Page 1: Air Conditioner
OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : FLOOR STANDING http://www.lghvac.com www.lg.com P/NO : MFL42619116... -
Page 2: Table Of Contents
Air Conditioner Ownerʼs Manual TABLE OF CONTENTS FOR YOUR RECORDS Write the model and serial numbers here: Safety Precautions....3 Model # Serial # Prior to Operation ....8 You can find them on a label on the side of each unit. Dealer's Name Date Purchased Introduction ......8... -
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. - Page 4 Safety Precautions Do not modify or extend the Do not install, remove, or re- Be cautious when unpacking power cable. install the unit by yourself and installing the product. (customer). • There is risk of fire or electric • There is risk of fire, electric •...
- Page 5 Safety Precautions Do not allow water to run Do not store or use flammable Do not use the product in a into electric parts. gas or combustibles near the tightly closed space for a product. long time. • It may cause There is risk of fire, •...
- Page 6 Safety Precautions When the product is not be used for a long Take care to ensure that nobody could step time, disconnect the power supply plug or on or fall onto the outdoor unit. turn off the breaker. • There is risk of product damage or failure, or •...
- Page 7 Safety Precautions Do not block the inlet or Use a soft cloth to clean. Do Do not touch the metal parts of outlet of air flow. not use harsh detergents, the product when removing the solvents, etc. air filter. They are very sharp! •...
-
Page 8: Prior To Operation
Prior to Operation Prior to Operation Preparing for Operation 1. Contact an installation specialist for installation. 2. Plug in the power plug properly. 3. Use a dedicated circuit. 4. Do not use an extension cord. 5. Do not start/stop operation by plugging/unplugging the power cord. 6. -
Page 9: Operating Instructions
Operating Instructions Operating Instructions Features and Specifications 1. Design for cooling 6. 3 cooling speeds 2. Super energy efficiency 7. Removable air filter 3. Micom control 8. Anti-Bacteria filter 4. Whisper quiet operation 9. 3 minutes delay circuit 5. Wireless remote control Air Outlet Vent Air Outlet Vent Remote Signal... - Page 10 Operating Instructions Indoor Unit Controls and Indicators 1. START/STOP BUTTON 6. COOLING OPERATION LAMP Operation starts when this button is pressed and stops when the button is pressed again. 7. SOFT DRY OPERATION LAMP 2. OPERATION MODE SELECTION 8. OUTDOOR UNIT OPERATION LAMP BUTTON Used to select the operation Mode.
-
Page 11: Operation Mode
Operating Instructions Features of the Remote Control- Door Closed INDOOR FAN OPERATION BUTTON Used to circulate the room air without cooling or heating (turns indoor fan on/off). JET COOL Button Speed cooling operates super high fan speed. OPERATION MODE SELECTION Button Used to select the operation mode. -
Page 12: Remote Control Preparation
Operating Instructions Remote Control Preparation 1. How to mount onto a wall Use the screws to secure the holder to the wall or attach the holder side of indoor unit. To insert the remote control to the holder. Insert Pull How to insert batteries 1. -
Page 13: Owner's Instruction
Owner's Instruction Owner's Instruction Cooling Mode - Standard Operation Press the ON/OFF button. The unit will respond with beep sound. Press MODE button to select Cooling Mode. To raise the temperature Set the desired temperature by pressing TEMP button. Press ROOM TEMPERATURE CHECKING button to check the room temperature. -
Page 14: Auto Changeover Mode
Owner's Instruction Auto Changeover Mode This Function is only for Multi-V SYNC H/P model. Press the ON/OFF button. The unit will respond with beep sound. Press MODE button to select Auto Changeover Mode. Set the desired room temperature. h Setting Temp. Range in Auto Changeover Mode : 18~30°C (64~86°F) To raise the temperature To lower the temperature... -
Page 15: Dehumidification Mode
Owner's Instruction Dehumidification Mode Press the ON/OFF button. The unit will respond with beep sound. Press MODE button to select Dehumidification Mode. Set the fan speed. You can select the fan speed in four steps - low, medium, high, or chaos. Each time the button is pressed, the fan speed mode is shifted. -
Page 16: Heating Mode
Owner's Instruction Heating Mode This Function is only for H/P model. Press the ON/OFF button. The unit will respond with beep sound. Press MODE button to select Heating Mode. Set the desired temperature by pressing TEMP button. Press ROOM TEMPERATURE CHECKING button to check the room temperature. -
Page 17: Fan Mode
Owner's Instruction Fan Mode Press the ON/OFF button. The unit will respond with beep sound. Press FAN button to select Fan Mode. Set the fan speed again. You can select the fan speed in four steps–low, medium, high, or chaos. Each time the button is pressed, the fan speed mode is shifted. -
Page 18: Temperature Setting/Room Temperature Checking
Temperature Setting/Room Temperature checking Temperature Setting/Room Temperature checking We can simply adjust the desired temperature • Press the buttons to adjust the desired temperature : Increase 1˚C or 2˚F per one time pressing : Decrease 1˚C or 2˚F per one time pressing Set temp: Indicate the temperature that user want to set <Cooling Mode>... -
Page 19: Airflow Setting
Airflow Setting Airflow Setting Up/Down Airflow Direction Control (Optional) The up/down airflow (Vertical Airflow) can be adjusted by using the remote controller. 1. Press the ON/OFF button to start the unit. 2. Press UP/DOWN AIRFLOW button and the louvers will swing up and down. Press the UP/DOWN AIRFLOW button again to set the vertical louver at the desired airflow direction. -
Page 20: Sub Function
Sub function Sub function Celsius/Fahrenheit Switching Press the °C/°F SWITCH button to change from Celsius to Fahrenheit or from Fahrenheit to Celsius. Whenever press TEMPERATURE SETTING button in Fahrenheit mode, the temperature will increase/drop 2°F. Child Lock Operation Procedure Press the fan speed button and High temperature setting buttons simultaneously for 3 seconds. The unit will respond with beep. -
Page 21: Timer
Timer Timer Setting the Current Time 1. Press the TIMER button for 3 seconds. 3. Press the SET / CLEAR button. 2. Press TIME SETTING buttons until the desired time is set. Check the indicator for A.M. and P.M. NOTICE Timer Setting 1. -
Page 22: Care And Maintenance
Care and Maintenance Care and Maintenance CAUTION: Before performing any maintenance, turn off the main power to the system. During the season Cleaning of the air filters. Recommended about once every two weeks Remove the Air Filter. Clean. Take hold of the tab and pull slightly •... -
Page 23: Operation Tips
Care and Maintenance When the air conditioner is not going to be used for a long time. At the end of the season At the start of the season Operate the air conditioner at the Clean the air filters, re-insert, then following settings for 2 to 3 hours. -
Page 24: Before You Call For Service
Before you call for service... Before you call for service... Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service..If the fault persists, please contact your dealer or service center. Case Explanation Does not operate. •... - Page 25 1. Please call the installing contractor of your product, as warranty service will be provided by them. 2. If you have service issues that have not been addressed by the contractor, please call 1-888-865- 3026. CANADA Service call Number # : (888) LG Canada, (888) 542-2623...
