Cisco AS5850 Product Overview
The Cisco AS5850 is a high-density, ISDN and modem WAN aggregation system that provides both
digital and analog call termination. It is intended to be used in service provider dial point-of-presence
(POP) or centralized enterprise dial environments.
The gateway components include hybrid trunk and port-handling cards (both functions are handled by
different components in the same slot), dedicated port-handling cards, dedicated trunk cards, route
switch controllers, power entry modules, and a blower unit to cool the chassis. An optional 2400W AC
power shelf is also available. The gateway is designed with environmental monitoring and reporting
functions to help maintain normal system operation and resolve adverse environmental conditions prior
to loss of operation. If conditions reach critical thresholds, the system shuts down to avoid equipment
damage from excessive heat or electrical current.
Downloadable software and microcode allow you to load new software images into Flash memory
remotely, without having to physically access the universal gateway, for fast and reliable upgrades.
This chapter provides physical and functional overviews to familiarize you with your new
Cisco AS5850. The chapter also contains physical descriptions of system hardware and major
components and functional descriptions of component features.
Descriptions and examples of software commands appear in this document only when they are
Note
necessary for installing the system hardware. For software configuration information, refer to the
Cisco AS5850 Universal Gateway Commissioning Guidelines that shipped with your system, or the
Cisco AS5850 Universal Gateway Operation, Administration, Maintenance, and Provisioning
Guide. These documents are available on Cisco.com (http://www.cisco.com), by selecting:
Products and Services > Universal Gateways > Cisco AS5800 Universal Gateways
This chapter contains the following sections:
•
•
•
•
•
Split Backplane, page 1-11
•
•
•
78-10573-06 0A
C H A P T E R
Cisco AS5850 Universal Gateway Hardware Installation Guide
1
1-1

Advertisement

loading

Related Manuals for Cisco AS5850

Summary of Contents for Cisco AS5850

  • Page 1: Table Of Contents

    C H A P T E R Cisco AS5850 Product Overview The Cisco AS5850 is a high-density, ISDN and modem WAN aggregation system that provides both digital and analog call termination. It is intended to be used in service provider dial point-of-presence (POP) or centralized enterprise dial environments.

  • Page 2: If You Already Have A Cisco As5800

    If You Already Have a Cisco AS5800 If You Already Have a Cisco AS5800 If you already have a Cisco AS5800, the Cisco AS5850 should be easy to adjust to. The following major differences should be noted: The cooling module is 1 RU shorter.
  • Page 3 Chapter 1 Cisco AS5850 Product Overview System Components Figure 1-1 Cisco AS5850 with 2400W AC-Input Power Shelf—Front View Power LED Fault LEDs Cooling module Power Fault Bank 1 Bank 2 Bank 3 Captive screws 14-slot card cage (Line, port, and...

  • Page 4: Functional Overview

    Functional Overview The Cisco AS5850 supports high-density dial aggregation and integrates with the Cisco AS5350 and Cisco AS5400 universal gateways for scaling your service provider network. The Cisco AS5850 universal gateway also supports high availability of service through online insertion and removal (OIR) capabilities and redundant power modules that are hot swappable.
  • Page 5 Functional Overview any DS0 can be mapped to any HDLC controller or universal port. You can install multiple ingress interface cards of like types and configure the Cisco AS5850 for card or port level redundancy, depending on your needs. Trunk and port handling cards are tied together using several time-division multiplexing (TDM) buses on the backplane.
  • Page 6 Cisco AS5850 Product Overview Functional Overview A dial wholesale customer can connect to a Cisco AS5850, then tunnel PPP (Point-to-Point Protocol) packet information to a retail service provider using dial Virtual Private Network (dial VPN). For detailed system specification tables, refer to Appendix A, “Cisco AS5850 Specifications.”...
  • Page 7 PS 2 PS 3 power shelf (optional) 120/240 VAC 15A 120/240 VAC 15A 120/240 VAC 15A Note VDC output of the 2400 W AC power shelf is set at -51 volts DC. Cisco AS5850 Universal Gateway Hardware Installation Guide 78-10573-06 0A...

  • Page 8: Network Management

    The Cisco Universal Gateway Manager (Cisco UGM) configures and manages fault, performance, and security of the Cisco AS5850. Cisco UGM is a UNIX-based solution that can be run from a Cisco Element Management Framework (EMF) server, and also provides the following features: Fault Device and port-specific alarm frequency and severity information.

  • Page 9: Cisco As5850 Chassis

    Cisco AS5850 Chassis The Cisco AS5850 contains 14 slots (numbered 0 through 13 on the backplane) and can support trunk cards and universal port cards in slots 0 through 5 or 8 through 13. Slots 6 and 7 in the chassis are dedicated slots for the RSCs.
  • Page 10 RSC. However, the command is not rejected, because the values configured on the other RSC may not be known. Warning messages are issued to both RSCs when this Cisco AS5850 Universal Gateway Hardware Installation Guide 1-10...
  • Page 11 The split backplane configuration of the Cisco AS5850 platform increases bandwidth by using two RSCs. The dual RSCs serve as the interfaces between the split Cisco AS5850 gateway and the external network. Split backplane configuration requires two RSC cards. For more information on hardware and...
  • Page 12 RSC that owns it. Slot Ownership Arbitration The Cisco AS5850 operates in a default split backplane mode. Currently, the RSC in slot 6 automatically owns all cards in slots 0 through 5, and does not receive inventory messages from cards present in slots 8 through 13.

  • Page 13: Field-Replaceable Units

    AC-input single power module AS58-PWR-3AC/MOD= For information about the feature cards used in the Cisco AS5850, refer to the Cisco AS5850 Universal Gateway Card Guide that shipped with your system. For information about other FRUs, review the rest of this chapter, or for detailed specification tables, refer to Appendix A, “Cisco AS5850 Specifications.”...
  • Page 14 Field-Replaceable Units Feature Cards For information about the feature cards used in the Cisco AS5850, refer to the Cisco AS5850 Universal Gateway Card Guide that shipped with your system. For information about other FRUs, review the rest of this chapter, or for detailed specification tables, refer to Appendix A, “Cisco AS5850 Specifications”...
  • Page 15 Connects to an external alarm source through a connector located on the front panel • Install the RSC card in the Cisco AS5850 in either slot 6 or slot 7. The card plugs directly into the backplane. The RSC card consists of the following components: •...
  • Page 16 RSC front panel LEDs. Figure 1-7 RSC Front Panel Bell alarm terminal block LCD display MODE Push buttons MAST FLASH Console port Auxiliary port FE port Network clock BNC connector Cisco AS5850 Universal Gateway Hardware Installation Guide 1-16 78-10573-06 0A...
  • Page 17 Comes on when power is on and the RSC is power) not in the reset state. HIST (history clear) Yellow Comes on when software recognizes a major or minor alarm situation. The LED will stay on until cleared. Cisco AS5850 Universal Gateway Hardware Installation Guide 1-17 78-10573-06 0A...
  • Page 18 (option will flash when it is configurable). Press repeatedly (for 0.25 seconds) to cycle through possible parameters for that option. SEL button Press (2 seconds) to accept the displayed and flashing parameter. Cisco AS5850 Universal Gateway Hardware Installation Guide 1-18 78-10573-06 0A...
  • Page 19 TDM bus data movement. The common logic can use a variety of sources to generate this system timing, including a T1 or E1 signal input from the BNC connector on the RSC front panel. Cisco AS5850 Universal Gateway Hardware Installation Guide 1-19...
  • Page 20 802.1q and 802.1p VLAN support is available on the Gigabit Ethernet interface of the ERSC. The Note daughter card on the ERSC has two GigE ports and a front panel with FastEthernet ports. Cisco AS5850 Universal Gateway Hardware Installation Guide 1-20 78-10573-06 0A...
  • Page 21 Chapter 1 Cisco AS5850 Product Overview Field-Replaceable Units Figure 1-9 RSC Gigabit Ethernet Egress Interfaces Cisco AS5850 Universal Gateway Hardware Installation Guide 1-21 78-10573-06 0A...
  • Page 22 Table 1-9 GBIC to Host Connector Pin Assignment Pin Signal RX_LOS RGND RGND MOD_DEF(0) MOD_DEF(1) MOD_DEF(2) TX_DISABLE TGND TGND TX_FAULT RGND -RX_DAT +RX_DAT RGND TGND +TX_DAT -TX_DAT TGND Cisco AS5850 Universal Gateway Hardware Installation Guide 1-22 78-10573-06 0A...
  • Page 23 WS-G5486 DC-Input Power Entry Module The Cisco AS5850 is equipped with two power-entry modules (PEMFs), which accept DC-input power either from your site DC source or from an optional AC-input power shelf, and distribute –48 VDC to –60 VDC power to the chassis components using the backplane. The PEMFs provide power redundancy and load-sharing;...
  • Page 24 Table 1-12. If a PEMF is not properly seated in the Cisco AS5850 backplane, an electronic circuit, or interlock, trips a breaker in the PEMF and terminates power to the output connectors. This same interlock provides reverse polarity protection when the system is powered off.
  • Page 25 PEMF (visible only from below the chassis) connects a monitor cable to an optional AC-input power shelf. The PEMFs are located on the rear of the universal gateway. Figure 1-2 shows the location of the PEMFs as viewed from the rear of the chassis. Cisco AS5850 Universal Gateway Hardware Installation Guide 1-25 78-10573-06 0A...
  • Page 26 The 2400W AC-input power shelf includes three 1200-watt (W) AC-input power modules that plug into a common power backplane in the 2400W AC-input power shelf. Two 1200W AC-input power modules are capable of powering a fully configured Cisco AS5850. The third power module provides full redundancy.
  • Page 27 Internal monitoring data is passed to the chassis through the maintenance bus (Mbus) monitoring system. You can view this data through a terminal connected to the RSC console port. The command to display the monitoring information is described in the Cisco AS5850 Universal Gateway Operation, Administration, Maintenance, and Provisioning Guide, available online at: http://www.cisco.com/univercd/cc/td/doc/product/access/acs_serv/as5850/sw_conf/5850oamp/...

  • Page 28: Power Requirements

    On indicates a power fault condition such as overvoltage, undervoltage, overtemperature, or HV bus low. Power Requirements The Cisco AS5850 ships configured for either AC-input or DC-input power with loadsharing, depending on your order. AC-Input Power Specifications The Cisco AS5850 accepts AC-input power using a separate, self-contained AC-input power shelf, which converts AC-input power into DC output for use by the universal gateway.

  • Page 29: Online Insertion And Removal

    75V eventually trip the PEMF 60A circuit breaker, and you might have to reset the breaker. The Cisco AS5850 supports several types of logic cards with varying power requirements. As a result, each logic card DC-to-DC converter system is isolated from the distributed –48 VDC power, creating a more stable distributed power system.
  • Page 30 Chapter 1 Cisco AS5850 Product Overview Online Insertion and Removal Cisco AS5850 Universal Gateway Hardware Installation Guide 1-30 78-10573-06 0A...
