  • Page 1 S-636 / S-646 SE Q uickie ® S-636 / S-646 SE BC, SC, MPC / BD, SD, MPD Supplier: This manual must be given to the user of O w n e r ’ s M a n u a l this wheelchair.

  • Page 2: For Answers To Your Questions

    S - 6 3 6 / S - 6 4 6 I. INTRODUCTION SUNRISE LISTENS Thank you for choosing a Quickie wheelchair. We want to hear your questions or comments about this manual, the safety and reli- ability of your chair, and the service you receive from your Sunrise supplier.

  • Page 3: Table Of Contents

    M. SEAT FRAME TILT STOP PADS........22 S. RAMPS, SLOPES & SIDEHILLS ........10 N. CHECK-OUT ..............22 T. TO REDUCE THE RISK OF A FALL, –S-636/S-646 SE ............23 TIP-OVER OR LOSS OF CONTROL ......11 A. PERFORMANCE CONTROL SETTINGS ......23 U. RAMPS AT HOME & WORK .........11 B.

  • Page 4: Your Chair And Its Parts

    S - 6 3 6 / S - 6 4 6 III. YOUR CHAIR AND ITS PARTS YOUR QUICKIE S-636 / S-646 SE & ITS PARTS Push Handle Flip back dual post armrest Remote joystick Aluminum Seat Pan Swing-away footrest latch plate...
  • Page 5 Height Adjustable Armrest Backrest Headrest Back Support Shroud Vent Tray (optional) Backrest Pivot Plate S-636 / S-646 Power Base Angle Adjustable Foot Plate 10. Calf Pad 11. Elevating Legrest (optional) 12. Seat Pan All features may not be available with some chair setups or in conjunction with another chair feature.

  • Page 6: Notice- Read Before Use

    S - 6 3 6 / S - 6 4 6 IV. NOTICE– READ BEFORE USE A. CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS Sunrise provides a choice of many power wheelchair styles, sizes and adjustments to meet the needs of the rider. However, final selection of a wheelchair rests solely with you and your health care professional.

  • Page 7: Emi (Electromagnetic Interference)

    3. The configuration tested and found to be immune to at least 20 and transceivers. (A “transceiver” is a device that both sends V/m is: Quickie S-636 / S-646 power wheelchair with a right and receives radio wave signals). hand mounted RNET remote joystick system, 20” seat width, 2.

  • Page 8: General Warnings

    1. Never exceed the following weight capacities: fall, tip-over or loss of control may occur and cause S-636 SC = 400 lbs; S-636 MPC = 300 lbs; S-646 = 300 lbs. severe injury to your or others. The weight capacity of your S-636/S-646 is identified by a label located on the inside cover of the battery compartment door.

  • Page 9: G.changes & Adjustments

    WARNING WARNING 1. This chair is designed for use on firm, even surfaces such as Never use non-Quickie parts or make a changes to your concrete, asphalt and indoor flooring. chair unless authorized by Sunrise. (Doing so will void the 2.

  • Page 10: N.transfers

    S - 6 3 6 / S - 6 4 6 VI. GENERAL WARNINGS N.TRANSFERS touch the joystick and cause your chair to move when you do not expect it. WARNING 4. Firmly grasp a rear wheel or an armrest with one hand. This It is dangerous to transfer on your own.

  • Page 11: To Reduce The Risk Of A Fall, Tip-Over Or Loss Of Control

    S - 6 3 6 / S - 6 4 6 VI. GENERAL WARNINGS T. TO REDUCE THE RISK OF A FALL, TIP- V. WHEELCHAIR LIFTS OVER OR LOSS OF CONTROL: WARNING Wheelchair lifts are used in vans, buses, and buildings to WARNING help you move from one level to another.

  • Page 12: Warnings: Components & Options

    WARNING WARNING Proper inflation extends the life of your tires and makes 1. Quickie sling seats, standard foam cushions, and other body your chair easier to use. supports, are not designed for the relief of pressure. 1. Do not use this chair if any of the tires are under- or over- 2.

  • Page 13: Push Handles

    Please contact your dealer or the Quickie Technical 2. Low pressure in a rear tire may cause the wheel lock on that Service Department if you do not receive this information.

  • Page 14: Set-Up, Adjustment, & Use

    Be sure this chair performs to your chosen operational settings. If it does not, turn the chair off immediately and reprogram with the Quickie DTT Programmer. if you do not own a Quickie DTT Programmer have your supplier reprogram your wheelchair as needed. Or, you can order a Quickie DTT Programming Pad for your own use, from your supplier.

  • Page 15: D.battery Removal

    S - 6 3 6 / S - 6 4 6 IX. SET-UP, ADJUSTMENT, & USE D.BATTERY REMOVAL To remove batteries for transport or service: 1. Unscrew both the right and left battery box rear cover retaining fasteners (A). 2. Lower battery box rear cover (B) until the cover is fully extended and supported by the cables (C).

  • Page 16: Remote Joystick Swing-Away Retractable Mount

    S - 6 3 6 / S - 6 4 6 IX. SET-UP, ADJUSTMENT, & USE H. REMOTE JOYSTICK SWING-AWAY RETRACTABLE MOUNT (OPTIONAL) The remote joystick is mounted with a mechanism which allows the control to be locked in a forward or retracted position using magnets.

  • Page 17: Backrest

    To achieve 1/2" increments adjust position bolt (G) to either hole (H) and refasten. N. WHEEL LOCKS Wheel locks are installed by Sunrise when requested on the Quickie S-636/S-646. 1. Mounting The wheel lock mounts to the motor mount. Use a torque setting of 100 in./lbs when adjust- ing wheel locks.

  • Page 18: O.suspension

    2. Damping Adjustment The suspension system used on the S-636/S-646 SE has the ability to adjust the rebound (damping) of the suspension. Rebound or damping is the rate at which the spring returns to its original position after experiencing a deflection.

  • Page 19: Operating Instructions

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS OPER TING INSTRUCTIONS– POWER RECLINE A. NOTES Work Surface For Set-Up: Use a flat surface, such as a table, to assemble, adjust and check your seating system. This makes the steps easier and helps ensure a correct set-up.

  • Page 20: Lateral Thoracic Supports

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS C. LATERAL THORACIC SUPPORTS 1. To adjust the height of the lateral support mount, loosen the adjustment screw until the receiver slides freely on the back posts. Tighten the adjustment screw when the proper height is determined.

  • Page 21: Seat Depth

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS J. SEAT DEPTH The seat depth can be adjusted in one-inch increments along the seat rail. Use holes in rail, viewed through side channel as a guide. NOTE–...

  • Page 22: Legrest

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS L. LEGREST 1. Legrest Length is adjusted in 5/8" increments Remove Legrest from chair. Using a 5/32 hex wrench, remove the lower two 1/4-28 screws (A). Loosen, but do not remove the upper 1/4 -20 screw (B) until the extension tube will slide within hanger.

  • Page 23: Performance Control Settings

    The On-board Programmer or RNET PC Programmer lets you adjust the control settings of the S-636/S-646. Listed below are a few of the many settings that can be adjust via the On- board Programmer or RNET PC Programmer. (See RNET OBP Owners Manual for full pro- grammable parameters.)

  • Page 24: D.joystick Stationary

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS D. JOYSTICK STATIONARY Your chair has an available programming feature called “Joystick Stationary” which can be set by your dealer. This feature senses when the joystick is displaced from neutral, yet left in a steady position for a predetermined period of time.

  • Page 25: R-Net Joysticks & Omni Controller

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS 5. Joystick (G) The joystick controls the direction and speed of your chair. Turn the chair on and move the joystick in the direction you want to go. •...

  • Page 26: Rnet Controller

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS G. RNET CONTROLLER Joystick The Rnet control system has two versions of the Joystick Module – with and without lighting con- trol. Most of the controls are common to both; however, the lighting buttons are only included on the Joystick Module with lighting control.

  • Page 27: Led Joystick

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS H. LED JOYSTICK 1. On/Off Button The on/off button applies power to the control system electronics, which in turn supply power to the wheelchair’s motors. Do not use the on/off button to stop the wheelchair unless there is an emergency.

  • Page 28: Lcd Screen

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS I. LCD SCREEN Restart When the control system requires a reboot; for The status of the control system can be understood by observing example, after a module re-configuration, this the LCD screen.

  • Page 29: Color Lcd Screen

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS J. COLOR LCD SCREEN This section covers those joystick modules that are fitted with a color LCD screen. The color LCD screen is split into three areas of information. The Top Bar, the Base Bar and the Main Screen Area.

  • Page 30: Motor Brakes

    S - 6 3 6 / S - 6 4 6 X. OPERATING INSTRUCTIONS K. MOTOR BRAKES Disconnect the motor brake when you need to manually push the chair. (For example, in an emergency, or if batteries fail). WARNING 1. Do not disengage motor brake unless power to the chair is off.

  • Page 31: Batteries

    S - 6 3 6 / S - 6 4 6 XI. BATTERIES A. INTRODUCTION 1. Notes: • Batteries supply the power for your chair. They contain a finite amount of energy and have limits on how long they can store and supply energy. •...

  • Page 32: Acid Burns (Unsealed Wet Cell Batteries)

    S - 6 3 6 / S - 6 4 6 XI. BATTERIES C. ACID BURNS (UNSEALED WET CELL BATTERIES) Acid in batteries is corrosive. It can cause serious burns to the eyes and skin and can damage floors, furniture, clothing and your wheelchair. WARNING 1.

  • Page 33: Charging Batteries

    S - 6 3 6 / S - 6 4 6 XI. BATTERIES E. CHARGING BATTERIES 4. Connect and disconnect battery cables with caution. Only connect the charger to the power supply after the charger WARNING has been connected to the chair. To avoid the risk of severe injury or death from electri- 5.

  • Page 34: Maintenance

    S - 6 3 6 / S - 6 4 6 XII. MAINTENANCE A. NOTES 1. Proper maintenance will improve performance and extend the useful life of your chair. 2. Clean your chair regularly. This will help you find loose or worn parts and will make your chair easier to use.

  • Page 35: Pneumatic Tires

    S - 6 3 6 / S - 6 4 6 XII. MAINTENANCE E. PNEUMATIC TIRES WARNING 1. Do not use this chair if any of the tires are under- or over-inflated. 2. Low pressure in a tire may cause the chair to veer to one side and result in loss of control.

  • Page 36: Maintenance Chart

    S - 6 3 6 / S - 6 4 6 XII. MAINTENANCE I. MAINTENANCE CHART You should check the items on this chart at the indicated intervals. If any of the items are loose, worn, bent or distorted, immediately have them checked and/or repaired by your authorized Sunrise supplier.

  • Page 37: Wiring Diagrams

    S - 6 3 6 / S - 6 4 6 XIII. WIRING DIAGRAMS VR2-90 R-NET EL-90 108833 Rev. C...
  • Page 38 S - 6 3 6 / S - 6 4 6 XIII. WIRING DIAGRAMS Output Module Intelligent Seating Module (ISM) R-NET BUS CONNECTIONS DRIVE ONLY AND THRU-DRIVE ACTUATOR CONNECTIONS 108833 Rev. C...
  • Page 39 S - 6 3 6 / S - 6 4 6 XIII. WIRING DIAGRAMS SWITCH DRIVEN SINGLE ACTUATOR DRIVER R-NET MULTI-ACTUATOR 108833 Rev. C...
  • Page 40 S - 6 3 6 / S - 6 4 6 XIII. WIRING DIAGRAMS R-NET MULTI-ACTUATOR W/O RECLINE LIGHTS & INDICATORS 108833 Rev. C...

  • Page 41: Sunrise Limited Warranty

    S - 6 3 6 / S - 6 4 6 XIV. SUNRISE LIMITED WARRANTY A. FOR FIVE (5) YEARS E. WHAT WE WILL DO Sunrise warrants the frame of this wheelchair against defects in Our sole liability is to repair or replace covered parts. This is the materials and workmanship for five years from date of first con- exclusive remedy for consequential damages.
  • Page 42 Sunrise Medical • 2842 Business Park Ave. • Fresno, CA 93727 • USA In Canada (800) 263-3390 Customer Ser vice: 800.333.4000 ©2010 Sunrise Medical (US) LLC www.SunriseMedical.com 10.10 108833 Rev. C...
