3 | NDN-921 FlexiDomeHD 720p Day/Night IP Camera
Cost effective, simple installation
Three power options, PoE (Power-over-Ethernet), 24
VAC and 12 VDC are available. Using PoE makes
installation easier and more cost-effective, as cameras
do not require a local power source. To increase
system reliability, the camera can be simultaneously
connected to both PoE and 12 VDC/24 VAC supplies.
Additionally, uninterruptible power supplies (UPS) can
be used, which will allow continuous operation, even
during a power failure.
For trouble-free network cabling, the cameras support
Auto-MDIX which allows the installer to use straight or
cross-over cables.
Easy Upgrade
Remotely upgrade the camera whenever new firmware
becomes available. This ensures up-to-date products,
thus protecting investment with little effort.
Access Security
Various security levels are available for accessing the
network, the camera, and the data channels. As well
as password protection with three levels, 802.1x
authentication using a RADIUS (Remote Authentication
Dial In User Service) server is supported. To secure
Web browser access, use HTTPS with a SSL certificate
stored in the camera. For total data protection, the
video and audio communication channels can be
independently AES encrypted with 128-bit keys by
installing the optional encryption site license.
Typical applications
• Prisons and correctional facilities
• Retail outlets
• Commercial and government buildings
• Schools
• Hospitals
• Banks
• City surveillance
• Places with high crowd density or mass gatherings
Certifications and approvals
HD standards
Complies with the 296M-2001 Standard in:
– Resolution: 1280x720
– Scan: Progressive
– Color representation: complies with ITU-R BT.709
– Aspect ratio: 16:9
– Frame rate: 25 and 30 frames/s
Electro Magnetic Compatibility
Emission EN55022 Class B
EN61000-3-2
EN61000-3-3
FCC Part 15: Class B
Immunity EN50130-4 (PoE, +12 VDC)
EN55024 (24 VAC)
EN50121-4
Safety EN60950-1
UL60950-1 (2nd edition)
CAN/CSA-C 22.2 No. 60950-1
Vibration As per IEC60068-2-6 (5 m/s
Region Certification
Canada CSA
Europe CE
USA UL
FCC

Installation/configuration notes

Ordering chart
921
1 N Network camera
2 D Dome (FlexiDome fixed dome)
3 N Day/Night
4 921 DinionHD performance
5 V Varifocal lens, auto iris
6 03 3 to 9 mm F1.4
7 Motion+
2 IVA Ready *
I IVA enabled
8 P PoE
9 Flush mount (blank)
S Surface mount
* No license included
Flush Mounting
, operational)
2
I
