ECS Motherboard User Manual

Motherboard
Hide thumbs Also See for Motherboard:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Manual

Advertisement

Table of Contents
loading

Related Manuals for ECS Motherboard

Summary of Contents for ECS Motherboard

  • Page 3 Motherboard User’s Guide This publication, including photographs, illustrations and software, is under the protection of international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer.

  • Page 4: Table Of Contents

    Features and Checklist Translation ........v Chapter 1: Introduction ............1 Key Features ..................2 Package Contents ................5 Chapter 2: Motherboard Installation ........7 Motherboard Components ..............8 I/O Ports ..................... 10 Installing the Processor ..............11 Installing Memory Modules ............... 12 Jumper Settings ..................

  • Page 5: Static Electricity Precautions

    If you don’t have a wrist strap, discharge static electricity by touching the bare metal of the system chassis. 3. Carefully hold this motherboard by its edges. Do not touch those components unless it is absolutely necessary. Put this motherboard on the top of static-protection package with component side facing up while installing.
  • Page 6 Motherboard User’s Guide Notice: 1. Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certified yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pop out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.
  • Page 7 Guide de l’utilisateur de la carte mère Traduction des Caractéristiques & Liste de contrôle Liste de contrôle Le coffret de votre carte mère contient les éléments suivants: La carte mère • Guide de l’utilisateur • Un câble plat pour lecteur de disquette (optionnel) •...
  • Page 8 Guide de l’utilisateur de la carte mère Supporte maîtrise de bus Ultra DMA IDE avec vitesse de transfert de 133/100/ • 66 Mo/sec Accélérateur Graphique 3D de Haute Performance & Haute Qualité. Intégré • dans un moteur 256 bits 3D hautes performances •...
  • Page 9 Guide de l’utilisateur de la carte mère • Le périphérique multifonction PCI consiste en deux noyaux de Contrôleur d’Hôtes UHCI pour signalisation pleine/faible vitesse et un noyau de Con- trôleur d’Hôtes EHCI pour signalisation haute vitesse • Le hub racine consiste en 4 ports de face en aval avec émetteur-récepteurs de couche physique intégrés partagés par le Contrôleur d’Hôte UHCI et EHCI, jusqu'à...
  • Page 10 Motherboard Benutzerhandbuch Funktionen & Checkliste Checkliste Die Verpackung Ihres Motherboards enthält folgende Teile: Motherboard • Benutzerhandbuch • Bandkabel für Floppylaufwerke (optional) • Bandkabel für IDE-Laufwerke • Software -CD • Ausstattung LGA775 Socket Prozessor-Unterstützung Unterstützt die neuesten Prozessoren der Intel Pentium 4/ Celeron D Serie •...
  • Page 11 Front-Out, Surround-Out, MIC-In und LINE-In-Jack Sensing • Zwei analoge Line-Level Mono-Eingänge • Standard 48-Pin LQFP • Onboard-I/O-Steckplätze Das Motherboard verfügt über einen kompletten Satz von I/O-Steckplätze und Anschlüssen: Zwei PS/2-Steckplätze für Maus und Tastatur • Ein serieller Steckplatz • Ein paralleler Steckplatz •...
  • Page 12 Motherboard Benutzerhandbuch Unterstützt PCI-Bus Power Management Interface , Spezifikation Release 1.1 • Legacy-Unterstützung für alle Downstream-Ports • Hinweis:Bestimmte Hardwarespezifikationen und Teile der softwareausstattung können ohne weitere Ankündigung abgeändert werden.
  • Page 13 Guida dell’utente della scheda madre Traduzione Funzioni e Lista Lista L’imballo della scheda madre é composto da: La scheda madre • Guida dell’utente • Una piattina per il collegamento dei drive (opzionale) • Una piattina IDE • Il CD con il Software di supporto •...
  • Page 14 Guida dell’utente della scheda madre Acceleratore grafico 3D a elevate prestazioni e qualità: avanzato motore 3D a • 256 bit integrato Acceleratore grafico 2D a elevate prestazioni: frame buffer fino a 64 MB con • indirizzamento lineare Decoder Video MPEG-2/1: conformità agli standard MPEG-2 ISO/IEC 13818- •...
  • Page 15 Guida dell’utente della scheda madre • Il root hub è composto in 4 porte in downstream facing con ricevitore physical layer integrato condiviso dall’Host Controller UHCI e EHCI sino a otto porte funzionali • Supporto per interfaccia risparmio energia bus PCI specifiche release 1.1 •...
  • Page 16 Guía de Usuario de la Placa Principal Traducción de Características & Lista LISTA DE VERIFICACIÓN El paquete de su placa principal contiene los sigtes. ítems: La placa principal • Guía del Usuario • Un cable cinta para el lector de disquete (optativo) •...
  • Page 17 Guía de Usuario de la Placa Principal Acelerador de Gráficas 3D de alto rendimiento & alta calidad: un motor de • 256-bit de alto rendimiento incorporado Acelerador de Gráficas 2D de alto rendimiento: máximo 64MB de buffer de • marco con dirección lineal Decodificador de Vídeo MPEG-2/1: conformidad de las normas MPEG-2 •...
  • Page 18 Guía de Usuario de la Placa Principal • Soporta Especificación de Interfaz de Administración de Energía de BUS PCI versión 1.1 • Soporte de legado para todos los puetos que miran hacia abajo Nota: Algunas especificaciones de hardware e ítems de software son sujetos a cambio sin aviso previo .
  • Page 19 Guia de Utilizador da Motherboard Tradução da Lista & Características Lista de verificação A embalagem da sua placa principal contém os seguintes itens: A placa principal • O Guia de Utilizador • Um cabo para a unidade de disquetes (opcional) •...
  • Page 20 Guia de Utilizador da Motherboard Acelerador de Gráficos 3D de Alta Qualidade & Elevada Performance: incor- • porado com um dispositivo 3D de 256 bits de elevada performance Acelerador de Gráficos 2D de Elevada Performance: com buffer de imagens •...
  • Page 21 Guia de Utilizador da Motherboard • Suporte de gestão de energia PCI-Bus Revisão 1.1 da especificação da inter- face • Suporte para todas as portas de protecção a jusante Nota: As especificações de alguns artigos de hardware e software encontram-se sujeitos a alterações sem aviso prévio.
  • Page 22 主板用户指南 功能和检查单翻译 检查单 您的主板包装含有以下项目： 主板 • 用户手册 • 一根磁盘驱动器扁平电缆（可选） • 一根 IDE 驱动器扁平电缆 • 软件支持 CD • 功能 支持 LGA775 Socket 处理器 支持带多线程技术的最新 Intel Pentium 4 / Celeron D 系列处理器 • 支持 800 MHz前端总线 • 多线程技术可以让操作系统认为自己连接了两个处理器，允许两个线程并行运 行，每个线程位于同一处理器中的单独“逻辑”处理器中。 芯片组 芯片组包含 SiS661FX 北桥 和 SiS964L 南桥, 它基于一种新型的、可扩展的架构 ，能提供已经证明的可靠性和高性能。...
  • Page 23 主板用户指南 高性能高质量 3D 图形加速器：内建高性能 256 位 3D 引擎 • 高性能 2D 图形加速器：最大 64MB 帧缓冲区，带线性寻址 • MPEG-2/1 视频解码器：符合 MPEG-2 ISO/IEC 13818-2 MP@HL 和 MPEG-1 • ISO/IEC 11172-2 标准 AC’97 Codec 兼容 AC’97 2.3 规格 • 具有可调独立采样速率的 16 位立体声全双工 CODEC（编解码器） • 它支持 3.3v 数字、5v 模拟电源和低功耗管理 •...
  • Page 24 主板用户指南 xxii...

  • Page 25: Chapter 1 Introduction

    Line-in, Line-out and Microphone, and four back-panel USB2.0 ports. In addition, onboard USB headers USB2/USB3 provide extra ports by connecting the Extended USB Module to the motherboard. It is a Micro ATX motherboard and has power connectors for an ATX power supply.

  • Page 26: Key Features

    Motherboard User’s Guide Key Features The key features of this motherboard include: LGA775 Socket Processor Support Supports the latest Intel Pentium 4/Celeron D Series processors with Hyper-Threading Technology Supports up to 800 MHz Front-Side Bus Hyper-Threading technology enables the operating system into thinking it’s hooked up to two processors, allowing two...
  • Page 27 Chapter 1: Introduction Supports DDR400/333/266 memory bus Maximum installed memory is 2GB Expansion Slots Three 32-bit PCI slots One 8X AGP slot One CNR slot Onboard IDE channels Two IDE Connectors Supports PIO (Programmable Input/Output) and DMA (Direct Memory Access) modes Supports IDE Ultra DMA bus mastering with transfer rates of 133/100/66 MB/sec High Performance &...
  • Page 28 Motherboard User’s Guide Onboard I/O Ports The motherboard has a full set of I/O ports and connectors: Two PS/2 ports for mouse and keyboard One serial port One parallel port One VGA port One LAN port (optional) Four back-panel USB 2.0 ports...
  • Page 29 Chapter 1: Introduction BIOS Firmware This motherboard uses AMI BIOS that enables users to configure many system features including the following: Power management Wake-up alarms CPU parameters and memory timing CPU and memory timing The firmware can also be used to set parameters for different processor clock speeds.

  • Page 30: Package Contents

    Motherboard User’s Guide Package Contents Your motherboard package contains the following items: The motherboard The User’s Guide One diskette drive ribbon cable (optional) One IDE drive ribbon cable The Software support CD Optional Accessories You can purchase the following optional accessories for this motherboard.

  • Page 31: Chapter 2 Motherboard Installation

    Chapter 2: Motherboard Installation Chapter 2 Motherboard Installation To install this motherboard in a system, please follow these instructions in this chapter: Identify the motherboard components Install a CPU Install one or more system memory modules Make sure all jumpers and switches are set correctly...

  • Page 32: Motherboard Components

    Motherboard User’s Guide Motherboard Components CPUFAN1 LGA775 SOCKET CPUPW1 ATXPW1 AUDIO2 AGP1 SYSFAN2 USB2/3 SPDIFO1 SPK1 PANEL1 CNR1 FDD1 SYSFAN1...
  • Page 33 Chapter 2: Motherboard Installation LABEL COMPONENTS DDR1/2 Two 184-pin DDR SDRAM sockets IDE1/2 Primary/Secondary IDE connectors CPUPW1 Standard 4-Pin ATX Power connector ATXPW1 Standard 20-Pin ATX Power connector USB2/USB3 Front Panel USB headers FDD1 Floppy Disk Drive connector PANEL1 Front Panel Switch/LED header...

  • Page 34: I/O Ports

    Motherboard User’s Guide I/O Ports The illustration below shows a side view of the built-in I/O ports on the motherboard. Optional PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS/2 Keyboard Use the lower PS/2 port to connect a PS/2 keyb oard.

  • Page 35: Installing The Processor

    Chapter 2: Motherboard Installation Installing the Processor This motherboard has a LGA775 socket for the latest Intel Pentium 4/Celeron D processors. When choosing a processor, consider the performance requirements of the system. Perfor- mance is based on the processor design, the clock speed and system bus frequency of the processor, and the quantity of internal cache memory and external cache memory.
  • Page 36 Motherboard User’s Guide Be careful not to touch the contacts. C. Install the CPU on the socket • Orientate CPU package to the socket. Make sure you match triangle marker to pin 1 location. D. Close the load plate •...

  • Page 37: Installing Memory Modules

    Chapter 2: Motherboard Installation Installing Memory Modules This motherboard accommodates two 184-pin 2.5V DIMM sockets (Dual Inline Memory Module) for unbuffered DDR400/ 333/266 (Double Data Rate SDRAM), and maximum 2.0 GB installed memory. DDR SDRAM is a type of SDRAM that supports data transfers on both edges of each clock cycle (the rising and falling edges), effectively doubling the memory chip’s data throughput.
  • Page 38 Motherboard User’s Guide Memory Module Installation Procedure These modules can be installed with up to 2 GB system memory. Refer to the following to install the memory module. Push down the latches on both sides of the DIMM socket. Align the memory module with the socket. There is a notch on the DIMM socket that you can install the DIMM module in the correct direction.

  • Page 39: Jumper Settings

    CMOS memory if the settings in the Setup Utility are incorrect and prevent your motherboard from operating. To clear the CMOS memory, disconnect all the power cables from the motherboard and then move the jumper cap into the CLEAR setting for a few seconds. Function...

  • Page 40: Install The Motherboard

    SB5V function. Install the Motherboard Install the motherboard in a system chassis (case). The board is a Micro ATX size motherboard. You can install this motherboard in an ATX case. Make sure your case has an I/O cover plate matching the ports on this motherboard.

  • Page 41: Connecting Optional Devices

    Chapter 2: Motherboard Installation Connect the power connector from the power supply to the ATXPW1 connector on the motherboard. The CPUPW1 is a +12V connector for CPU Vcore power. If there is a cooling fan installed in the system chassis, connect the cable from the cooling fan to the SYSFAN1/2 fan power connec- tor on the motherboard (SYSFAN2 is an optional connector).
  • Page 42 AUD_RET_L USB2/USB3: Front panel USB Headers The motherboard has USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB headers USB2/USB3 to connect the front-mounted ports to the motherboard.

  • Page 43: Install Other Devices

    Via a specific audio cable, you can connect the SPDIFO1 header (S/PDIF output) on the motherboard to the S/ PDIF digital input on the external speakers or AC Decode de- vices.
  • Page 44 IDE devices include hard disk drives, high-density diskette drives, and CD-ROM or DVD-ROM drives, among others. The motherboard ships with an IDE cable that can support one or two IDE devices. If you connect two devices to a single cable, you must configure one of the drives as Master and one of the drives as Slave.
  • Page 45 If you want to install more IDE devices, you can purchase a second IDE cable and connect one or two devices to the Second- ary IDE channel connector IDE2 on the motherboard. If you have two devices on the cable, one must be Master and one must be Slave.

  • Page 46: Expansion Slots

    Motherboard User’s Guide Expansion Slots This motherboard has one AGP, CNR and three 32-bit PCI slots. AGP1 PCI1 PCI2 PCI3 CNR1...
  • Page 47 Chapter 2: Motherboard Installation Follow the steps below to install an AGP/CNR/PCI expansion card. Locate the AGP, CNR or PCI slots on the motherboard. Remove the blanking plate of the slot from the system chassis. Install the edge connector of the expansion card into the slot.

  • Page 48: Chapter 3 Bios Setup Utility

    You can run the setup utility and manually change the configura- tion. You might need to do this to configure some hardware installed in or connected to the motherboard, such as the CPU, system memory, disk drives, etc.

  • Page 49: Running The Setup Utility

    Chapter 3: BIOS Setup Utility Running the Setup Utility Every time you start your computer, a message appears on the screen before the operating system loading that prompts you to “Hit <DEL>if you want to run SETUP”. Whenever you see this message, press the Delete key, and the Main menu page of the Setup Utility appears on your monitor.

  • Page 50: Standard Cmos Setup Page

    Motherboard User’s Guide Standard CMOS Setup Page This page displays a table of items defining basic information about your system. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Standard CMOS Setup System Time 00:00:10 Help Item System Date...

  • Page 51: Advanced Setup Page

    Chapter 3: BIOS Setup Utility Advanced Setup Page This page sets up more advanced information about your system. Handle this page with caution. Any changes can affect the operation of your computer. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Advanced Setup Share Memory Size 32MB...
  • Page 52 Motherboard User’s Guide BootUp Num-Lock This item determines if the Num Lock key is active or inactive at system start-up time. Boot To OS/2> 64MB Enable this item if you are booting the OS/2 operating system and you have more than 64MB of system memory installed.

  • Page 53: Features Setup Page

    Chapter 3: BIOS Setup Utility Spread Spectrum If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic Interference) generated by the system. DRAM Voltage Control Use this item to adjust the voltage of the DRAM memory. CPU Vcore Voltage Adjustment Use this item to adjust the Vcore voltage of the CPU.
  • Page 54 Motherboard User’s Guide Serial Port1 Address Use this item to enable or disable the onboard COM1 serial port, and to assign a port address. OnBoard IR Port Use this item to enable or disable the onboard infrared port, and to assign a port address.

  • Page 55: Power Management Setup Page

    Enable this item if you plan to use the USB ports on this motherboard. USB Function For DOS Enable this item if you plan to use the USB ports on this motherboard in a DOS environment. Power Management Setup Page This page sets some parameters for system power management operation.
  • Page 56 Motherboard User’s Guide Suspend Mode Use this item to define how your system suspends. In the default, S1(POS), the suspend mode is equivalent to a software power down. If you select S3 (STR), the suspend mode is a suspend to RAM, i.e., the system shuts down with the exception of a refresh...

  • Page 57: Pci/Plug And Play Setup Page

    Chapter 3: BIOS Setup Utility PCI / Plug and Play Setup Page This page sets up some parameters for devices installed on the PCI bus and those utilizing the system plug and play capability. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. PCI / Plug and Play Setup Primary Graphics Adapter Help Item...

  • Page 58: Bios Securityfeatures Setup Page

    Motherboard User’s Guide BIOS Security Features Setup Page This page helps you install or change a password. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. BIOS Security Features Setup Security Settings Help Item Install or Change Supervisor Password : Not Installed the password.

  • Page 59: Cpu Pnp Setup Page

    Chapter 3: BIOS Setup Utility CPU PnP Setup Page This page helps you manually configure the mainboard for the CPU. The system will automatically detect the type of installed CPU and make the appropriate adjustments to the items on this page.

  • Page 60: Hardware Monitor Page

    Motherboard User’s Guide Hardware Monitor Page This page sets up some parameters for the hardware monitoring function of this motherboard. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Hardware Monitor Setup ***System Hardware Monitor*** Help Item Vcore 1.296 V Vdimm 2.496 V...

  • Page 61: Load Optimal Settings

    Chapter 3: BIOS Setup Utility Load Optimal Defaults This option opens a dialog box to ask if you are sure to install optimized defaults or not. You select [OK], and then press <En- ter>, the Setup Utility loads all default values; or select [Cancel], and then press <Enter>, the Setup Utility does not load default values.

  • Page 62: Chapter 4 Software & Applications

    If your operating system is Windows 2000/XP, it will automatically install all the drivers and utilities for your motherboard; if Windows NT or manual installation, please follow the instructions described as the Installing under Windows NT or Manual Installation sec-...

  • Page 63: Installing Support Software

    Chapter 4: Software & Applications Installing Support Software Insert the support CD-ROM disc in the CD-ROM drive. When you insert the CD-ROM disc in the system CD- ROM drive, the CD automatically displays an Auto Setup screen. The screen displays three buttons of Setup, Browse CD and Exit on the right side, and three others Setup, Application and ReadMe at the bottom.
  • Page 64 Motherboard User’s Guide Auto-Installing under Windows 2000/XP If you are under Windows 2000/XP, please click the Setup button to run the software auto-installing program while the Auto Setup screen pops out after inserting the support CD-ROM: The installation program loads and displays the following screen.

  • Page 65: Bundled Software Installation

    Chapter 4: Software & Applications Installing under Windows NT or Manual Installation If you are under Windows NT, the auto-installing program doesn’t work out; or you have to do the manual installation, please follow this procedure while the Auto Setup screen pops out after insert- ing the support CD-ROM: Click the ReadMe to bring up a screen, and then click the Install Path at the bottom of the screen.
  • Page 66 Motherboard User’s Guide Hyper-Threading CPU While you are in Windows Task Manager, please push down ctrl+Alt Del keys. A dual CPU appears in the CPU Usage History&Device Manager under WinXP. Note: Hyper-Threading Function only works under WINXP Operating System; therefore, disable it under other Operating...
