Related Manuals for Seagate Cheetah ST3450856SS
Summary of Contents for Seagate Cheetah ST3450856SS
- Page 1 Product Manual Cheetah 15K.6 SAS ST3450856SS ST3450056SS (FDE) ST3300656SS ST3300056SS (FDE) ST3146356SS ST3146756SS (FDE) 100466193 Rev. C July 2011...
- Page 2 LLC in the United States and/or other countries. Cheetah 15K.6 and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
Seagate Technology support services ........ - Page 4 7.4.1 Temperature ........... . 33 7.4.2 Relative humidity .
-
Page 5: Seagate Technology Support Services
Authorized Service Centers For information regarding Warranty Support, visit http://www.seagate.com/www/en-us/support/warranty_&_returns_assistance For information regarding Data Recovery Services, visit http://www.i365.com For Seagate OEM & Distribution partner portal, visit https://direct.seagate.com/portal/system For Seagate reseller portal, visit http://spp.seagate.com Cheetah 15K.6 SAS Product Manual, Rev. C... -
Page 6: Scope
Scope ® ® This manual describes Seagate Technology LLC, Cheetah SAS (Serial Attached SCSI) disk drives. Cheetah 15K.6 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of Cheetah 15K.6 and other Seagate SAS drives. -
Page 7: Standards, Compliance And Reference Documents
Section 9.3. Standards The Cheetah 15K.6 SAS family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The Cheetah 15K.6 disk drive is a UL recognized component per UL1950, CSA certified to CAN/CSA C22.2 No. -
Page 8: Compliance
Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the rep- resentations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our... -
Page 9: Reference Documents
Seagate also has internal systems in place to ensure ongoing compliance with the RoHS Directive and all laws and regulations which restrict chemical content in electronic products. These systems include standard operat- ing procedures that ensure that restricted substances are not utilized in our manufacturing operations, labora- tory analytical validation testing, and an internal auditing process to ensure that all standard operating procedures are complied with. -
Page 10: General Description
General description Cheetah 15K.6 drives provide high performance, high capacity data storage for a variety of systems including engineering workstations, network servers, mainframes, and supercomputers. The Serial Attached SCSI inter- face is designed to meet next-generation computing demands for performance, scalability, flexibility and high- density storage requirements. -
Page 11: Standard Features
Standard features Cheetah 15K.6 drives have the following standard features: • 1.5 / 3 Gbit Serial Attached SCSI (SAS) interface • Integrated dual port SAS controller supporting the SCSI protocol • Support for SAS expanders and fanout adapters • Firmware downloadable using the SAS interface •... -
Page 12: Reliability
Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. We recommend customers use this capacity in their project planning, as it ensures a stable operating point with backward and forward compatibility from generation to generation. -
Page 13: Performance Characteristics
Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Cheetah 15K.6 drives. Internal drive characteristics ST3450856SS ST3300656SS ST3146356SS ST3450056SS ST3300056SS ST3146756SS Drive capacity Gbytes (formatted, rounded off value) Read/write data heads Tracks per inch 150,000 150,000... -
Page 14: Format Command Execution Time (Minutes)
5.2.2 Format command execution time (minutes) When changing sector sizes, the format times shown below may need to be increased by 30 minutes. ST3450856SS ST3300656SS ST3146356SS ST3450056SS ST3300056SS ST3146756SS Maximum (with verify) Maximum (without verify) Note. There is no significant difference in the format time between FDE and non-FDE models of the same capacity. -
Page 15: Prefetch/Multi-Segmented Cache Control
If the drive receives a START STOP UNIT command with the START bit equal to 0 before receiving a NOTIFY (ENABLE SPINUP) primitive, the drive waits for a START STOP UNIT command with the START bit equal to 1. After receiving a START STOP UNIT command with the START bit equal to 1, the drive waits for a NOTIFY (ENABLE SPINUP) primitive. -
Page 16: Caching Write Data
Note. The size of each segment is not reported by Mode Sense command page 08h, bytes 14 and 15. The value 0XFFFF is always reported regardless of the actual size of the segment. Sending a size specification using the Mode Select command (bytes 14 and 15) does not set up a new segment size. -
Page 17: Reliability Specifications
Reliability specifications The following reliability specifications assume correct host and drive operational interface, including all inter- face timings, power supply voltages, environmental requirements and drive mounting constraints. Seek error rate: Less than 10 errors in 10 seeks Read Error Rates Recovered Data Less than 10 errors in 10 bits transferred (OEM default settings) -
Page 18: Seek Errors
6.1.3 Seek errors A seek error is defined as a failure of the drive to position the heads to the addressed track. After detecting an initial seek error, the drive automatically performs an error recovery process. If the error recovery process fails, a seek positioning error (Error code = 15h or 02h) will be reported with a Hardware error (04h) in the Sense Key. -
Page 19: S.m.a.r.t
6.2.4 S.M.A.R.T. S.M.A.R.T. is an acronym for Self-Monitoring Analysis and Reporting Technology. This technology is intended to recognize conditions that indicate imminent drive failure and is designed to provide sufficient warning of a failure to allow you to back up the data before an actual failure occurs. Note. -
Page 20: Thermal Monitor
Reporting control Reporting is controlled by the MRIE bits in the Informational Exceptions Control mode page (1Ch). Subject to the reporting method, the firmware will issue to the host an 01-5Dxx sense code. The error code is preserved through bus resets and power cycles. Determining rate S.M.A.R.T. -
Page 21: Drive Self Test (Dst)
DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive. - Page 22 A Drive Not Ready condition is reported by the drive under the following conditions: • Motor will not spin • Motor will not lock to speed • Servo will not lock on track • Drive cannot read configuration tables from the disk In these conditions, the drive responds to a Test Unit Ready command with an 02/04/00 or 02/04/03 code.
-
Page 23: Product Warranty
Seagate’s option and at no charge to the customer, if returned by customer at customer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. -
Page 24: Physical/Electrical Specifications
AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown below. Values indicated apply at the drive connector. Table 12: DC power requirements ST3450856SS ST3450856SS ST3450856SS 1.5 Gbit mode 3 Gbit mode Notes (Amps) - Page 25 Table 13: DC power requirements ST3450056SS (FDE) ST3450056SS (FDE) ST3450056SS (FDE) 1.5 Gbit mode 3 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [1] [7] 0.45 0.77 0.48...
- Page 26 Table 15: (FDE) DC power requirements ST3300056SS ST3300056SS (FDE) ST3300056SS (FDE) 1.5 Gbit mode 3 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [1] [7] 0.48 0.66 0.50...
- Page 27 Table 17: (FDE) DC power requirements ST3146756SS ST3146756SS (FDE) ST3146756SS (FDE) 1.5 Gbit mode 3 Gbit mode Notes (Amps) (Amps) (Amps) (Amps) Voltage +12V [2] +12V [2] Regulation ±5% ±5% [2] ±5% ±5% [2] Avg idle current DCX [1] [7] 0.49 0.55 0.51...
-
Page 28: Conducted Noise Immunity
7.2.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a defined frequency range. Maximum allowed noise values given below are peak-to-peak measurements and apply at the drive power connector. 250 mV pp from 100 Hz to 20 MHz. +12V = 800 mV pp from 100 Hz to 8 KHz. - Page 29 Figure 1. Typical 450GB current profiles Figure 2. Typical 300GB current profiles Cheetah 15K.6 SAS Product Manual, Rev. C...
- Page 30 Figure 3. Typical 146GB current profiles Cheetah 15K.6 SAS Product Manual, Rev. C...
-
Page 31: Power Dissipation
+12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 4. ST3450856SS, 3 Gbit, DC current and power vs. input/output operations per second Cheetah 15K.6 SAS Product Manual, Rev. C... - Page 32 (FDE) model ST3450056SS Typical power dissipation under idle conditions in 3Gb operation is 11.64 watts (39.72 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
- Page 33 model ST3300656SS Typical power dissipation under idle conditions in 3Gb operation is 10.26 watts (35.01 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
- Page 34 (FDE) model ST3300056SS Typical power dissipation under idle conditions in 3Gb operation is 10.42 watts (35.56 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
- Page 35 ST3146356SS model Typical power dissipation under idle conditions in 3Gb operation is 9.06 watts (30.92 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis.
- Page 36 in 3 Gbit operation ST3146756SS (FDE) model Typical power dissipation under idle conditions in 3Gb operation is 9.15 watts (31.22 BTUs per hour). To obtain operating power for typical random read operations, refer to the following I/O rate curve (see Figure 4).
-
Page 37: Environmental Limits
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp. -
Page 38: Effective Altitude (Sea Level)
7.4.3 Effective altitude (sea level) a. Operating –1,000 to +10,000 feet (–305 to +3,048 meters) b. Non-operating –1,000 to +40,000 feet (–305 to +12,210 meters) 7.4.4 Shock and vibration Shock and vibration limits specified in this document are measured directly on the drive chassis. If the drive is installed in an enclosure to which the stated shock and/or vibration criteria is applied, resonances may occur internally to the enclosure resulting in drive movement in excess of the stated limits. - Page 39 36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.
-
Page 40: Acoustics
There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive. -
Page 41: Corrosive Environment
The sil- ver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 42: Mechanical Specifications
Refer to Figure 12 for detailed physical dimensions. See Section 9.3, “Drive mounting.” Height: 1.028 in 26.11 mm Width: 4.010 in 101.85 mm Depth: 5.787 in 146.99 mm Weight: ST3450856SS: 1.563 pounds 0.709 kilograms ST3450056SS ST3300656SS: 1.53 pounds 0.694 kilograms ST3300056SS ST3146356SS: 1.487 pounds 0.674 kilograms ST3146756SS 26.11 MAX 2X 20.14 (1.028 MAX) -
Page 43: Defect And Error Management
Defect and error management Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). - Page 44 The drive firmware error recovery algorithms consists of 13 levels for read recoveries and five levels for write. Each level may consist of multiple steps, where a step is defined as a recovery function involving a single re- read or re-write attempt. The maximum level used by the drive in LBA recovery is determined by the read and write retry counts.
-
Page 45: Sas System Errors
SAS system errors Information on the reporting of operational errors or faults across the interface is given in the SAS Interface Manual. The SSP Response returns information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations performed by the drive. Status returned by the drive to the initiator is described in the SAS Interface Manual. -
Page 46: Deferred Auto-Reallocation
DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is being attempted to a previously failing location. -
Page 47: Installation
Installation Cheetah 15K.6 disk drive installation is a plug-and-play process. There are no jumpers, switches, or termina- tors on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which you need to mount the drive. - Page 48 If forced air is determined to be necessary, possible air-flow patterns are shown in Figure 13. The air-flow pat- terns are created by one or more fans, either forcing or drawing air as shown in the illustrations. Conduction, convection, or other forced air-flow patterns are acceptable as long as the temperature measurement guide- lines of Section 7.4.1 are met.
-
Page 49: Drive Mounting
Drive mounting Mount the drive using the bottom or side mounting holes. If you mount the drive using the bottom holes, ensure that you do not physically distort the drive by attempting to mount it on a stiff, non-flat surface. The allowable mounting surface stiffness is 80 lb/in (14.0 N/mm). -
Page 50: Interface Requirements
10.0 Interface requirements This section partially describes the interface requirements as implemented on Cheetah 15K.6 drives. Addi- tional information is provided in the SAS Interface Manual (part number 100293071). 10.1 SAS features This section lists the SAS-specific features supported by Cheetah 15K.6 drives. 10.1.1 task management functions Table 19 lists the SAS task management functions supported. -
Page 51: Dual Port Support
10.2 Dual port support Cheetah 15K.6 SAS drives have two independent ports. These ports may be connected in the same or differ- ent SCSI domains. Each drive port has a unique SAS address. The two ports run at the same link rate. The first port to successfully complete speed negotiation sets the link rate support by both ports. -
Page 52: Scsi Commands Supported
10.3 SCSI commands supported Table 21 lists the SCSI commands supported by Cheetah 15K.6 drives. Table 21: Commands supported by Cheetah 15K.6 SAS family drives Command name Command code Supported Change Definition Compare Copy Copy and Verify Format Unit [1] DPRY bit supported DCRT bit supported STPF bit supported... - Page 53 Table 21: Commands supported by Cheetah 15K.6 SAS family drives (continued) Command name Command code Supported Non-medium Error page (06h) Pages Supported list (00h) Read Error Counter page (03h) Read Reverse Error Counter page (04h) Self-test Results page (10h) Background Medium Scan page (15h) Start-stop Cycle Counter page (0Eh) Temperature page (0Dh) Verify Error Counter page (05h)
- Page 54 Table 21: Commands supported by Cheetah 15K.6 SAS family drives (continued) Command name Command code Supported Reassign Blocks Receive Diagnostic Results Supported Diagnostics pages (00h) Translate page (40h) Release Release (10) Request Sense Actual Retry Count bytes Extended Sense Field Pointer bytes Reserve 3rd Party Reserve Extent Reservation...
- Page 55 Table 21: Commands supported by Cheetah 15K.6 SAS family drives (continued) Command name Command code Supported FUA bit Write Long Write Same PBdata LBdata XDRead XDWrite XPWrite Cheetah 15K.6 drives can format to 512, 520, 524, or 528 bytes per logical block. Warning.
-
Page 56: Inquiry Data
Eight ASCII digits representing the eight digits of the product serial number. Bytes 18 through 26 reflect model of drive. The table above shows the hex values for Model ST3450856SS. Refer to the values below for the values of bytes 18 through 27 of you particular model:... -
Page 57: Mode Sense Data
10.3.2 Mode Sense data The Mode Sense command provides a way for the drive to report its operating parameters to the initiator. The drive maintains four sets of mode parameters: 1. Default values Default values are hard-coded in the drive firmware stored in flash E-PROM (nonvolatile memory) on the drive’s PCB. - Page 58 10.3.2.1 ST3450856SS/ST3450056SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff...
- Page 59 10.3.2.2 ST3300656SS/ST3300056SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 83 16 bb d0 00 00 00 00 03 80 04 c4 02 00 00 01 01 09 00 5f 40 00 00 00...
- Page 60 10.3.2.3 ST3146356SS/ST3146756SS Mode Sense data MODE DATA HEADER: 01 2e 00 10 00 00 00 08 MODE PAGES: 81 0a c0 0b ff 00 00 00 05 00 ff ff 81 0a ff ff 00 00 00 00 ff 00 ff ff 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00 83 16 bb d0 00 00 00 00 03 80 04 c4 02 00 00 01 01 09 00 5f 40 00 00 00...
-
Page 61: Miscellaneous Operating Features And Conditions
10.4 Miscellaneous operating features and conditions Table 23 lists various features and conditions. A “Y” in the support column indicates the feature or condition is supported. An “N” in the support column indicates the feature or condition is not supported. Table 23: Miscellaneous features Supported... - Page 62 Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual.. SAS Interface connector Figure 14. Physical interface Cheetah 15K.6 SAS Product Manual, Rev. C...
- Page 63 0.80 (6X) 5.92 7.62 4.65 0.52 0.08 x 45 2.00 (3X) 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B 0.30 0.05 (2X) 1.10 4.00 0.08 C OF DATUM D 0.15 D R0.30 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43...
-
Page 64: Physical Characteristics
Detail A 6.10 0.30 0.05 x 45 (5X) 2.25 0.05 0.40 0.05 X 45 (3X) 4.85 0.05 0.10 B CORING ALLOWED IN THIS AREA. 4.40 0.15 R0.30 0.08 SEE Detail 2 1.95 0.08 0.35 0.05 SECTION C - C 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH... -
Page 65: Electrical Description
10.4.4 Electrical description SAS drives use the device connector for: • DC power • SAS interface • Activity LED This connector is designed to either plug directly into a backpanel or accept cables. 10.4.5 Pin descriptions This section provides a pin-out of the SAS device and a description of the functions provided by the pins. Table 25: SAS pin descriptions Signal name... -
Page 66: Sas Transmitters And Receivers
10.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 17. The receiver is AC cou- pling to eliminate ground shift noise. Differential Transmitter Receiver Transfer Medium Figure 17. SAS transmitters and receivers 10.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector. -
Page 67: Differential Signals
The Ready LED Out signal is designed to pull down the cathode of an LED. The anode is attached to the proper +3.3 volt supply through an appropriate current limiting resistor. The LED and the current limiting resis- tor are external to the drive. See Table 27 for the output characteristics of the LED drive signals. Table 27: LED drive signal State... - Page 68 10.5.2.1.2 Receive eye mask Figure 18 describes the receive eye mask. This eye mask applies to jitter after the application of a single pole high-pass frequency-weighting function that progressively attenuates jitter at 20 dB/decade below a frequency of ((bit rate) / 1.667). Absolute amplitude (in V)
- Page 69 The leading and trailing edge slopes of figure 18 shall be preserved. As a result the amplitude value of Z1 is less than that given in table 30 and Z1 and Z1 shall be defined from those slopes by the following equa- tion: )xadditional sinusoidal jitter –...
- Page 70 10.5.2.2 Transmitter signal characteristics Table 29 specifies the signal requirements at the transmitter end of a TxRx connection as measured into the zero-length test load. All specifications are based on differential measurements. The OOB sequence is performed at signal voltage levels corresponding to the lowest supported transfer rate. Table 29 specifies the signal characteristics.
- Page 71 10.5.2.3 Receiver signal characteristics Table 30 defines the compliance point requirements of the signal at the receiver end of a TxRx connection as measured into the test loads specified in figure 21 and figure 22. Table 30: Receiver signal characteristics Signal characteristic Units 1.5 Gbps...
- Page 72 10.5.2.3.2 Receiver jitter tolerance Table 32 defines the amount of jitter the receiver shall tolerate . Table 32: Receiver jitter tolerance 1.5 Gbps 3.0 Gbps Sinusoidal Deterministic Total Sinusoidal Deterministic Total e,f,h e,g,h jitter jitter jitter jitter jitter jitter 0.10 0.35 0.65 0.10...
- Page 73 Table 33: Impedance requirements (Sheet 2 of 2) Requirement Units 1.5 Gbps 3.0 Gbps Common mode impedance 20 min/40 max 20 min/40 max Transmitter source termination Differential impedance 60 min/115 max 60 min/115 max Differential impedance imbalance Common mode impedance 15 min/40 max 15 min/40 max a All times indicated for time domain reflectometer measurements are recorded times.
- Page 74 A combination of a zero-length test load and the transmitter compliance transfer function (TCTF) test load methodology is used for the specification of transmitter characteristics. This methodology specifies the trans- mitter signal at the test points on the required test loads. The transmitter uses the same settings (e.g., pre- emphasis, voltage swing) with both the zero-length test load and the TCTF test load.
- Page 75 Figure 22 shows the zero-length test load. 50 ohm 10 nF Probe points 10 nF 50 ohm SAS internal connector Figure 22. Zero-length test load Figure 23 shows an ISI loss example at 3.0 Gbps. (dB) Compliance interconnect magnitude response and ISI loss example for 3.0 Gbps ISI loss >...
- Page 76 10.5.2.5 Receiver characteristics The drive receiver is A.C. coupled. The receive network terminates the TxRx connection by a 100 ohm equiva- lent impedance as specified in table 33. The receiver operates within a BER of 10 when a SAS signal with valid voltage and timing characteristics is delivered to the compliance point from a 100 ohm source.
- Page 77 Index unformatted 9 check condition status 57 chemical pollutants 37 Numerics class B limit 3 clear ACA function 46 12 volt clear task set function 46 pins 62 commands supported 48 5 volt pins 62 condensation 33 condition met/good status 57 connector illustrated 60 abort task set function 46...
- Page 78 environmental control 36 IRAW 42 error management 39 rates 13 jumpers 43 errors 39 latency FCC rules and regulations 3 average rotational 9 features 7 logical block address 11 interface 46 logical block reallocation scheme 7 firmware 7 logical block size 7 corruption 51 logical segments 11 flawed sector reallocation 7...
- Page 79 non-operating 33 reliability 8 temperature 33 specifications 13 non-operating vibration 36 reliability and service 14 repair and return information 19 reporting actual retry count 57 reservation conflict status 57 office environment 36 resonance 34 operating 33 return information 19 option selection 61 rotation speed 9 out-of-plane distortion 45 safety 3...
- Page 80 task management functions 46 Abort task set 46 Clear ACA 46 Clear task set 46 terminate task 46 task management response codes 46 Function complete 00 46 Function not supported 05 46 Function reject 04 46 task set full status 57 technical support services 1 temperature 33 limits 33...
- Page 82 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100466193, Rev.
