JBL HLS 810 Technical Manual

Technical Manual
HLS 810
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance
• Max Amp Power
• Frequency Response
• Sensitivity
• Crossover Frequency

SYSTEM COMPONENTS:

• Cabinet
• Grille
• Low Frequency Transducer* 8" Polypropylene,
DC Resistance
• High Frequency Transducer* 10mm Polycarbonate Dome
PACKAGING
Upper Foam
332675-001
Lower Foam
332676-001
Outer Carton
332677-001
JBL Consumer Products, Inc. 250 Crossways Park Dr., Woodbury, New York 11797
8 ohms
150 watts
50Hz - 20kHz (+3dB)
89 dB (1 watt @ 1 meter)
2600 Hz
HLS 810 (Not For Sale)
332674-001
Shielded (332651-001)
4.4 ohms ±10%
(TW010B17/101829B)
Owner's Manual
332661-001
Survey Card
331384-001
OWNER'S
MANUAL
Warranty Card
331994-001
SYSTEM COMPONENTS: (cont.)
DC Resistance
• Crossover Network
AURAL SWEEP TEST SPECIFICATIONS:
• System Aural Sweep Test
• L.F. Aural Sweep Test
• H.F. Aural Sweep Test
PHYSICAL SPECIFICATIONS
• Enclosure dimensions:
• Weight
WARRANTY:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

High Frequency*
TW010B17/101829B
YEL
Low Frequency*
332651-001
– +
GRN/BLK
HLS 810 SCHEMATIC
L1
1.50 mH
+IN
INPUT
L2
0.33 mH
–IN
C3
2.7 mfd 50V
5.5 ohms ±10%
332678-001
6.0V Input 50 Hz to 20 kHz
6.0V Input 40 Hz to 3 kHz
2.83V Input 2 kHz to 20 kHz
19 7/16 x 9 3/4 x 9 3/4"
(H x W x D) 494 x 248 x 248mm
43lbs. (19.5kg). Sold in Pairs.
Network
332678-001
YEL/BLK
GRN
18" GREEN
C1
33 mfd 50V
C2
30 mfd 50V
18" GREEN/BLK
15" YELLOW
L3
0.33 mH
15" YELLOW/BLK
+
.250
L.F.
.205
+
.187
H.F.
.110
3-99
