- Page 1 Operator ′ s manual 326Lx Please read the operator’s manual carefully and make sure you E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
-
Page 2: Key To Symbols
KEY TO SYMBOLS Symbols Only intended for trimmer heads. WARNING! Clearing saws, brushcutters and trimmers can be dangerous! Careless or incorrect use can result in serious or fatal injury to the operator or others. Please read the operator’s manual carefully Noise emission to the environment and make sure you understand the according to the European Community’s... -
Page 3: Table Of Contents
CONTENTS Contents Note the following before starting: KEY TO SYMBOLS Husqvarna AB has a policy of continuous product development and therefore reserves the right to modify the Symbols ............... design and appearance of products without prior notice. CONTENTS Contents .............. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Personal protective equipment Machine ′ ′ ′ ′ s safety equipment This section describes the machine ′ s safety equipment, its IMPORTANT! You must use approved personal protective purpose, and how checks and maintenance should be carried equipment whenever you use the machine. Personal out to ensure that it operates correctly. -
Page 5: Cutting Equipment
SAFETY INSTRUCTIONS Vibration damping system For mufflers it is very important that you follow the instructions on checking, maintaining and servicing your machine. See Your machine is equipped with a vibration damping system instructions under the heading Checking, maintaining and that is designed to minimize vibration and make operation servicing the machine’s safety equipment. -
Page 6: Checking, Maintaining And Servicing The Machine ' S Safety Equipment
SAFETY INSTRUCTIONS Checking, maintaining and servicing Stop switch the machine ′ ′ ′ ′ s safety equipment • Start the engine and make sure the engine stops when you move the stop switch to the stop setting. IMPORTANT! All servicing and repair work on the machine requires special training. -
Page 7: Cutting Equipment
SAFETY INSTRUCTIONS • Regularly check that the muffler is securely attached to • Tighten the nut using the socket spanner. 35-50 Nm (3.5- the machine. 5 kpm). CAUTION! The nylon lining inside the locking nut must not be so worn that you can turn it by hand. The lining should offer a resistance of at least 1.5 Nm. -
Page 8: General Safety Precautions
SAFETY INSTRUCTIONS General safety precautions • To increase the life of the cord it can be soaked in water for a couple of days. This will make the line tougher so that it lasts longer. IMPORTANT! IMPORTANT! Always ensure the trimmer cord is wound The machine is only designed for trimming grass. -
Page 9: Fuel Safety
SAFETY INSTRUCTIONS (CAUTION! Not with your foot). Then grip the starter • Ensure the machine is cleaned and that a complete handle with your right hand and pull the starter cord. service is carried out before long-term storage. Never twist the starter cord around your hand. WARNING! Take care when handling fuel. -
Page 10: Basic Working Techniques
SAFETY INSTRUCTIONS Basic working techniques Cutting • Always slow the engine to idle speed after each working operation. Long periods at full throttle without any load on the engine can lead to serious engine damage. • The trimmer is ideal for cutting grass that is difficult to reach using a normal lawn mower. -
Page 11: What Is What
WHAT IS WHAT? What is what? 1 Trimmer head 13 Choke control 2 Grease filler cap, bevel gear 14 Air purge 3 Bevel gear 15 Air filter cover 4 Cutting attachment guard 16 Handle adjustment 5 Shaft 17 Locking nut 6 Loop handle 18 Support flange 7 Throttle control... -
Page 12: Assembly
ASSEMBLY Fitting the loop handle Fitting a trimmer guard and Superauto II 1” trimmer head • Clip the loop handle onto the shaft. Note that the loop handle must be fitted between the arrows on the shaft. • Fit the correct trimmer guard (A) for use with the trimmer •... -
Page 13: Fitting Other Guards And Cutting Attachments
ASSEMBLY Fitting other guards and cutting attachments • Fit the correct trimmer guard (A) for use with the trimmer head. Hook the trimmer guard/combination guard onto the fitting on the shaft and secure with the bolt (L). • Fit the drive disc (B) on the output shaft. •... -
Page 14: Fuel Handling
Mixture 1:50 (2%). When refuelling, open the fuel cap slowly so • If HUSQVARNA two-stroke oil is not available, you may that any excess pressure is released gently. use another two-stroke oil of good quality that is intended Tighten the fuel cap carefully after refuelling. -
Page 15: Starting And Stopping
STARTING AND STOPPING Check before starting Starting and stopping • Check that the support flange is not cracked due to fatigue or due to being tightened too much. Discard the support WARNING! The complete clutch cover and flange if it is cracked. shaft must be fitted before the machine is started, otherwise the clutch can come loose and cause personal injury. - Page 16 STARTING AND STOPPING some resistance (the starter pawls grip), now quickly and powerfully pull the cord. Never twist the starter cord around your hand. Repeat pulling the cord until the engine starts. When the engine starts. return choke control to run position and apply full throttle;...
-
Page 17: Maintenance
MAINTENANCE Carburettor WARNING! If the idle speed cannot be adjusted so that the cutting attachment Your Husqvarna product has been designed and stops, contact your dealer/service manufactured to specifications that reduce harmful workshop. Do not use the machine until it emissions. -
Page 18: Muffler
MAINTENANCE High speed jet H Muffler The high speed jet H affects the engine power, speed, temperature and fuel consumption. If the high speed jet H is set too lean (screwed in too far) the engine speed will be too high and cause engine damage. -
Page 19: Cooling System
• A dirty air filter. Always use HUSQVARNA filter oil, art. no. 531 00 92-48. The These factors cause deposits on the spark plug electrodes, filter oil contains a solvent to make it spread evenly through which may result in operating problems and starting the filter. -
Page 20: Maintenance Schedule
However, before using the machine you should check 0,5 mm that the bevel gear is filled three-quarters full with grease. Use HUSQVARNA special grease. 1 Check the starter and starter cord. The grease in the bevel gear does not normally need to be 2 Check that the vibration damping elements are not changed except if repairs are carried out. -
Page 21: Technical Data Technical Data
TECHNICAL DATA Technical data Technical data 326Lx Engine Cylinder displacement, cm 24,5 Cylinder bore, mm 34,0 Stroke, mm Idle speed, rpm 2700 Recommended max. fast idle speed, rpm 11000-11700 Speed of output shaft, rpm 8014 Max. engine output, acc. to ISO 8893, kW/ rpm 0,9/8400 Catalytic converter muffler... -
Page 22: Ec-Declaration Of Conformity (Applies To Europe Only)
EC-declaration of conformity (Applies to Europe only) We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare that the clearing saws Husqvarna 326LX with serial numbers dating from 2002 onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVE:... - Page 23 Super Auto II Super Auto II 1 " 4,0 m 15 cm ~2,0 m 6 " 6,5 ' 15 cm 6 "...
- Page 25 8,5 m 10 cm 4" 4,2 m "Clic" 15 cm 6"...
- Page 26 4,25 m 4,25 m 15 cm 6" 15 cm 6" ´®z+H;6¶6k¨ ´®z+H;6¶6k¨...
- Page 27 8,5 m 10 cm 4" 4,3 m "Clic" 15 cm 6"...
- Page 28 1140272-26 ´®z+H;6¶6k¨ ´®z+H;6¶6k¨ 2004-03-22...
