RS-232C Control Specification
Notes:
If [Power Saving Standby is set to enable] / [Power Saving is set ON] (Depend on the
models), the BD Player denies the command from RS-232C. It means the BD Player does
not turn on via RS-232C control. Please set [Power Saving = Normal Standby or Quick
Start Mode] / [Power Saving = Off] for the power on/off control via RS-232C. Please refer to
"Power Saving" setup part in each User manual for the detail.
Category
Document Version
Author(s)
Last update
Number of Page
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of copyright.
All specifications might be subject to change without notice.
UD, BD Player
:
Universal(SA-CD/Blu-ray/DVD/CD), BD/DVD/CD Player
:
1.0
:
Marantz America, Inc.
:
Feb/12/2010
:
39
Marantz America, Inc. 2010
RS-232C Control Specification :
Rev 1.1
