computer and the NBG4115, skip this step.) • If there is a DHCP server on your network, make sure your computer is using a dynamic IP address.
Page 216: Internet Access
AP. • Go to Network > Wireless LAN > General > WDS and check if the NBG4115 is set to bridge mode. Select Disable and try to connect to the Internet again.
Page 217 Internet, especially peer-to-peer applications. Check the signal strength. If the signal strength is low, try moving the NBG4115 closer to the AP if possible, and look around to see if there are any devices that might be interfering with the wireless network (for example, microwaves, other wireless networks, and so on).
Page 218: Resetting The Nbg4115 To Its Factory Defaults
27.5 Resetting the NBG4115 to Its Factory Defaults If you reset the NBG4115, you lose all of the changes you have made. The NBG4115 re-loads its default settings, and the password resets to 1234. You have to make all of your changes again.
Page 219 Chapter 27 Troubleshooting Check that both the NBG4115 and your wireless station are using the same wireless and wireless security settings. Make sure traffic between the WLAN and the LAN is not blocked by the firewall on the NBG4115. Make sure you allow the NBG4115 to be remotely accessed through the WLAN interface.
Page 220: Zyxel Netusb Share Center Utility Problems
27.7 ZyXEL NetUSB Share Center Utility Problems I cannot access or see a USB device that is connected to the NBG4115. Disconnect the problematic USB device, then reconnect it to the NBG4115. Ensure that the USB device in question has power.
Page 221: Appendix A Product Specifications
USB Port The NBG4115 has one built-in USB 2.0 type A for 3G connectivity. When a 3G card is plugged in and operational this port functions as a WAN port.
Page 222 Configuration Backup & Make a copy of the NBG4115’s configuration and put it back on Restoration the NBG4115 later if you decide you want to revert back to an earlier configuration. Network Address Each computer on your network must have its own unique IP Translation (NAT) address.
Page 223 Time and Date Get the current time and date from an external server when you turn on your NBG4115. You can also set the time manually. These dates and times are then used in logs. Port Forwarding If you have a server (mail or web server for example) on your network, then use this feature to let people access it from the Internet.
Page 224 Appendix A Product Specifications NBG4115 User’s Guide...
Page 225: Appendix B Pop-Up Windows, Javascripts And Java Permissions
Disable Pop-up Blockers In Internet Explorer, select Tools, Pop-up Blocker and then select Turn Off Pop-up Blocker. Figure 124 Pop-up Blocker You can also check if pop-up blocking is disabled in the Pop-up Blocker section in the Privacy tab. NBG4115 User’s Guide...
Page 226 Click Apply to save this setting. Enable Pop-up Blockers with Exceptions Alternatively, if you only want to allow pop-up windows from your device, see the following steps. In Internet Explorer, select Tools, Internet Options and then the Privacy tab. NBG4115 User’s Guide...
Page 227 Select Settings…to open the Pop-up Blocker Settings screen. Figure 126 Internet Options: Privacy Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.167.1. NBG4115 User’s Guide...
Page 228 Figure 127 Pop-up Blocker Settings Click Close to return to the Privacy screen. Click Apply to save this setting. JavaScripts If pages of the web configurator do not display properly in Internet Explorer, check that JavaScripts are allowed. NBG4115 User’s Guide...
Page 229 Figure 128 Internet Options: Security Click the Custom Level... button. Scroll down to Scripting. Under Active scripting make sure that Enable is selected (the default). Under Scripting of Java applets make sure that Enable is selected (the default). NBG4115 User’s Guide...
Page 230: Java Permissions
Figure 129 Security Settings - Java Scripting Java Permissions From Internet Explorer, click Tools, Internet Options and then the Security tab. Click the Custom Level... button. Scroll down to Microsoft VM. Under Java permissions make sure that a safety level is selected. NBG4115 User’s Guide...
Page 231 Click OK to close the window. Figure 130 Security Settings - Java JAVA (Sun) From Internet Explorer, click Tools, Internet Options and then the Advanced tab. Make sure that Use Java 2 for <applet> under Java (Sun) is selected. NBG4115 User’s Guide...
Page 232 The steps below apply to Mozilla Firefox 3.0 as well. You can enable Java, Javascripts and pop-ups in one screen. Click Tools, then click Options in the screen that appears. Figure 132 Mozilla Firefox: TOOLS > Options NBG4115 User’s Guide...
Page 233 Click Content to show the screen below. Select the check boxes as shown in the following screen. Figure 133 Mozilla Firefox Content Security Opera Opera 10 screens are used here. Screens for other versions may vary slightly. NBG4115 User’s Guide...
Page 234 Appendix B Pop-up Windows, JavaScripts and Java Permissions Allowing Pop-Ups From Opera, click Tools, then Preferences. In the General tab, go to Choose how you prefer to handle pop-ups and select Open all pop-ups. Figure 134 Opera: Allowing Pop-Ups NBG4115 User’s Guide...
Page 235 Content from the left-side menu. Select the check boxes as shown in the following screen. Figure 135 Opera: Enabling Java To customize JavaScript behavior in the Opera browser, click JavaScript Options. Figure 136 Opera: JavaScript Options Select the items you want Opera’s JavaScript to apply. NBG4115 User’s Guide...
Page 236 Appendix B Pop-up Windows, JavaScripts and Java Permissions NBG4115 User’s Guide...
Page 237: Appendix C Ip Addresses And Subnetting
192.168.1.1). Each of these four parts is known as an octet. An octet is an eight-digit binary number (for example 11000000, which is 192 in decimal notation). Therefore, each octet has a possible range of 00000000 to 11111111 in binary, or 0 to 255 in decimal. NBG4115 User’s Guide...
Page 238: Subnet Masks
Table 77 IP Address Network Number and Host ID Example OCTET: OCTET: OCTET: OCTET (192) (168) IP Address (Binary) 11000000 10101000 00000001 00000010 Subnet Mask (Binary) 11111111 11111111 11111111 00000000 Network Number 11000000 10101000 00000001 Host ID 00000010 NBG4115 User’s Guide...
Page 239 MAXIMUM NUMBER OF SUBNET MASK HOST ID SIZE HOSTS 8 bits 255.0.0.0 24 bits – 2 16777214 16 bits 255.255.0.0 16 bits – 2 65534 24 bits 255.255.255.0 8 bits – 2 29 bits 255.255.255.248 3 bits – 2 NBG4115 User’s Guide...
Page 240 In this example, the company network address is 192.168.1.0. The first three octets of the address (192.168.1) are the network number, and the remaining octet is the host ID, allowing a maximum of 2 – 2 or 254 possible hosts. NBG4115 User’s Guide...
Page 241 The “borrowed” host ID bit can have a value of either 0 or 1, allowing two subnets; 192.168.1.0 /25 and 192.168.1.128 /25. The following figure shows the company network after subnetting. There are now two sub-networks, A and B. Figure 139 Subnetting Example: After Subnetting NBG4115 User’s Guide...
Page 242 Table 82 Subnet 2 LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE IP Address 192.168.1. IP Address (Binary) 11000000.10101000.00000001. 01000000 Subnet Mask (Binary) 11111111.11111111.11111111. 11000000 Subnet Address: Lowest Host ID: 192.168.1.65 192.168.1.64 Broadcast Address: Highest Host ID: 192.168.1.126 192.168.1.127 NBG4115 User’s Guide...
Page 243 Similarly, use a 27-bit mask to create eight subnets (000, 001, 010, 011, 100, 101, 110 and 111). The following table shows IP address last octet values for each subnet. Table 85 Eight Subnets SUBNET LAST BROADCAST SUBNET FIRST ADDRESS ADDRESS ADDRESS ADDRESS NBG4115 User’s Guide...
Page 244: Configuring Ip Addresses
255.255.255.248 (/29) 8192 255.255.255.252 (/30) 16384 255.255.255.254 (/31) 32768 Configuring IP Addresses Where you obtain your network number depends on your particular situation. If the ISP or your network administrator assigns you a block of registered IP NBG4115 User’s Guide...
Page 245 Network Address Translation (NAT) on the NBG4115. Once you have decided on the network number, pick an IP address for your NBG4115 that is easy to remember (for instance, 192.168.1.1) but make sure that no other device on your network is using that IP address.
Page 246 Since a router connects different networks, it must have interfaces using different network numbers. For example, if a router is set between a LAN and the Internet (WAN), the router’s LAN and WAN addresses must be on different subnets. In the NBG4115 User’s Guide...
Page 247 LAN port both use 192.168.1.1 as the IP address. The computer cannot access the Internet. This problem can be solved by assigning a different IP address to the computer or the router’s LAN port. Figure 142 Conflicting Computer and Router IP Addresses Example NBG4115 User’s Guide...
Page 248 Appendix C IP Addresses and Subnetting NBG4115 User’s Guide...
Page 249: Appendix D Setting Up Your Computer's Ip Address
P P E N D I X Setting Up Your Computer’s IP Address Note: Your specific NBG4115 may not support all of the operating systems described in this appendix. See the product specifications for more information about which operating systems are supported.
Page 250 Appendix D Setting Up Your Computer’s IP Address Windows XP/NT/2000 The following example uses the default Windows XP display theme but can also apply to Windows 2000 and Windows NT. Click Start > Control Panel. In the Control Panel, click the Network Connections icon. NBG4115 User’s Guide...
Page 251 Appendix D Setting Up Your Computer’s IP Address Right-click Local Area Connection and then select Properties. On the General tab, select Internet Protocol (TCP/IP) and then click Properties. NBG4115 User’s Guide...
Page 252 In the Command Prompt window, type "ipconfig" and then press [ENTER]. You can also go to Start > Control Panel > Network Connections, right-click a network connection, click Status and then click the Support tab to view your IP address and connection information. NBG4115 User’s Guide...
Page 253: Windows Vista
Appendix D Setting Up Your Computer’s IP Address Windows Vista This section shows screens from Windows Vista Professional. Click Start > Control Panel. In the Control Panel, click the Network and Internet icon. Click the Network and Sharing Center icon. NBG4115 User’s Guide...
Page 254 Appendix D Setting Up Your Computer’s IP Address Click Manage network connections. Right-click Local Area Connection and then select Properties. Note: During this procedure, click Continue whenever Windows displays a screen saying that it needs your permission to continue. NBG4115 User’s Guide...
Page 255 Appendix D Setting Up Your Computer’s IP Address Select Internet Protocol Version 4 (TCP/IPv4) and then select Properties. NBG4115 User’s Guide...
Page 256 ISP. You may also have to enter a Preferred DNS server and an Alternate DNS server, if that information was provided.Click Advanced. Click OK to close the Internet Protocol (TCP/IP) Properties window. 10 Click OK to close the Local Area Connection Properties window. NBG4115 User’s Guide...
Page 257 Status and then click the Support tab to view your IP address and connection information. Windows 7 This section shows screens from Windows 7 Enterprise. Click Start > Control Panel. In the Control Panel, click View network status and tasks under the Network and Internet category. NBG4115 User’s Guide...
Page 258 Appendix D Setting Up Your Computer’s IP Address Click Change adapter settings. Double click Local Area Connection and then select Properties. Note: During this procedure, click Continue whenever Windows displays a screen saying that it needs your permission to continue. NBG4115 User’s Guide...
Page 259 Appendix D Setting Up Your Computer’s IP Address Select Internet Protocol Version 4 (TCP/IPv4) and then select Properties. NBG4115 User’s Guide...
Page 260 DNS server and an Alternate DNS server, if that information was provided. Click Advanced if you want to configure advanced settings for IP, DNS and WINS. Click OK to close the Internet Protocol (TCP/IP) Properties window. Click OK to close the Local Area Connection Properties window. NBG4115 User’s Guide...
Page 261 In the Command Prompt window, type "ipconfig" and then press [ENTER]. The IP settings are displayed as follows. Mac OS X: 10.3 and 10.4 The screens in this section are from Mac OS X 10.4 but can also apply to 10.3. Click Apple > System Preferences. NBG4115 User’s Guide...
Page 262 Appendix D Setting Up Your Computer’s IP Address In the System Preferences window, click the Network icon. When the Network preferences pane opens, select Built-in Ethernet from the network connection type list, and then click Configure. NBG4115 User’s Guide...
Page 263 • In the IP Address field, type your IP address. • In the Subnet Mask field, type your subnet mask. • In the Router field, type the IP address of your device. Click Apply Now and close the window. NBG4115 User’s Guide...
Page 264 Figure 143 Mac OS X 10.4: Network Utility Mac OS X: 10.5 and 10.6 The screens in this section are from Mac OS X 10.5 but can also apply to 10.6. Click Apple > System Preferences. NBG4115 User’s Guide...
Page 265 Appendix D Setting Up Your Computer’s IP Address In System Preferences, click the Network icon. When the Network preferences pane opens, select Ethernet from the list of available connection types. From the Configure list, select Using DHCP for dynamically assigned settings. NBG4115 User’s Guide...
Page 266 • In the IP Address field, enter your IP address. • In the Subnet Mask field, enter your subnet mask. • In the Router field, enter the IP address of your NBG4115. Click Apply and close the window. NBG4115 User’s Guide...
Page 267 The procedure, screens and file locations may vary depending on your specific distribution, release version, and individual configuration. The following screens use the default Ubuntu 8 installation. Note: Make sure you are logged in as the root administrator. NBG4115 User’s Guide...
Page 268 When the Network Settings window opens, click Unlock to open the Authenticate window. (By default, the Unlock button is greyed out until clicked.) You cannot make changes to your configuration unless you first enter your admin password. NBG4115 User’s Guide...
Page 269 Appendix D Setting Up Your Computer’s IP Address In the Authenticate window, enter your admin account name and password then click the Authenticate button. In the Network Settings window, select the connection that you want to configure, then click Properties. NBG4115 User’s Guide...
Page 270 Network Settings screen. If you know your DNS server IP address(es), click the DNS tab in the Network Settings window and then enter the DNS server information in the fields provided. Click the Close button to apply the changes. NBG4115 User’s Guide...
Page 271 Check your TCP/IP properties by clicking System > Administration > Network Tools, and then selecting the appropriate Network device from the Devices tab. The Interface Statistics column shows data if your connection is working properly. Figure 145 Ubuntu 8: Network Tools NBG4115 User’s Guide...
Page 272 Follow the steps below to configure your computer IP address in the KDE: Click K Menu > Computer > Administrator Settings (YaST). When the Run as Root - KDE su dialog opens, enter the admin password and click OK. NBG4115 User’s Guide...
Page 273 When the YaST Control Center window opens, select Network Devices and then click the Network Card icon. When the Network Settings window opens, click the Overview tab, select the appropriate connection Name from the list, and then click the Configure button. NBG4115 User’s Guide...
Page 274 Select Dynamic Address (DHCP) if you have a dynamic IP address. Select Statically assigned IP Address if you have a static IP address. Fill in the IP address, Subnet mask, and Hostname fields. Click Next to save the changes and close the Network Card Setup window. NBG4115 User’s Guide...
Page 275 Click Finish to save your settings and close the window. Verifying Settings Click the KNetwork Manager icon on the Task bar to check your TCP/IP properties. From the Options sub-menu, select Show Connection Information. Figure 147 openSUSE 10.3: KNetwork Manager NBG4115 User’s Guide...
Page 276 Appendix D Setting Up Your Computer’s IP Address When the Connection Status - KNetwork Manager window opens, click the Statistics tab to see if your connection is working properly. Figure 148 openSUSE: Connection Status - KNetwork Manager NBG4115 User’s Guide...
Page 277: Appendix E Wireless Lans
(AP). Intra-BSS traffic is traffic between wireless clients in the BSS. When Intra-BSS is enabled, wireless client A and B can access the wired network and communicate NBG4115 User’s Guide...
Page 278 This wired connection between APs is called a Distribution System (DS). This type of wireless LAN topology is called an Infrastructure WLAN. The Access Points not only provide communication with the wired network but also mediate wireless network traffic in the immediate neighborhood. NBG4115 User’s Guide...
Page 279 A hidden node occurs when two stations are within range of the same access point, but are not within range of each other. The following figure illustrates a hidden node. Both stations (STA) are within range of the access point (AP) or NBG4115 User’s Guide...
Page 280 RTS (Request To Send)/CTS (Clear to Send) handshake will never occur as data frames will be fragmented before they reach RTS/CTS size. Note: Enabling the RTS Threshold causes redundant network overhead that could negatively affect the throughput performance instead of providing a remedy. NBG4115 User’s Guide...
Page 281: Fragmentation Threshold
Use the dynamic setting to automatically use short preamble when all wireless devices on the network support it, otherwise the NBG4115 uses long preamble. Note: The wireless devices MUST use the same preamble mode in order to communicate.
Page 282: Wireless Security Overview
IEEE802.1x EAP with RADIUS Server Authentication Wi-Fi Protected Access (WPA) WPA2 Most Secure Note: You must enable the same wireless security settings on the NBG4115 and on all wireless clients that you want to associate with it. NBG4115 User’s Guide...
Page 283 The following types of RADIUS messages are exchanged between the access point and the RADIUS server for user authentication: • Access-Request Sent by an access point requesting authentication. • Access-Reject Sent by a RADIUS server rejecting access. • Access-Accept Sent by a RADIUS server allowing access. NBG4115 User’s Guide...
Page 284: Types Of Eap Authentication
The wireless client ‘proves’ that it knows the password by encrypting the password with the challenge and sends back the information. Password is not sent in plain text. NBG4115 User’s Guide...
Page 285 However, PEAP only supports EAP methods, such as EAP-MD5, EAP-MSCHAPv2 and EAP-GTC (EAP-Generic Token Card), for client authentication. EAP-GTC is implemented only by Cisco. LEAP LEAP (Lightweight Extensible Authentication Protocol) is a Cisco implementation of IEEE 802.1x. NBG4115 User’s Guide...
Page 286: Dynamic Wep Key Exchange
RADIUS server, you should use WPA2-PSK (WPA2-Pre-Shared Key) that only requires a single (identical) password entered into each access point, wireless gateway and wireless client. As long as the passwords match, a wireless client will be granted access to a WLAN. NBG4115 User’s Guide...
Page 287 The common-password approach makes WPA(2)-PSK susceptible to brute-force password-guessing attacks but it’s still an improvement over WEP as it employs a consistent, single, alphanumeric password to derive a PMK which is used to generate unique temporal encryption NBG4115 User’s Guide...
Page 288 The RADIUS server then checks the user's identification against its database and grants or denies network access accordingly. A 256-bit Pairwise Master Key (PMK) is derived from the authentication process by the RADIUS server and the client. NBG4115 User’s Guide...
Page 289 The AP checks each wireless client's password and allows it to join the network only if the password matches. The AP and wireless clients generate a common PMK (Pairwise Master Key). The key itself is not sent over the network, but is derived from the PSK and the SSID. NBG4115 User’s Guide...
Page 290: Security Parameters Summary
Enable without Dynamic WEP Open Enable with Dynamic WEP Key Enable without Dynamic WEP Disable Shared Enable with Dynamic WEP Key Enable without Dynamic WEP Disable TKIP/AES Enable WPA-PSK TKIP/AES Disable WPA2 TKIP/AES Enable WPA2-PSK TKIP/AES Disable NBG4115 User’s Guide...
Page 291: Antenna Characteristics
Types of Antennas for WLAN There are two types of antennas used for wireless LAN applications. NBG4115 User’s Guide...
Page 292: Positioning Antennas
For omni-directional antennas mounted on a wall or ceiling, point the antenna down. For a single AP application, place omni-directional antennas as close to the center of the coverage area as possible. For directional antennas, point the antenna in the direction of the desired coverage area. NBG4115 User’s Guide...
Page 293: Appendix F Common Services
Border Gateway Protocol. BOOTP_CLIENT DHCP Client. BOOTP_SERVER DHCP Server. CU-SEEME 7648 A popular videoconferencing solution from White Pines Software. 24032 TCP/UDP Domain Name Server, a service that matches web names (for example www.zyxel.com) to IP numbers. NBG4115 User’s Guide...
Page 294 ICMP echo requests to test whether or not a remote host is reachable. POP3 Post Office Protocol version 3 lets a client computer get e-mail from a POP3 server through a temporary connection (TCP/IP or other). NBG4115 User’s Guide...
Page 295 Access Controller Access Control System). TELNET Telnet is the login and terminal emulation protocol common on the Internet and in UNIX environments. It operates over TCP/IP networks. Its primary function is to allow users to log into remote host systems. NBG4115 User’s Guide...
Page 296 Table 92 Commonly Used Services (continued) NAME PROTOCOL PORT(S) DESCRIPTION TFTP Trivial File Transfer Protocol is an Internet file transfer protocol similar to FTP, but uses the UDP (User Datagram Protocol) rather than TCP (Transmission Control Protocol). VDOLIVE 7000 Another videoconferencing solution. NBG4115 User’s Guide...
Page 297: Appendix G Legal Information
This publication is subject to change without notice. Trademarks NetUSB is a trademark of ZyXEL Communications, Inc. Other trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective owners.
Page 298 This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: this device may not cause interference and this device must accept any interference, including interference that may cause undesired operation of the device NBG4115 User’s Guide...
Page 299 03-909 de l’ARCEP, la puissance d’émission ne devra pas dépasser 10 mW (10 dB) dans le cadre d’une installation WiFi en extérieur pour les fréquences comprises entre 2454 MHz et 2483,5 MHz. This Class B digital apparatus complies with Canadian ICES-003. NBG4115 User’s Guide...
Page 300: Zyxel Limited Warranty
Registration Register your product online to receive e-mail notices of firmware upgrades and information at www.zyxel.com for global products, or at www.us.zyxel.com for North American products. NBG4115 User’s Guide...
Page 301 Appendix G Legal Information End-User License Agreement WARNING: ZyXEL Communications Corp. IS WILLING TO LICENSE THE ENCLOSED SOFTWARE TO YOU ONLY UPON THE CONDITION THAT YOU ACCEPT ALL OF THE TERMS CONTAINED IN THIS LICENSE AGREEMENT. PLEASE READ THE TERMS CAREFULLY BEFORE COMPLETING THE INSTALLATION PROCESS AS INSTALLING THE SOFTWARE WILL INDICATE YOUR ASSENT TO THEM.
Page 302 MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. ZyXEL DOES NOT WARRANT THAT THE FUNCTIONS CONTAINED IN THE SOFTWARE WILL MEET ANY REQUIREMENTS OR NEEDS YOU MAY HAVE, OR THAT THE SOFTWARE WILL OPERATE ERROR FREE, OR IN AN UNINTERUPTED FASHION, OR THAT ANY NBG4115 User’s Guide...
Page 303 Audit Rights ZyXEL SHALL HAVE THE RIGHT, AT ITS OWN EXPENSE, UPON REASONABLE PRIOR NOTICE, TO PERIODICALLY INSPECT AND AUDIT YOUR RECORDS TO ENSURE YOUR COMPLIANCE WITH THE TERMS AND CONDITIONS OF THIS LICENSE AGREEMENT. 10 Termination NBG4115 User’s Guide...
Page 304 Note: Some components of this product incorporate source code covered under the Apache License, GPL License, LGPL License, Sun License, and Castor License. To obtain the source code covered under those Licenses, please check ftp://opensource.zyxel.com to get it. NBG4115 User’s Guide...
Page 305: Index
46, 136 DHCP client information BitTorrent DHCP status Bridge/Repeater Dimensions disclaimer 60, 135 DNS server see also Domain name system DNS Server DNS server Certificate Authority Domain name See CA. vs host name. see also system name certifications NBG4115 User’s Guide...
Page 306 Internet Group Multicast Protocol Stateful inspection ZyXEL device firewall IP Address 131, 142, 143 firewall IP address stateful inspection dynamic Firmware upload IP Pool file extension using HTTP firmware version 41, 67 fragmentation threshold FTP. see also File Transfer Program NBG4115 User’s Guide...
Page 307 IGMP Power Specification PPPoE 55, 119 benefits dial-up connection see also Point-to-Point Protocol over Ethernet 139, 142, 245 global PPTP 56, 121 how it works see also Point-to-Point Tunneling Protocol inside preamble mode local product registration outside NBG4115 User’s Guide...
Page 308 Service and port numbers UPnP security issues Service Set URL Keyword Blocking Service Set IDentification user authentication Service Set IDentity. See SSID. local (user) database Session Initiated Protocol RADIUS server User Name SSID 41, 67, 92, 96 stateful inspection firewall NBG4115 User’s Guide...
Page 309 Wireless association list wireless channel 106, 173 wireless client WPA supplicants wireless LAN wireless LAN scheduling Wireless LAN wizard Wireless network Xbox Live basic guidelines channel encryption example MAC address filter overview security SSID Wireless security overview NBG4115 User’s Guide...
Page 310 Index NBG4115 User’s Guide...

ZyXEL Communications NBG4115 User Manual

About this User's Guide

Document Conventions

Safety Warnings

Contents Overview

Table of Contents

User's Guide

PART I User's Guide

Chapter 1 Introduction

Chapter 2 The WPS Button

Chapter 3 Zyxel Netusb Share Center Utility

Chapter 4

The Web Configurator

Chapter 5 Connection Wizard

Chapter 6 AP Mode

Chapter 7 Tutorials

Technical Reference

Part II: Technical Reference

Chapter 8 Wireless LAN

Chapter 9 WAN

Chapter 10 LAN

Chapter 11 DHCP Server

Chapter 12 NAT

Chapter 13 DDNS

Chapter 14 Firewall

Chapter 15 Content Filtering

Chapter 16 Static Route

Chapter 17 Bandwidth Management

Chapter 18 Remote Management

Chapter 19 Upnp

Chapter 20 Wol

Chapter 21 Netusb

Chapter 22 System

Chapter 23 Logs

Chapter 24 Tools

Chapter 25 Sys OP Mode

Chapter 26 Language

Chapter 27 Troubleshooting

Appendix A Product Specifications

Appendix B Pop-Up Windows, Javascripts and Java Permissions

Appendix C IP Addresses and Subnetting

Appendix D Setting up Your Computer's IP Address

Appendix E Wireless Lans

Appendix F Common Services

Appendix G Legal Information

Index

Quick Links

Troubleshooting

Related Manuals for ZyXEL Communications NBG4115

Summary of Contents for ZyXEL Communications NBG4115
